通过SSL / TLS下载Apache CXF wsdl

通过SSL / TLS下载Apache CXF wsdl

我有一个在运行的cxf服务

https://localhost:8443/services/MyService?wsdl

带有客户证书。WSDL在这里并不重要。

删除客户端证书或https要求时，我可以调用该服务。

服务和客户端类是使用cxf wsdl2java实用程序生成的。

这是MyService.class：

package com.mycompany;

import java.net.URL;
import java.util.logging.Level;
import java.util.logging.Logger;

import javax.xml.namespace.QName;
import javax.xml.ws.Service;
import javax.xml.ws.WebEndpoint;
import javax.xml.ws.WebServiceClient;
import javax.xml.ws.WebServiceFeature;

/**
 * This class was generated by Apache CXF 2.7.3 2013-03-29T13:59:37.423-03:00 Generated source version: 2.7.3
 */
@WebServiceClient(name = "MyService",wsdlLocation = "myservice.wsdl",targetNamespace = "http://server/schemas/services")
public class MyService extends Service {

    public final static URL WSDL_LOCATION;

    public final static QName SERVICE = new QName("http://server/schemas/services","MyService");
    public final static QName MyServicePort = new QName("http://server/schemas/services","MyServicePort");
    static {
        URL url = MyService.class.getResource("myservice.wsdl");
        if (url == null) {
            Logger.getLogger(MyService.class.getName()).log(Level.INFO,"Can not initialize the default wsdl from {0}","myservice.wsdl");
        }
        WSDL_LOCATION = url;
    }

    public MyService(URL wsdlLocation) {
        super(wsdlLocation,SERVICE);
    }

    public MyService(URL wsdlLocation,QName serviceName) {
        super(wsdlLocation,serviceName);
    }

    public MyService() {
        super(WSDL_LOCATION,SERVICE);
    }

    /**
     *
     * @return returns EncaminharMensagemPortType
     */
    @WebEndpoint(name = "MyServicePort")
    public MyServicePortType getMyServicePort() {
        return super.getPort(MyServicePort,MyServicePortType.class);
    }

    /**
     *
     * @param features
     *            A list of {@link javax.xml.ws.WebServiceFeature} to configure on the proxy. Supported features not in the
     *            <code>features</code> parameter will have their default values.
     * @return returns EncaminharMensagemPortType
     */
    @WebEndpoint(name = "MyServicePort")
    public MyServicePortType getMyServicePort(WebServiceFeature... features) {
        return super.getPort(MyServicePort,MyServicePortType.class,features);
    }

}

这是我的没有客户证书要求的客户：（工作正常）

package com.mycompany;

import java.net.URL;

import javax.xml.namespace.QName;

import com.mycompany.IdHolder;
import com.mycompany.MyDataObject;

public class CxfClientSslTest {

    public static void main(String[] args) {
        try {

            QName SERVICE_NAME = new QName("http://server/schemas/services","MyService");
            URL wsdlURL = new URL("https://localhost:8443/services/MyService?wsdl");
            MyService ss = new MyService(wsdlURL,SERVICE_NAME);
            MyServicePortType port = ss.getMyServicePort();

            IdHolder mensagem = new IdHolder();
            mensagem.setId(1L);
            MyDataObject dataObject = port.getById(mensagem);

            System.out.println("Id: " + dataObject.getId());
        } catch (Exception e) {
            e.printStackTrace();
        }
    }
}

这是我的客户发送他的证书：

package com.mycompany;

import java.io.File;
import java.io.FileInputStream;
import java.io.IOException;
import java.io.InputStream;
import java.net.URL;
import java.security.KeyStore;
import java.security.KeyStoreException;
import java.security.NoSuchAlgorithmException;
import java.security.UnrecoverableKeyException;
import java.security.cert.CertificateException;

import javax.net.ssl.KeyManager;
import javax.net.ssl.KeyManagerFactory;
import javax.net.ssl.TrustManager;
import javax.net.ssl.TrustManagerFactory;
import javax.xml.namespace.QName;

import org.apache.cxf.configuration.jsse.TLSClientParameters;
import org.apache.cxf.endpoint.Client;
import org.apache.cxf.frontend.ClientProxy;
import org.apache.cxf.transport.http.HTTPConduit;

public class CxfClientSslTest {

    public static void main(String[] args) {
        try {

            QName SERVICE_NAME = new QName("http://server/schemas/services",SERVICE_NAME);
            MyServicePortType port = ss.getMyServicePort();

            tslIt(port);

