Android 进阶答疑:Hook（android hook技术）
接下来深海会和大家逐步分享分析Android插件化相关的东西
要了解插件化首先要具备三个前提条件：
1.Android 系统源码阅读于理解
2.Java 反射机制
3.Hook技术
今天咱们就一起分析Hook的相关知识
一.Hook是什么？
在事件执行的过程中截获并监控事件的执行流，将自身的代码融入其执行流中
二.简单举例: Hook 修改 View.OnClickListener 事件
首先阅读系统类View的源码，找到Hook点击事件的关键代码
看点击事件的方法：这边传入的事件赋给了ListenerInfo对象的mOnClickListener接口实例
public void setonClickListener(@Nullable OnClickListener l) {
if (!isClickable()) {
setClickable(true);
}
getListenerInfo().mOnClickListener = l;
}追溯该方法：该方法返回了ListenerInfo对象
@UnsupportedAppUsage
ListenerInfo getListenerInfo() {
if (mListenerInfo != null) {
return mListenerInfo;
}
mListenerInfo = new ListenerInfo();
return mListenerInfo;
}然后整理结构：
得出Hook路线：
1.拿到View对象中的mListenerInfo对象
2.然后拿到mOnClickListener接口实例
3.对该实例进行二次封装后替换该实例
具体实现代码：
/*
*作者:赵星海
*时间:2020/6/23 9:51
*用途:Hook简单举例（View点击事件）
*/
public static void hookOnClickListener(View view) throws Exception {
// 第一步：反射得到 ListenerInfo 对象
Method getListenerInfo = View.class.getDeclaredMethod("getListenerInfo");
getListenerInfo.setAccessible(true);
Object listenerInfo = getListenerInfo.invoke(view);
// 第二步：得到原始的 OnClickListener事件方法
Class<?> listenerInfoClz = Class.forName("android.view.View$ListenerInfo");
Field mOnClickListener = listenerInfoClz.getDeclaredField("mOnClickListener");
mOnClickListener.setAccessible(true);
View.OnClickListener originonClickListener = (View.OnClickListener) mOnClickListener.get(listenerInfo);
// 第三步：用 Hook代理类 替换原始的 OnClickListener
View.OnClickListener hookedOnClickListener = new HookedClickListener(originonClickListener);
mOnClickListener.set(listenerInfo, hookedOnClickListener);
}
public static class HookedClickListener implements View.OnClickListener {
private View.OnClickListener origin;
public HookedClickListener(View.OnClickListener origin) {
this.origin = origin;
}
@Override
public void onClick(View v) {
// Toast.makeText(v.getContext(), "你的点击事件被赵星海劫持了！", Toast.LENGTH_SHORT).show();
if (origin != null) {
origin.onClick(v);
}
}
}好了今天的分享就到这里哦，关于上诉内容，有任何的疑惑或者建议欢迎评论区沟通交流哦~
深海特别愿意和大家一起互相学习互相进步
和
- <!--{hook/global_cpnav_extra1}-->和<!--{hook/global_cpnav_extra2}-->
- <!--{hook/global_cpnav_extra1}-->顶部左边
<!--{hook/global_cpnav_extra2}-->顶部右边 复制代码
androd hook acitivity 启动流程，替换启动的activity（Android Instrumentation）
前言：如果程序想要知道有activity启动，如果想要拦截activity，然后跳转到指定的activity怎么办？
我们看下ActivityThread 里面：
private Activity performLaunchActivity(ActivityClientRecord r, Intent customIntent) {
// System.out.println("##### [" + System.currentTimeMillis() + "] ActivityThread.performLaunchActivity(" + r + ")");
ActivityInfo aInfo = r.activityInfo;
if (r.packageInfo == null) {
r.packageInfo = getPackageInfo(aInfo.applicationInfo, r.compatInfo,
Context.CONTEXT_INCLUDE_CODE);
}
ComponentName component = r.intent.getComponent();
if (component == null) {
component = r.intent.resolveActivity(
mInitialApplication.getPackageManager());
r.intent.setComponent(component);
}
if (r.activityInfo.targetActivity != null) {
component = new ComponentName(r.activityInfo.packageName,
r.activityInfo.targetActivity);
}
ContextImpl appContext = createBaseContextForActivity(r);
Activity activity = null;
try {
java.lang.ClassLoader cl = appContext.getClassLoader();
activity = mInstrumentation.newActivity(
cl, component.getClassName(), r.intent);
StrictMode.incrementExpectedActivityCount(activity.getClass());
r.intent.setExtrasClassLoader(cl);
r.intent.prepareToEnterProcess();
if (r.state != null) {
r.state.setClassLoader(cl);
}
} catch (Exception e) {
if (!mInstrumentation.onException(activity, e)) {
throw new RuntimeException(
"Unable to instantiate activity " + component
+ ": " + e.toString(), e);
}
}
....
