编译分布式并行版caffe（Open MPI）教程（c++分布式编译）
caffe版本：https://github.com/yjxiong/caffe
使用环境：
1 CentOS release 6.6 (Final)
2 CUDA8.0
3 CuDNN6.0
4 Open MPI 3.1.3
5 OpenCV 3.1.0CUDA8.0、CuDNN6.0、OpenCV3.1.0以及其他caffe所需要的依赖已经装好，这里仅需要安装OpenMPI3.1.3，步骤如下：
OpenMPI-3.1.3安装
1. 解压openmpi-3.1.3，进入解压后的文件夹 — openmpi3.1.3，在终端输入如下命令：
1 ./configure --prefix=/storage/student5/usr/local/openmpi --with-cuda --enable-mpi-thread-multiple
2 #--prefix后的路径未openmpi的安装路径；
3 sudo make all install
4 # make all install 加sudo，否则安装过程中可能出问题2. 测试安装是否成功
1 cd openmpi-3.1.3/examples
2 make
3 mpirun -np 4 hello_cCaffe安装
1. 下载caffe，将Makefile.config.example另存为Makefile.config，将其修改成以下的样子：
1 ## Refer to http://caffe.berkeleyvision.org/installation.html
2 # Contributions simplifying and improving our build system are welcome!
3
4 # cuDNN acceleration switch (uncomment to build with cuDNN).
5 USE_CUDNN := 1
6
7 # CPU-only switch (uncomment to build without GPU support).
8 # CPU_ONLY := 1
9
10 # uncomment to disable IO dependencies and corresponding data layers
11 USE_OPENCV := 1
12 USE_LEVELDB := 1
13 USE_LMDB := 1
14
15 # Uncomment if you''re using OpenCV 3
16 OPENCV_VERSION := 3
17
18 # To customize your choice of compiler, uncomment and set the following.
19 # N.B. the default for Linux is g++ and the default for OSX is clang++
20 # CUSTOM_CXX := g++
21
22 # CUDA directory contains bin/ and lib/ directories that we need.
23 CUDA_DIR := /usr/local/cuda
24 # On Ubuntu 14.04, if cuda tools are installed via
25 # "sudo apt-get install nvidia-cuda-toolkit" then use this instead:
26 # CUDA_DIR := /usr
27
28 # CUDA architecture setting: going with all of them.
29 # For CUDA < 6.0, comment the *_50 lines for compatibility.
30 CUDA_ARCH := -gencode arch=compute_30,code=sm_30 \
31 -gencode arch=compute_35,code=sm_35 \
32 -gencode arch=compute_50,code=sm_50 \
33 -gencode arch=compute_50,code=compute_50
34
35 # BLAS choice:
36 # atlas for ATLAS (default)
37 # mkl for MKL
38 # open for OpenBlas
39 BLAS := atlas
40 # Custom (MKL/ATLAS/OpenBLAS) include and lib directories.
41 # Leave commented to accept the defaults for your choice of BLAS
42 # (which should work)!
43 BLAS_INCLUDE := /usr/include
44 BLAS_LIB := /usr/lib64/atlas
45
46 # Homebrew puts openblas in a directory that is not on the standard search path
47 # BLAS_INCLUDE := $(shell brew --prefix openblas)/include
48 # BLAS_LIB := $(shell brew --prefix openblas)/lib
49
50 # This is required only if you will compile the matlab interface.
51 # MATLAB directory should contain the mex binary in /bin.
52 MATLAB_DIR := /usr/local/MATLAB/R2014a
53 # MATLAB_DIR := /Applications/MATLAB_R2012b.app
54
55 # NOTE: this is required only if you will compile the python interface.
56 # We need to be able to find Python.h and numpy/arrayobject.h.
57 PYTHON_INCLUDE := /usr/include/python2.7 \
58 /usr/lib/python2.7/dist-packages/numpy/core/include
59 # Anaconda Python distribution is quite popular. Include path:
60 # Verify anaconda location, sometimes it''s in root.
61 # ANACONDA_HOME := $(HOME)/anaconda
62 # PYTHON_INCLUDE := $(ANACONDA_HOME)/include \
63 # $(ANACONDA_HOME)/include/python2.7 \
64 # $(ANACONDA_HOME)/lib/python2.7/site-packages/numpy/core/include \
65
66 # We need to be able to find libpythonX.X.so or .dylib.