            IdHolder mensagem = new IdHolder();
            mensagem.setId(1L);
            MyDataObject dataObject = port.getById(mensagem);

            System.out.println("Id: " + dataObject.getId());
        } catch (Exception e) {
            e.printStackTrace();
        }
    }

    public static void tslIt(MyServicePortType port) throws KeyStoreException,NoSuchAlgorithmException,CertificateException,IOException,UnrecoverableKeyException {
        Client client = ClientProxy.getClient(port);
        HTTPConduit http = (HTTPConduit) client.getConduit();

        TLSClientParameters tlsClientParameters = http.getTlsClientParameters();

        KeyStore keyStore = getKeyStore();
        KeyStore trustStore = getTrustStore();

        KeyManagerFactory keyManagerFactory = KeyManagerFactory.getInstance(KeyManagerFactory.getDefaultAlgorithm());
        TrustManagerFactory trustManagerFactory = TrustManagerFactory.getInstance(KeyManagerFactory.getDefaultAlgorithm());

        keyManagerFactory.init(keyStore,"123456".toCharArray());
        KeyManager[] keyMgrs = keyManagerFactory.getKeyManagers();
        tlsClientParameters.setKeyManagers(keyMgrs);

        trustManagerFactory.init(trustStore);
        TrustManager[] trustManagers = trustManagerFactory.getTrustManagers();
        tlsClientParameters.setTrustManagers(trustManagers);

        tlsClientParameters.setDisableCNCheck(true);
    }

    public static KeyStore getKeyStore() throws KeyStoreException,IOException {
        URL keyStoreUrl = CxfClientSslTest.class.getResource("/certs/client.jks");
        File keystoreFile = new File(keyStoreUrl.getPath());
        if (!keystoreFile.exists()) {
            throw new RuntimeException("keystore doesn't exists: " + keystoreFile.getAbsolutePath());
        }

        KeyStore keystore = KeyStore.getInstance(KeyStore.getDefaultType());
        InputStream keystoreInput = new FileInputStream(keystoreFile.getAbsolutePath());
        keystore.load(keystoreInput,"changeit".toCharArray());
        keystoreInput.close();
        return keystore;
    }

    public static KeyStore getTrustStore() throws KeyStoreException,IOException {
        URL trustStoreUrl = CxfClientSslTest.class.getResource("/certs/client-trust.jks");
        File trustStoreFile = new File(trustStoreUrl.getPath());
        if (!trustStoreFile.exists()) {
            throw new RuntimeException("truststore doesn't exists: " + trustStoreFile.getAbsolutePath());
        }

        KeyStore trustStore = KeyStore.getInstance(KeyStore.getDefaultType());
        InputStream trustStoreInput = new FileInputStream(trustStoreFile.getAbsolutePath());
        trustStore.load(trustStoreInput,"changeit".toCharArray());
        trustStoreInput.close();
        return trustStore;
    }