if (activity != null) {
CharSequence title = r.activityInfo.loadLabel(appContext.getPackageManager());
Configuration config = new Configuration(mCompatConfiguration);
if (r.overrideConfig != null) {
config.updateFrom(r.overrideConfig);
}
if (DEBUG_CONFIGURATION) Slog.v(TAG, "Launching activity "
+ r.activityInfo.name + " with config " + config);
Window window = null;
if (r.mPendingRemoveWindow != null && r.mPreserveWindow) {
window = r.mPendingRemoveWindow;
r.mPendingRemoveWindow = null;
r.mPendingRemoveWindowManager = null;
}
appContext.setOuterContext(activity);
activity.attach(appContext, this, getInstrumentation(), r.token,
r.ident, app, r.intent, r.activityInfo, title, r.parent,
r.embeddedID, r.lastNonConfigurationInstances, config,
r.referrer, r.voiceInteractor, window, r.configCallback);
if (customIntent != null) {
activity.mIntent = customIntent;
}
可以看到，执行启动activity的时候，
activity = mInstrumentation.newActivity(
cl, component.getClassName(), r.intent);
StrictMode.incrementExpectedActivityCount(activity.getClass());
那么我们是不是可以在这个时候拦截一下返回的activity呢？
OK,我们继承Instrumentation，并且重写里面的方法。
package com.****r.app;
import android.app.Activity;
import android.app.Instrumentation;
import android.content.Intent;
import com.*****.ActivityAbout;
/**
* =======================================================================================
* 作 者：caoxinyu
* 创建日期：2019/2/19.
* 类的作用:
* 修订历史：
* =======================================================================================
*/
public class MyInstrumentation extends Instrumentation {
private Instrumentation base;
public MyInstrumentation(Instrumentation base) {
this.base = base;
}
@Override
public Activity newActivity(ClassLoader cl, String className, Intent intent) throws InstantiationException, IllegalAccessException, ClassNotFoundException {
try {
//这里需要setExtrasClassLoader 不然的话，getParecleable 对象可能会拿不到
//很多hook Instrumentation的人都不知道。
// 这里try catch 是防止恶意攻击 导致android.os.BadParcelableException: ClassNotFoundException when unmarshalling
intent.setExtrasClassLoader(cl);
intent.getBooleanExtra("a",false);
}catch (Exception e){
}
if (intent.getBooleanExtra("ActivityAbout",false)) {
return super.newActivity(cl, ActivityAbout.class.getName(), intent);
}
return super.newActivity(cl,className, intent);
}
}
那么怎么使我们重写的类生效呢？
package com.***;
import android.app.Instrumentation;
import java.lang.reflect.Field;
import java.lang.reflect.Method;
public class Hooker {
private static final String TAG = "Hooker";
public static void hookInstrumentation() {
Class<?> activityThread = null;
try {
activityThread = Class.forName("android.app.ActivityThread");
Method sCurrentActivityThread = activityThread.getDeclaredMethod("currentActivityThread");
sCurrentActivityThread.setAccessible(true);
//获取ActivityThread 对象
Object activityThreadObject = sCurrentActivityThread.invoke(activityThread);
//获取 Instrumentation 对象
Field mInstrumentation = activityThread.getDeclaredField("mInstrumentation");
mInstrumentation.setAccessible(true);
Instrumentation instrumentation = (Instrumentation) mInstrumentation.get(activityThreadObject);
MyInstrumentation customInstrumentation = new MyInstrumentation(instrumentation);
//将我们的 customInstrumentation 设置进去
mInstrumentation.set(activityThreadObject, customInstrumentation);
} catch (Exception e) {
e.printStackTrace();
}
}
}
上面这些代码是通过反射，把自己的Instrumentation 设置进去。
然后在程序初始化的时候，调用下面的代码即可。
Hooker.hookInstrumentation();
我们启动一个A activity，如果intent.getBooleanExtra(“ActivityAbout”,false)，那么你的A activity 将被拦截成ActivityAbout。
那么还有一个问题，为什么要设置ClassLoader?