67 PYTHON_LIB := /usr/lib
68 # PYTHON_LIB := $(ANACONDA_HOME)/lib
69
70 # Homebrew installs numpy in a non standard path (keg only)
71 # PYTHON_INCLUDE += $(dir $(shell python -c ''import numpy.core; print(numpy.core.__file__)''))/include
72 # PYTHON_LIB += $(shell brew --prefix numpy)/lib
73
74 # Uncomment to support layers written in Python (will link against Python libs)
75 WITH_PYTHON_LAYER := 1
76
77 # Whatever else you find you need goes here.
78 INCLUDE_DIRS := $(PYTHON_INCLUDE) /usr/local/include
79 LIBRARY_DIRS := $(PYTHON_LIB) /usr/local/lib /usr/lib
80
81 # If Homebrew is installed at a non standard location (for example your home directory) and you use it for general dependencies
82 # INCLUDE_DIRS += $(shell brew --prefix)/include
83 # LIBRARY_DIRS += $(shell brew --prefix)/lib
84
85 # Uncomment to use `pkg-config` to specify OpenCV library paths.
86 # (Usually not necessary -- OpenCV libraries are normally installed in one of the above $LIBRARY_DIRS.)
87 # USE_PKG_CONFIG := 1
88
89 BUILD_DIR := build
90 DISTRIBUTE_DIR := distribute
91
92 # Uncomment for debugging. Does not work on OSX due to https://github.com/BVLC/caffe/issues/171
93 # DEBUG := 1
94
95 # The ID of the GPU that ''make runtest'' will use to run unit tests.
96 TEST_GPUID := 0
97
98 # enable pretty build (comment to see full commands)
99 Q ?= @2. 在caffe目录下执行以下操作：
1 mkdir build && cd build3. 编译caffe
如果要开启matlab接口，先修改caffe根目录下的CMakeList.txt文件line24：
1 caffe_option(BUILD_matlab "Build Matlab wrapper" OFF IF UNIX OR APPLE)修改为：
1 caffe_option(BUILD_matlab "Build Matlab wrapper" ON IF UNIX OR APPLE)否则在caffe/build路径下直接进行以下操作：
1 cmake -DUSE_MPI=ON -DMPI_CXX_COMPILER=/path/to/your/openmpi/bin/mpicxx ..
2 # USE_MPI=ON即表示开启Open MPI
3 # -DMPI_CXX_COMPILER后的路径一定得是Open MPI的安装路径下的bin中的mpicxx路径，在/usr/bin下也有这个mpicxx，不要错写路径了4. 安装caffe，在caffe根目录下执行以下操作：
1 make all -j8
2 make install
3 # 我在安装过程中，make all之后就不需要再make install
4 make runtest
5 # 同参考教程中一样，有两个test未通过5. 编译Python接口：
a. 添加环境变量：
1 gedit ~/.bashrcb. 在其中写入：
1 export PYTHONPATH=$PYTHONPATH:/path/to/your/caffe/pythonc. 使环境变量生效：
1 source ~/.bashrcd. 在caffe根目录下：
1 make pycaffe
2 # 教程中有加sudo，但是我没有加sudo也没有影响e. 测试Python接口，在终端输入以下命令：
1 python
2 import caffe
3 # 如果无错，则python接口编译成功
出现问题：
1. 安装caffe过程中，编译caffe时，输入以下命令出错：
1 cmake -DUSE_MPI=ON -DMPI_CXX_COMPILER=/path/to/your/openmpi/bin/mpicxx ..问题1：
1 CMake Warning at /usr/local/opencv-3.1.0/cmake/OpenCVConfig.cmake:166 (message):
2 Found OpenCV Windows Pack but it has no binaries compatible with your
3 configuration.
4
5 You should manually point CMake variable OpenCV_DIR to your build of OpenCV
6 library.
7 Call Stack (most recent call first):
8 cmake/Dependencies.cmake:62 (find_package)
9 CMakeLists.txt:31 (include)
10
11
12 CMake Error at cmake/Dependencies.cmake:62 (find_package):
13 Found package configuration file:
14
15 /usr/local/opencv-3.1.0/cmake/OpenCVConfig.cmake
16
17 but it set OpenCV_FOUND to FALSE so package "OpenCV" is considered to be
18 NOT FOUND.
19 Call Stack (most recent call first):
20 CMakeLists.txt:31 (include)
21
22
23 -- Configuring incomplete, errors occurred!
