1、安装库

npm install typings echarts --global

npm install ngx-echarts --save

npm install @types/echarts --save

2、app.module引入

import { browserModule } from ''@angular/platform-browser'';
import { NgModule } from ''@angular/core'';
import { AppRoutingModule } from ''./app-routing.module'';
import { AppComponent } from ''./app.component'';
import { HomeComponent } from ''./home/home.component'';
import {browserAnimationsModule} from "@angular/platform-browser/animations";
import {ButtonModule} from ''primeng/primeng'';
import { HeaderComponent } from ''./components/header/header.component'';  // header  components
import {NgxEchartsModule} from ''ngx-echarts'';
@NgModule({
  declarations: [
    AppComponent,
    HomeComponent,
    HeaderComponent,
    // selfHttp
  ],
  imports: [
    browserModule,
    HttpClientModule,
    AppRoutingModule,
    browserAnimationsModule,
    ButtonModule,
    NgxEchartsModule
  ],
  providers: [httpInterceptorProviders, apiList,{provide: LocationStrategy, useClass: HashLocationStrategy}],
  bootstrap: [AppComponent]
})
export class AppModule { }

3、具体文件使用

HTML代码

<div #myCharts echarts [options]="chartOption"></div>

ts代码

import { Component, OnInit, Input } from ''@angular/core'';
import { MessageService } from ''primeng/api'';
import * as ec from ''echarts'';  // 没有安装ypes/echarts就会报错
@Component({
  selector: ''app-table'',
  templateUrl: ''./table.component.html'',
  styleUrls: [''./table.component.css''],
  providers: [MessageService]
})

export class TableComponent implements OnInit {


  chartOption: any;
  constructor(private messageService: MessageService) {

  }

  ngOnInit() {
    this.selectedColumns = this.tablelist.header;
    this.items = [
      {
        label: ''查看'', icon: ''pi pi-eye'', command: (event) => this.showDialog()
      },
      { label: ''删除'', icon: ''pi pi-trash'', command: (event) => this.del() }
    ];

  }
  onRowSelect(event) {
    this.data = {
      labels: [],
      datasets: []
    };
    this.displaySidebar = true;
    // 组装图表
    var data1 = [];
    var data2 = [];
    var data3 = [];
    this.selectedList.forEach((element, index) => {
      data1.push((element.month + ''月''));
      // 销量
      data2.push(element.sale);
      // 店铺数
      data3.push(element.comNum);
    });
    this.chartOption = {
      // title: {
      //   text: ''堆叠区域图''
      // },
      backgroundColor: ''#2c343c'',
      tooltip: {
        trigger: ''axis''
      },
      legend: {
        data: [''零售额'', ''店铺总数'',],
        textStyle: {//图例文字的样式
          color: ''white'',
          fontSize: 16
        }
      },
      toolBox: {
        orient: ''vertical'',
        top: ''middle'',
        feature: {
          // dataView: {//数据视图工具，可以展现当前图表所用的数据，编辑后可以动态更新。
          //   show: true,//是否显示组件。
          //   readOnly: false
          // },
          magicType: {//动态类型切换 示例：feature: { magicType: {type: [''line'', ''bar'', ''stack'', ''tiled'']}}
            show: true,
            type: [''line'', ''bar'']
          },
          restore: {//配置项还原。
            show: true
          },
          saveAsImage: {}
        }
      },
      dataZoom: {//dataZoom 组件 用于区域缩放，从而能自由关注细节的数据信息，或者概览数据整体，或者去除离群点的影响。
        type: ''slider'',//滑动条型数据区域缩放组件
        start: 0,//起始位置0
        end: 100//结束位置100
      },
      grid: {
        left: ''3%'',
        right: ''4%'',
        bottom: ''40px'',
        containLabel: true
      },
      xAxis: [
        {
          type: ''category'',
          boundaryGap: false,
          axisLabel: {
            interval: 0,
            textStyle: {
              color: ''#c3dbff'',  //更改坐标轴文字颜色
              fontSize: 14      //更改坐标轴文字大小
            }
          },
          data: data1,
          axisLine: {
            linestyle: {
              color: ''white'', //更改坐标轴颜色
            }
          }
        }
      ],
      yAxis: [
        {
          type: ''value'',
          axisLabel: {
            interval: 0,
            textStyle: {
              color: ''#c3dbff'',  //更改坐标轴文字颜色
              fontSize: 14      //更改坐标轴文字大小
            }
          },
          axisLine: {
            linestyle: {
              color: ''white'', //更改坐标轴颜色
            }
          }
        }
      ],
      series: [
        {
          name: ''零售额'',
          type: ''line'',
          stack: ''总量'',
          areaStyle: {normal: {
            color:new ec.graphic.LinearGradient(0, 0, 0, 1, [  //随机颜色
              { offset: 0, color: ''red'' },
              { offset: 0.5, color: ''pink'' },
              { offset: 1, color: ''#ddd'' }
            ])
          }},
          itemStyle: {
            normal: {
              color: function () {
                return ''#'' + Math.floor(Math.random() * 0xffffff).toString(16); // 随机颜色
              }
            }
          },
          data: data2
        },
        {
          name: ''店铺总数'',
          type: ''line'',
          stack: ''总量'',
          areaStyle: {normal: {
            color:new ec.graphic.LinearGradient(0, 0, 0, 1, [
              { offset: 0, color: ''#9cd4d8'' },
              { offset: 0.5, color: ''#aec9fe'' },
              { offset: 1, color: ''pink'' }
            ])
          }},
          itemStyle: {
            normal: {
              color: function () {
                return ''#'' + Math.floor(Math.random() * 0xffffff).toString(16);
              }
            }
          },
          data: data3
        },
      ]
    }
  }

}

注意：渲染数据的时机要选好，组装数据放在最后组装，如果把chartOption 定义在前面，再给series赋值图表是不会更新的，当然ec的方法里面可能会有，但是确挺麻烦的，优先考虑简单的。

 有点colorful了，自己调整下。