intent.setExtrasClassLoader(cl);
因为如果不设置的话，getParecleable 对象可能会拿不到。在8.0以前的手机，直接崩溃：android.os.BadParcelableException: ClassNotFoundException when unmarshalling。在8.0以上的话，系统会catch 住这个崩溃，但是你的数据全都会被清空。
具体分析如下：
简单try catch，在低版本上没有问题。但是在android8.0以上，会有问题。
在Android8.0以上，如果getBooleanExt 方法里面失败了，系统会catch BadParcelableException，并把intent 里面的数据清空。具体可见下面的截图，
这就导致简单try catch 之后的代码，运行在8.0以上手机，收不到intent里面的数据，因为Intent 里面的跳转数据被清空了。
还是要查清楚为什么会出现ClassNotFoundException when unmarshalling
根据源码，在这里getBooleanExt 会出问题是因为系统在这一步还没有设置解析Parcelable 的classLoader。如下图
所以，有问题的代码需要这样改下。
系统是在调用了 mInstrumentation.newActivity之后设置了classLoader r.intent.setExtrasClassLoader(cl), 所以hook 在newActivity 这一步get Parcelable 数据是有问题的。
不然会有下面这种错误：
java.lang.RuntimeException: Unable to instantiate activity ComponentInfo{com.aaa./.WelcomeActivity}: android.os.BadParcelableException: ClassNotFoundException when unmarshalling: com.nearme.mcs.entity.MessageEntity
at android.app.ActivityThread.performLaunchActivity(ActivityThread.java:2492)
at android.app.ActivityThread.handleLaunchActivity(ActivityThread.java:2678)
at android.app.ActivityThread.access$900(ActivityThread.java:187)
at android.app.ActivityThread$H.handleMessage(ActivityThread.java:1523)
at android.os.Handler.dispatchMessage(Handler.java:111)
at android.os.Looper.loop(Looper.java:210)
at android.app.ActivityThread.main(ActivityThread.java:5809)
at java.lang.reflect.Method.invoke(Native Method)
at java.lang.reflect.Method.invoke(Method.java:372)
at com.android.internal.os.ZygoteInit$MethodAndArgsCaller.run(ZygoteInit.java:1113)
at com.android.internal.os.ZygoteInit.main(ZygoteInit.java:879)
Caused by: android.os.BadParcelableException: ClassNotFoundException when unmarshalling: com.nearme.mcs.entity.MessageEntity
at android.os.Parcel.readParcelableCreator(Parcel.java:2305)
at android.os.Parcel.readParcelable(Parcel.java:2255)
at android.os.Parcel.readValue(Parcel.java:2162)
at android.os.Parcel.readArrayMapInternal(Parcel.java:2495)
at android.os.BaseBundle.unparcel(BaseBundle.java:221)
at android.os.BaseBundle.getBoolean(BaseBundle.java:658)
at android.content.Intent.getBooleanExtra(Intent.java:5129)
at com.nearme.game.sdk.y.o_a(SourceFile:46)
at com.nearme.game.sdk.y.newActivity(SourceFile:28)
at android.app.ActivityThread.performLaunchActivity(ActivityThread.java:2469)
at android.app.ActivityThread.handleLaunchActivity(ActivityThread.java:2678)
at android.app.ActivityThread.access$900(ActivityThread.java:187)
at android.app.ActivityThread$H.handleMessage(ActivityThread.java:1523)
at android.os.Handler.dispatchMessage(Handler.java:111)
at android.os.Looper.loop(Looper.java:210)
at android.app.ActivityThread.main(ActivityThread.java:5809)
at java.lang.reflect.Method.invoke(Native Method)
at java.lang.reflect.Method.invoke(Method.java:372)
at com.android.internal.os.ZygoteInit$MethodAndArgsCaller.run(ZygoteInit.java:1113)
at com.android.internal.os.ZygoteInit.main(ZygoteInit.java:879)
加油，自己学会了使用Source Insight 看源码。开始慢慢的去学习技术的原理。加油！
Android ClassLoader Hook 注入方式
最近尝试热修复，反射调用补丁类，发现 android O 的类提前加载了，但没有初始化，所以出现了补丁无法生效的问题，对比一下之前版本，发现 Android 6.0 执行到指定位置才去加载，并且初始化，因此想法去证实这个问题。
一、为什么要注入 ClassLoader？
- 观察 Android 中类的加载时机、类的机制、定为加载问题
- 观察补丁包或者插件加载机制
二、替换方式
默认形式
PathClassloader.parent <- PathClassloader
方案一：
PathClassloader.parent <- Hook ClassLoader <- PathClassloader
这种方案实现比较简单
public class DelegateClassLoader extends PathClassLoader {
private ClassLoader mPathClassLoader;