24 See also "/storage/student5/usr/local/caffe/build/CMakeFiles/CMakeOutput.log".
25 See also "/storage/student5/usr/local/caffe/build/CMakeFiles/CMakeError.log".解决方法：
尝试一：在CMakeList.txt文件中加入set(OpenCV_DIR /path/to/your/OpenCV/build)，该法无效；
尝试二：退回到caffe根目录，然后make clean，暂时加入如下环境变量后重新从mkdir build && cd build开始，该法有效。
1 export OpenCV_DIR=/path/to/your/opencv/build问题2：
1 CMake Error at /usr/share/cmake/Modules/FindPackageHandleStandardArgs.cmake:108 (message):
2 Could NOT find Atlas (missing: Atlas_LAPACK_LIBRARY)
3 Call Stack (most recent call first):
4 /usr/share/cmake/Modules/FindPackageHandleStandardArgs.cmake:315 (_FPHSA_FAILURE_MESSAGE)
5 cmake/Modules/FindAtlas.cmake:43 (find_package_handle_standard_args)
6 cmake/Dependencies.cmake:74 (find_package)
7 CMakeLists.txt:31 (include)解决方法：
尝试一：指定Atlas路径，退回到caffe根目录，然后make clean，暂时加入环境变量export Atlas_ROOT_DIR=/your/Atlas/Root，再重新从mkdir build && cd build开始，该法无效；
尝试二：退回到caffe根目录，然后make clean，重新mkdir build && cd build开始，在终端输入以下命令后继续进行，该法有效。
1 cmake -DBLAS=open .
2. 当make all -j8时，
问题1：
1 /usr/bin/ld: .build_release/examples/cpp_classification/classification.o: undefined reference to symbol ''_ZN2cv6imreadERKNS_6StringEi''
2 /usr/local/lib/libopencv_imgcodecs.so.3.1: error adding symbols: DSO missing from command line
3 collect2: error: ld returned 1 exit status
4 make: *** [.build_release/examples/cpp_classification/classification.bin] Error 1
5 make: *** Waiting for unfinished jobs....解决方法：由于使用的是opencv-3.x，需要链接libopencv_imgcodercs.so，在Makefile文件中，line172处做如下修改：
1 LIBRARIES += glog gflags protobuf leveldb snappy \
2 lmdb boost_system hdf5_hl hdf5 m \
3 opencv_core opencv_highgui opencv_imgproc改为：
1 LIBRARIES += glog gflags protobuf leveldb snappy \
2 lmdb boost_system hdf5_hl hdf5 m \
3 opencv_core opencv_highgui opencv_imgproc opencv_imgcodecs问题2：
1 nvcc warning : The ''compute_20'', ''sm_20'', and ''sm_21'' architectures are deprecated, and may be
2 removed in a future release (Use -Wno-deprecated-gpu-targets to suppress warning).解决方法：删除Makefile.config中的以下语句：
1 -gencode arch=compute_20,code=sm_20 \
2 -gencode arch=compute_20,code=sm_21 \
参考教程：
1. https://blog.csdn.net/whyerdiku/article/details/78842498 （Python+Matlab接口）
2. http://www.cnblogs.com/beihaidao/p/6866342.html （Python+Matlab接口）
3. https://blog.csdn.net/qq_21368481/article/details/81257265?tdsourcetag=s_pctim_aiomsg （Matlab接口）
c – Caffe：opencv错误
我也在使用python3,现在我去安装和构建caffe.由于拥有AMD GPU和Anaconda,我在Makefile.config中设置了一些变量,因为我正在使用cpu.
当我运行make all时,我收到此错误：
$make all CXX/LD -o .build_release/examples/cpp_classification/classification.bin /usr/bin/ld: .build_release/examples/cpp_classification/classification.o: undefined reference to symbol '_ZN2cv6imreadERKNS_6StringEi' //usr/local/lib/libopencv_imgcodecs.so.3.0: error adding symbols: DSO missing from command line collect2: error: ld returned 1 exit status Makefile:565: recipe for target '.build_release/examples/cpp_classification/classification.bin' Failed make: *** [.build_release/examples/cpp_classification/classification.bin] Error 1
从搜索我认为这与使用openCV 3有关,但我不知道从哪里开始寻找解决方案.有帮助吗？
是的,我是那些希望摆弄Google Inception学习技术的无经验用户之一.