}

已检查来自客户端和服务器的TLS配置，并且都可以。但是当我运行程序时，我得到了：

Information: Can not initialize the default wsdl from myservice.wsdl
javax.xml.ws.WebServiceException: org.apache.cxf.service.factory.ServiceConstructionException: Failed to create service.
    at org.apache.cxf.jaxws.ServiceImpl.<init>(ServiceImpl.java:149)
    at org.apache.cxf.jaxws.spi.ProviderImpl.createServiceDelegate(ProviderImpl.java:98)
    at javax.xml.ws.Service.<init>(Service.java:77)
    at com.mycompany.MyService.<init>(MyService.java:36)
    at com.mycompany.CxfClientSslTest.main(CxfClientSslTest.java:32)
Caused by: org.apache.cxf.service.factory.ServiceConstructionException: Failed to create service.
    at org.apache.cxf.wsdl11.WSDLServiceFactory.<init>(WSDLServiceFactory.java:100)
    at org.apache.cxf.jaxws.ServiceImpl.initializePorts(ServiceImpl.java:199)
    at org.apache.cxf.jaxws.ServiceImpl.<init>(ServiceImpl.java:147)
    ... 4 more
Caused by: javax.wsdl.WSDLException: WSDLException: faultCode=PARSER_ERROR: Problem parsing 'https://localhost:8443/services/MyService?wsdl'.: javax.net.ssl.SSLHandshakeException: java.security.cert.CertificateException: No name matching localhost found
    at com.ibm.wsdl.xml.WSDLReaderImpl.getDocument(Unknown Source)
    at com.ibm.wsdl.xml.WSDLReaderImpl.readWSDL(Unknown Source)
    at com.ibm.wsdl.xml.WSDLReaderImpl.readWSDL(Unknown Source)
    at org.apache.cxf.wsdl11.WSDLManagerImpl.loadDefinition(WSDLManagerImpl.java:262)
    at org.apache.cxf.wsdl11.WSDLManagerImpl.getDefinition(WSDLManagerImpl.java:205)
    at org.apache.cxf.wsdl11.WSDLServiceFactory.<init>(WSDLServiceFactory.java:98)
    ... 6 more
Caused by: javax.net.ssl.SSLHandshakeException: java.security.cert.CertificateException: No name matching localhost found
    at sun.security.ssl.Alerts.getSSLException(Alerts.java:192)
    at sun.security.ssl.SSLSocketImpl.fatal(SSLSocketImpl.java:1868)
    at sun.security.ssl.Handshaker.fatalSE(Handshaker.java:276)
    at sun.security.ssl.Handshaker.fatalSE(Handshaker.java:270)
    at sun.security.ssl.ClientHandshaker.serverCertificate(ClientHandshaker.java:1337)
    at sun.security.ssl.ClientHandshaker.processMessage(ClientHandshaker.java:154)
    at sun.security.ssl.Handshaker.processLoop(Handshaker.java:868)
    at sun.security.ssl.Handshaker.process_record(Handshaker.java:804)
    at sun.security.ssl.SSLSocketImpl.readRecord(SSLSocketImpl.java:998)
    at sun.security.ssl.SSLSocketImpl.performInitialHandshake(SSLSocketImpl.java:1294)
    at sun.security.ssl.SSLSocketImpl.startHandshake(SSLSocketImpl.java:1321)
    at sun.security.ssl.SSLSocketImpl.startHandshake(SSLSocketImpl.java:1305)
    at sun.net.www.protocol.https.HttpsClient.afterConnect(HttpsClient.java:523)
    at sun.net.www.protocol.https.AbstractDelegateHttpsURLConnection.connect(AbstractDelegateHttpsURLConnection.java:185)
    at sun.net.www.protocol.http.HttpURLConnection.getInputStream(HttpURLConnection.java:1296)
    at sun.net.www.protocol.https.HttpsURLConnectionImpl.getInputStream(HttpsURLConnectionImpl.java:254)
    at com.sun.org.apache.xerces.internal.impl.XMLEntityManager.setupCurrentEntity(XMLEntityManager.java:653)
    at com.sun.org.apache.xerces.internal.impl.XMLVersionDetector.determineDocVersion(XMLVersionDetector.java:189)
    at com.sun.org.apache.xerces.internal.parsers.XML11Configuration.parse(XML11Configuration.java:799)
    at com.sun.org.apache.xerces.internal.parsers.XML11Configuration.parse(XML11Configuration.java:764)
    at com.sun.org.apache.xerces.internal.parsers.XMLParser.parse(XMLParser.java:123)
    at com.sun.org.apache.xerces.internal.parsers.DOMParser.parse(DOMParser.java:240)
    at com.sun.org.apache.xerces.internal.jaxp.DocumentBuilderImpl.parse(DocumentBuilderImpl.java:300)
    ... 12 more
Caused by: java.security.cert.CertificateException: No name matching localhost found
    at sun.security.util.HostnameChecker.matchDNS(HostnameChecker.java:208)
    at sun.security.util.HostnameChecker.match(HostnameChecker.java:93)
    at sun.security.ssl.X509TrustManagerImpl.checkIdentity(X509TrustManagerImpl.java:347)
    at sun.security.ssl.X509TrustManagerImpl.checkTrusted(X509TrustManagerImpl.java:203)
    at sun.security.ssl.X509TrustManagerImpl.checkServerTrusted(X509TrustManagerImpl.java:126)
    at sun.security.ssl.ClientHandshaker.serverCertificate(ClientHandshaker.java:1319)
    ... 30 more

当cxf尝试下载wsdl时，我可以看到在我的https配置完成之前就发生了问题。

我对如何使cxf使用该https配置下载wsdl进行了研究。我花了很多时间，但我找不到答案。

所以我的问题是：如何使cxf使用https配置下载wsdl？

拜托，我已经有了答案，我打算把它放在这里。因此，如果您没有很好的答案，或者更好的答案，请不要发布。