private DelegateClassLoader(String dexPath,ClassLoader parentClassLoader) {
super(dexPath, parentClassLoader);
mPathClassLoader = getClass().getClassLoader();
}
//PathClassloader.parent <- PathClassloader ====> PathClassloader.parent <- Hook ClassLoader <- PathClassloader
public static synchronized void hook(ClassLoader pathClassLoader) throws NoSuchFieldException, IllegalAccessException {
ClassLoader classLoader = new DelegateClassLoader("",pathClassLoader.getParent());
Field parentField = ClassLoader.class.getDeclaredField("parent");
parentField.setAccessible(true);
parentField.set(pathClassLoader,classLoader);
Thread.currentThread().setContextClassLoader(classLoader);
}
@Override
protected Class<?> loadClass(String name, boolean resolve) throws ClassNotFoundException {
return super.loadClass(name, resolve);
}
@Override
protected Class<?> findClass(String name) throws ClassNotFoundException {
return super.findClass(name);
}
}调用方式如下
public class BaseHotfixApplication extends Application {
@Override
protected void attachBaseContext(Context base) {
super.attachBaseContext(base);
try {
DelegateClassLoader.hook(base.getClassLoader());
} catch (NoSuchFieldException e) {
e.printStackTrace();
} catch (IllegalAccessException e) {
e.printStackTrace();
}
}
@Override
public void onCreate() {
super.onCreate();
}
}
方案二：
PathClassloader.parent <- PathClassloader <- Hook ClassLoader
本方案比较局限，但同样比较流行，来自 Tinker 的方案，本方案是为了解决热修复补丁包在 Android N 以后版本的混编问题
final class NewClassLoaderInjector {
public static ClassLoader inject(Application app, ClassLoader oldClassLoader, File dexOptDir,
boolean useDLC, List<File> patchedDexes) throws Throwable {
final String[] patchedDexPaths = new String[patchedDexes.size()];
for (int i = 0; i < patchedDexPaths.length; ++i) {
patchedDexPaths[i] = patchedDexes.get(i).getAbsolutePath();
}
final ClassLoader newClassLoader = createNewClassLoader(oldClassLoader,
dexOptDir, useDLC, patchedDexPaths);
doInject(app, newClassLoader);
return newClassLoader;
}
public static void triggerDex2Oat(Context context, File dexOptDir, boolean useDLC,
String... dexPaths) throws Throwable {
final ClassLoader triggerClassLoader = createNewClassLoader(context.getClassLoader(), dexOptDir, useDLC, dexPaths);
}
@SuppressWarnings("unchecked")
private static ClassLoader createNewClassLoader(ClassLoader oldClassLoader,
File dexOptDir,
boolean useDLC,
String... patchDexPaths) throws Throwable {
final Field pathListField = findField(
Class.forName("dalvik.system.BaseDexClassLoader", false, oldClassLoader),
"pathList");
final Object oldPathList = pathListField.get(oldClassLoader);
final StringBuilder dexPathBuilder = new StringBuilder();
final boolean hasPatchDexPaths = patchDexPaths != null && patchDexPaths.length > 0;
if (hasPatchDexPaths) {
for (int i = 0; i < patchDexPaths.length; ++i) {
if (i > 0) {
dexPathBuilder.append(File.pathSeparator);
}
dexPathBuilder.append(patchDexPaths[i]);
}
}
final String combinedDexPath = dexPathBuilder.toString();
final Field nativeLibraryDirectoriesField = findField(oldPathList.getClass(), "nativeLibraryDirectories");
List<File> oldNativeLibraryDirectories = null;
if (nativeLibraryDirectoriesField.getType().isArray()) {
oldNativeLibraryDirectories = Arrays.asList((File[]) nativeLibraryDirectoriesField.get(oldPathList));
} else {
oldNativeLibraryDirectories = (List<File>) nativeLibraryDirectoriesField.get(oldPathList);
}
final StringBuilder libraryPathBuilder = new StringBuilder();
boolean isFirstItem = true;