解决方法
c – 没有lmdb的Caffe Opencv
为了澄清我正在寻找能够处理大量无法融入内存的图像的解决方案(但假设一个训练批次(包含例如50个图像)可以存储在内存中).
解决方法
一些可用的输入方法是：
>数据
> MemoryData
> HDF5Data
> ImageData等
在模型文件中,您找到的第一个层将是Layer type：Data,它使用lmdb或leveldb作为输入方法.将一组图像转换为这些数据库非常容易,因为Caffe已经提供了转换图像的工具.
Layer类型：MemoryData直接从内存中读取数据,这在使用摄像机输入在测试阶段作为Caffe输入传递时非常有用.强烈建议不要使用此层进行培训.
图层类型：ImageData将文本文件作为输入.文本文件包含所有图像名称及其完整路径和类号. Caffe使用OpenCV来读取该层中的图像.它还负责图像的所有转换.因此,不建议使用OpenCV读取图像然后传递给MemoryData层,而是使用ImageData.
ImageData图层从中读取图像的.txt格式必须是：
/path/to/the/image/imageName.jpg classNumber
强烈建议使用LMDB或LevelDB,因为如果图像路径或名称包含空格,或者任何图像损坏,则ImageData无法正常工作.
各种层的细节可以在here中找到.
内存在GPU中分配,具体取决于型号和批量大小.如果发生内存溢出,您可以尝试减小批量大小. Caffe轻松处理了120万张图像的Imagenet数据库.因此,使用最佳批量大小,算法应该没有任何问题.
caffe 以及caffe2 安装时portobuf库相关的编译问题
安装caffe出现protobuf版本问题，是由于anaconda安装了不同的protobuf版本
pip show protoc
protoc --version
sudo apt-get install libprotobuf-dev libleveldb-dev libsnappy-dev libopencv-dev libhdf5-serial-dev protobuf-compiler
sudo apt-get install --no-install-recommends libboost-all-dev
sudo apt-get install python-protobuf
出现icu相关的问题，重新编译安装
http://www.linuxfromscratch.o...
protobuf自己编译时出现a local symbol'' can not be used when making a shared object; recompile with -fPIC错误
问题原因
是用了protobuf默认的安装方式(以下代码)，如此生成的静态库libprotobuf.a不是PIC object，所以不能被其它库使用（64位的so必须使用-fPIC编译选项，所以要求所链接的静态库也必须是-fPIC编译)。
./autogen.sh
./configure --prefix=INSTALL_PTAH
./make
./make install解决方法
confiure步骤时加上两个变量参数：
./configure CFLAGS="-fPIC" CXXFLAGS="-fPIC --prefix=INSTALL_PATH注意重新配置后需要make clean 清除一下原有的生成文件才有用
编译caffe2出现from google.protobuf import symbol_database as _symbol_database错误
问题原因
编译的protobuf没有安装到python环境中
解决方法
按照上述方法下再protobuf3.5.0版本后重新安装
cd PROTOBUF_PATH/python
python setup.py build
sudo python setup.py isntall编译caffe2出现以下问题
../lib/libgtest.a(gtest-all.cc.o)：在函数‘testing::internal::FormatDeathTestOutput(std::string const&)’中：
gtest-all.cc:(.text+0xca9)：对‘std::__throw_out_of_range_fmt(char const*, ...)’未定义的引用
gtest-all.cc:(.text+0xce3)：对‘std::__throw_out_of_range_fmt(char const*, ...)’未定义的引用
../lib/libgtest.a(gtest-all.cc.o)：在函数‘testing::TestResult::GetTestPartResult(int) const’中：
gtest-all.cc:(.text+0x1faf)：对‘std::__throw_out_of_range_fmt(char const*, ...)’未定义的引用
../lib/libgtest.a(gtest-all.cc.o)：在函数‘testing::TestResult::GetTestProperty(int) const’中：
gtest-all.cc:(.text+0x230f)：对‘std::__throw_out_of_range_fmt(char const*, ...)’未定义的引用
../lib/libgtest.a(gtest-all.cc.o)：在函数‘testing::internal::UnitTestImpl::ConfigureStreamingOutput()’中：
gtest-all.cc:(.text+0x1bffe)：对‘std::__throw_out_of_range_fmt(char const*, ...)’未定义的引用
../lib/libgtest.a(gtest-all.cc.o):gtest-all.cc:(.text+0x1d2d7): 跟着更多未定义的参考到 std::__throw_out_of_range_fmt(char const*, ...)