for (File libDir : oldNativeLibraryDirectories) {
if (libDir == null) {
continue;
}
if (isFirstItem) {
isFirstItem = false;
} else {
libraryPathBuilder.append(File.pathSeparator);
}
libraryPathBuilder.append(libDir.getAbsolutePath());
}
final String combinedLibraryPath = libraryPathBuilder.toString();
ClassLoader result = null;
if (useDLC && Build.VERSION.SDK_INT >= 27) {
result = new DelegateLastClassLoader(combinedDexPath, combinedLibraryPath, ClassLoader.getSystemClassLoader());
final Field parentField = ClassLoader.class.getDeclaredField("parent");
parentField.setAccessible(true);
parentField.set(result, oldClassLoader);
} else {
result = new TinkerClassLoader(combinedDexPath, dexOptDir, combinedLibraryPath, oldClassLoader);
}
// ''EnsureSameClassLoader'' mechanism which is first introduced in Android O
// may cause exception if we replace definingContext of old classloader.
if (Build.VERSION.SDK_INT < 26) {
findField(oldPathList.getClass(), "definingContext").set(oldPathList, result);
}
return result;
}
private static void doInject(Application app, ClassLoader classLoader) throws Throwable {
Thread.currentThread().setContextClassLoader(classLoader);
final Context baseContext = (Context) findField(app.getClass(), "mBase").get(app);
try {
findField(baseContext.getClass(), "mClassLoader").set(baseContext, classLoader);
} catch (Throwable ignored) {
// There''s no mClassLoader field in ContextImpl before Android O.
// However we should try our best to replace this field in case some
// customized system has one.
}
final Object basePackageInfo = findField(baseContext.getClass(), "mPackageInfo").get(baseContext);
findField(basePackageInfo.getClass(), "mClassLoader").set(basePackageInfo, classLoader);
if (Build.VERSION.SDK_INT < 27) {
final Resources res = app.getResources();
try {
findField(res.getClass(), "mClassLoader").set(res, classLoader);
final Object drawableInflater = findField(res.getClass(), "mDrawableInflater").get(res);
if (drawableInflater != null) {
findField(drawableInflater.getClass(), "mClassLoader").set(drawableInflater, classLoader);
}
} catch (Throwable ignored) {
// Ignored.
}
}
}
private static Field findField(Class<?> clazz, String name) throws Throwable {
Class<?> currClazz = clazz;
while (true) {
try {
final Field result = currClazz.getDeclaredField(name);
result.setAccessible(true);
return result;
} catch (Throwable ignored) {
if (currClazz == Object.class) {
throw new NoSuchFieldException("Cannot find field "
+ name + " in class " + clazz.getName() + " and its super classes.");
} else {
currClazz = currClazz.getSuperclass();
}
}
}
}
private NewClassLoaderInjector() {
throw new UnsupportedOperationException();
}
}ClassLoader 定义如下
@Keep
@SuppressLint("NewApi")
public final class TinkerClassLoader extends BaseDexClassLoader {
private final ClassLoader mOriginAppClassLoader;
TinkerClassLoader(String dexPath, File optimizedDir, String libraryPath, ClassLoader originAppClassLoader) {
super(dexPath, optimizedDir, libraryPath, ClassLoader.getSystemClassLoader());
mOriginAppClassLoader = originAppClassLoader;
}
@Override
protected Class<?> findClass(String name) throws ClassNotFoundException {
Class<?> cl = null;
try {
cl = super.findClass(name);
} catch (ClassNotFoundException ignored) {
cl = null;
}
if (cl != null) {
return cl;
} else {
return mOriginAppClassLoader.loadClass(name);
}
}
@Override
public URL getResource(String name) {
// The lookup order we use here is the same as for classes.
URL resource = Object.class.getClassLoader().getResource(name);
if (resource != null) {
return resource;
}
resource = findResource(name);
if (resource != null) {
return resource;
}
return mOriginAppClassLoader.getResource(name);
}
@Override
public Enumeration<URL> getResources(String name) throws IOException {
@SuppressWarnings("unchecked")
final Enumeration<URL>[] resources = (Enumeration<URL>[]) new Enumeration<?>[] {
Object.class.getClassLoader().getResources(name),
findResources(name),
mOriginAppClassLoader.getResources(name)
};
return new CompoundEnumeration<>(resources);
}
@Keep
class CompoundEnumeration<E> implements Enumeration<E> {
private Enumeration<E>[] enums;
private int index = 0;
public CompoundEnumeration(Enumeration<E>[] enums) {
this.enums = enums;
}
@Override
public boolean hasMoreElements() {
while (index < enums.length) {
if (enums[index] != null && enums[index].hasMoreElements()) {
return true;
}
index++;
}
return false;
}
@Override
public E nextElement() {
if (!hasMoreElements()) {
throw new NoSuchElementException();
}
return enums[index].nextElement();
}
}
}
Android Exception Hook
承接上一篇文章Android Inline Hook，接下来我们看一下android系统中基于异常的hook方式，这种方式与inline hook相比实现较为简单，但执行效率是它的短板。
exception hook的执行流程大致如下：
如图所示，在hook过程中需要多次对hook点指令和hook点的下一条指令进行修改，由此造成在执行效率上的损耗。
首先我们需要将hook点指令替换为一条不合法的异常指令，当程序执行到该位置时进程会接收到信号SIGILL（illegal instruction），然后进入到我们注册的SIgnal Handler中，在信号处理函里我们需要做两件事，一是执行我们的hook逻辑（如修改寄存器的值），二是恢复hook点指令并将hook点指令的下一条指令替换为异常指令，再恢复程序的运行。当程序运行到hook点的下一条指令时会再次触发异常进入信号处理函数，这一次我们需要在信号处理函数中将hook点指令再次替换为异常指令，然后恢复hook点的下一条指令，最后恢复程序运行。
由此可见，我们在信号处理函数中需要对异常的发生位置进行判断，对hook点跟hook点的下一条指令进行区分。当然最重要的是理解Linux系统中的信号机制。
void signal_handler(int signum, siginfo_t *Ssiginfo, void *context)
{
//信号处理函数
ucontext_t *uc = context;
struct sigcontext *sigc = &uc->uc_mcontext; } struct sigaction sig; //initialize the signal set sigemptyset(&sig.sa_mask); //make sigaction.sa_sigaction specifies the //signal-handling function for signum sig.sa_flags = SA_SIGINFO; //attach our handler sig.sa_sigaction = signal_handler; sigaction(SIGILL, &sig, NULL);通过sigaction函数对信号进行注册后我们便可以在信号处理函数中对其进行处理。Linux用户手册中对该函数进行了详细的说明，可参阅：Linux Programmer''s Manual SIGACTION(2)
在信号处理函数中我们可以通过结构体sigcontext获取异常发生时各个寄存器的信息，其定义如下：
struct sigcontext {
unsigned long trap_no; unsigned long error_code; unsigned long oldmask;
unsigned long arm_r0; unsigned long arm_r1; unsigned long arm_r2;
unsigned long arm_r3; unsigned long arm_r4; unsigned long arm_r5;
unsigned long arm_r6; unsigned long arm_r7; unsigned long arm_r8;
unsigned long arm_r9; unsigned long arm_r10; unsigned long arm_fp;
unsigned long arm_ip; unsigned long arm_sp; unsigned long arm_lr;
unsigned long arm_pc; unsigned long arm_cpsr;unsigned long fault_address;
};例如我们可以通过pc寄存器的值确定程序执行的位置。
完整程序如下：
1 #include <assert.h>
2 #include <unistd.h>
3 #include <stdlib.h>
4 #include <stdio.h>
5 #include <signal.h>
6 #include <ucontext.h>
7 #include <sys/mman.h>
8
9 int g_code_type;