../lib/libcaffe2.so：对‘std::thread::_M_start_thread(std::shared_ptr<std::thread::_Impl_base>, void (*)())’未定义的引用
../lib/libcaffe2.so：对‘__cxa_throw_bad_array_new_length’未定义的引用
问题原因
ubuntu14.0默认的gcc g++版本是4.8 需要升级到4.9
sudo add-apt-repository ppa:ubuntu-toolchain-r/test
sudo apt-get update
sudo apt-get install gcc-4.9 g++-4.9为Cmake 指定gcc g++版本
方法1：修改环境变量
修改环境变量，但是但是不一定都有用
export CC=/usr/local/bin/gcc-4.9
export CXX=/usr/local/bin/g++-4.9
方法2： 命令行设置cmake参数
cmake -D CMAKE_C_COMPILER=/usr/local/bin/gcc-4.9 -D CMAKE_CXX_COMPILER=/usr/local/bin/g++-4.9 ..
方法3:在CMakeList中设置变量
set(CMAKE_C_COMPILER "/usr/local/bin/gcc-4.9")
set(CMAKE_CXX_COMPILER "/usr/local/bin/g++-4.9")
判断caffe2是否安装成功，正常情况打印Success
cd ~ && python -c ''from caffe2.python import core'' 2>/dev/null && echo "Success" || echo "Failure"
判断GPU是否正常，正常情况打印值为1
python2 -c ''from caffe2.python import workspace; print(workspace.NumCudaDevices())''
自编译protobuf>=3.2.0
# CAFFE2=/path/to/caffe2
cd $CAFFE2/third_party/protobuf/cmake
mkdir -p build && cd build
cmake .. \
-DCMAKE_INSTALL_PREFIX=$HOME/c2_tp_protobuf \
-Dprotobuf_BUILD_TESTS=OFF \
-DCMAKE_CXX_FLAGS="-fPIC"
make install编译caffe2时调用
cmake .. \
# insert your Caffe2 CMake flags here
-DPROTOBUF_PROTOC_EXECUTABLE=$HOME/c2_tp_protobuf/bin/protoc \
-DPROTOBUF_INCLUDE_DIR=$HOME/c2_tp_protobuf/include \
-DPROTOBUF_LIBRARY=$HOME/c2_tp_protobuf/lib64/libprotobuf.a安装mxnet时出现libgfortran.so.1找不到的问题
ImportError: libgfortran.so.1: cannot open shared object file: No such file or directory
解决方法
conda install libgfortran=1conda 可以指定安装版本
caffe 安装编译问题 - ImportError: libopencv_core.so.3.4: cannot open shared object file: No such file or d...
问题描述
>>> import caffe
Traceback (most recent call last):
File "<stdin>", line 1, in <module>
File "/home/xxx/Downloads/caffe/python/caffe/__init__.py", line 1, in <module>
from .pycaffe import Net, SGDSolver, NesterovSolver, AdaGradSolver, RMSPropSolver, AdaDeltaSolver, AdamSolver, NCCL, Timer
File "/home/xxx/Downloads/caffe/python/caffe/pycaffe.py", line 13, in <module>
from ._caffe import Net, SGDSolver, NesterovSolver, AdaGradSolver, \
ImportError: libopencv_core.so.3.4: cannot open shared object file: No such file or directory问题原因
一种是系统中本身不存在该文件，这个需要自行查找；一种是系统存在该文件，只是系统不知道，可使用以下方法试试；
尝试方法
~/Downloads/caffe$ sudo ldconfig使用以上方法问题还是没有解决；
参考
1.ImportError: libopencv_core.so.3.1: cannot open shared object file: No such file or directory；
完
我们今天的关于编译分布式并行版caffe和Open MPI教程的分享就到这里，谢谢您的阅读，如果想了解更多关于c – Caffe：opencv错误、c – 没有lmdb的Caffe Opencv、caffe 以及caffe2 安装时portobuf库相关的编译问题、caffe 安装编译问题 - ImportError: libopencv_core.so.3.4: cannot open shared object file: No such file or d...的相关信息，可以在本站进行搜索。
本文标签：
![[转帖]Ubuntu 安装 Wine方法（ubuntu如何安装wine）](https://www.gvkun.com/zb_users/cache/thumbs/4c83df0e2303284d68480d1b1378581d-180-120-1.jpg)