10 long g_code_address;
11 uint32_t g_code_origin;
12 uint32_t g_code_next;
13
14 long get_module_addr(pid_t pid, const char *module_name)
15 {
16 FILE *fp;
17 char file_path[256];
18 char file_line[512];
19 if (pid < 0) {
20 snprintf(file_path, sizeof(file_path), "/proc/self/maps");
21 } else {
22 snprintf(file_path, sizeof(file_path), "/proc/%d/maps", pid);
23 }
24 fp = fopen(file_path, "r");
25 if (fp == NULL) {
26 return -1;
27 }
28 long addr_start = -1, addr_end = 0;
29 while (fgets(file_line, sizeof(file_line), fp)) {
30 if (strstr(file_line, module_name)) {
31 if (2 == sscanf(file_line, "%8lx-%8lx", &addr_start, &addr_end)) {
32 break;
33 }
34 }
35 }
36 fclose(fp);
37 return addr_start;
38 }
39
40 bool change_addr_attr(long address, bool writable) {
41 //根据内存页大小对齐
42 long page_size = sysconf(_SC_PAGESIZE);
43 long page_start = address & (~(page_size - 1));
44 if (writable == true) {
45 return mprotect((void*)page_start, page_size, PROT_READ | PROT_WRITE | PROT_EXEC) != -1;
46 } else {
47 return mprotect((void*)page_start, page_size, PROT_READ | PROT_EXEC) != -1;
48 }
49 }
50
51 bool write_code(long address, uint32_t data)
52 {
53 if (change_addr_attr(address, true) == false) {
54 return false;
55 }
56 if (g_code_type == IS_THUMB) {
57 *((uint16_t*)address) = (uint16_t)data;
58 } else {
59 *((uint32_t*)address) = data;
60 }
61 return change_addr_attr(address, false);
62 }
63
64 bool write_ill_instruction(long address, uint32_t *save)
65 {
66 if (g_code_type == IS_THUMB) {
67 *save = *((uint16_t*)address);
68 } else if (g_code_type == IS_ARM) {
69 *save = *((uint32_t*)address);
70 }
71 return write_code(address, 0xFFFFFFFF);
72 }
73
74 static void signal_handler(int signum, siginfo_t *Ssiginfo, void *context)
75 {
76 ucontext_t *uc = context;
77 struct sigcontext *sigc = &uc->uc_mcontext;
78
79 long next_address = g_code_address + (IS_ARM ? 4 : 2);
80
81 if (sigc->arm_pc == g_code_address) {
82 //恢复hook点指令
83 write_code(g_code_address, g_code_origin);
84 //将hook点下一条指令改为异常指令
85 write_ill_instruction(next_address, &g_code_next);
86 } else if (sigc->arm_pc == next_address){
87 //恢复hook点下一条指令
88 write_code(next_address, g_code_next);
89 //将hook点指令改为异常指令
90 write_ill_instruction(g_code_address, &g_code_origin);
91 } else {
92 exit(EXIT_FAILURE);
93 }
94 }
95
96 bool hook_exception_make(const char *library, long address, enum code_type type)
97 {
98 g_code_type = type;
99
100 struct sigaction sig;
101 sigemptyset(&sig.sa_mask);
102 sig.sa_flags = SA_SIGINFO;
103 sig.sa_sigaction = signal_handler;
104 sigaction(SIGILL, &sig, NULL);
105
106 long target_address = get_module_addr(-1, library);
107 g_code_address = target_address + address;
108 return write_ill_instruction(g_code_address, &g_code_origin);
109 }
今天关于Android 进阶答疑:Hook和android hook技术的介绍到此结束，谢谢您的阅读，有关和、androd hook acitivity 启动流程，替换启动的activity（Android Instrumentation）、Android ClassLoader Hook 注入方式、Android Exception Hook等更多相关知识的信息可以在本站进行查询。
本文标签：
