1 package hello;
 2
 3 import org.springframework.context.ApplicationContext;
 4 import org.springframework.context.support.ClassPathXmlApplicationContext;
 5
 6 public class HelloWorld
 7 {
 8     public static void main(String[] args) {
 9         ApplicationContext context = new ClassPathXmlApplicationContext("applicationContext.xml");
10         System.out.println(context.getBean("hello.Dog", Dog.class).name);
11         System.out.println(context.getBean("hello.Dog#0", Dog.class).name);
12     }
13 }
14
15 class Dog {
16     String name = "PiPi";
17 }

1 <?xml version="1.0" encoding="UTF-8"?>
2 <beans xmlns="http://www.springframework.org/schema/beans"
3        xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
4        xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd">
5
6     <bean class="hello.Dog"/>
7
8 </beans>

 1     /**
 2      * Parses the supplied {@code <bean>} element. May return {@code null}
 3      * if there were errors during parse. Errors are reported to the
 4      * {@link org.springframework.beans.factory.parsing.ProblemReporter}.
 5      */
 6     public BeanDefinitionHolder parseBeanDefinitionElement(Element ele, BeanDefinition containingBean) {
 7         String id = ele.getAttribute(ID_ATTRIBUTE);
 8         String nameAttr = ele.getAttribute(NAME_ATTRIBUTE);
 9
10         List<String> aliases = new ArrayList<String>();
11         if (StringUtils.hasLength(nameAttr)) {
12             String[] nameArr = StringUtils.tokenizeToStringArray(nameAttr, MULTI_VALUE_ATTRIBUTE_DELIMITERS);
13             aliases.addAll(Arrays.asList(nameArr));
14         }
15
16         String beanName = id;
17         if (!StringUtils.hasText(beanName) && !aliases.isEmpty()) {
18             beanName = aliases.remove(0);
19             if (logger.isDebugEnabled()) {
20                 logger.debug("No XML ''id'' specified - using ''" + beanName +
21                         "'' as bean name and " + aliases + " as aliases");
22             }
23         }
24
25         if (containingBean == null) {
26             checkNameUniqueness(beanName, aliases, ele);
27         }
28
29         AbstractBeanDefinition beanDefinition = parseBeanDefinitionElement(ele, beanName, containingBean);
30         if (beanDefinition != null) {
31             if (!StringUtils.hasText(beanName)) {
32                 try {
33                     if (containingBean != null) {
34                         beanName = BeanDefinitionReaderUtils.generateBeanName(
35                                 beanDefinition, this.readerContext.getRegistry(), true);
36                     }
37                     else {
38                         beanName = this.readerContext.generateBeanName(beanDefinition);  //获取到的bean名称为com.example.Hello#0这样的格式，#后面的数字为该类对象在进程中的编号。
39                         // Register an alias for the plain bean class name, if still possible,
40                         // if the generator returned the class name plus a suffix.
41                         // This is expected for Spring 1.2/2.0 backwards compatibility.
42                         String beanClassName = beanDefinition.getBeanClassName(); //获取class属性配置的bean的类名（全限定类名）
43                         if (beanClassName != null &&
44                                 beanName.startsWith(beanClassName) && beanName.length() > beanClassName.length() &&
45                                 !this.readerContext.getRegistry().isBeanNameInUse(beanClassName)) {
46                             aliases.add(beanClassName);  //使用全限定类名作为别名
47                         }
48                     }
49                     if (logger.isDebugEnabled()) {
50                         logger.debug("Neither XML ''id'' nor ''name'' specified - " +
51                                 "using generated bean name [" + beanName + "]");
52                     }
53                 }
54                 catch (Exception ex) {
55                     error(ex.getMessage(), ele);
56                     return null;
57                 }
58             }
59             String[] aliasesArray = StringUtils.toStringArray(aliases);
60             return new BeanDefinitionHolder(beanDefinition, beanName, aliasesArray);  //创建bean定义对象
61         }
62
63         return null;
64     }

/** Map of bean definition objects, keyed by bean name */
    private final Map<String, BeanDefinition> beanDefinitionMap = new ConcurrentHashMap<String, BeanDefinition>(256);

 1     //---------------------------------------------------------------------
 2     // Implementation of BeanDefinitionRegistry interface
 3     //---------------------------------------------------------------------
 4
 5     @Override
 6     public void registerBeanDefinition(String beanName, BeanDefinition beanDefinition)
 7             throws BeanDefinitionStoreException {
 8
 9         Assert.hasText(beanName, "Bean name must not be empty");
10         Assert.notNull(beanDefinition, "BeanDefinition must not be null");
11
12         if (beanDefinition instanceof AbstractBeanDefinition) {
13             try {
14                 ((AbstractBeanDefinition) beanDefinition).validate();
15             }
16             catch (BeanDefinitionValidationException ex) {
17                 throw new BeanDefinitionStoreException(beanDefinition.getResourceDescription(), beanName,
18                         "Validation of bean definition failed", ex);
19             }
20         }
21
22         BeanDefinition existingDefinition = this.beanDefinitionMap.get(beanName);
23         if (existingDefinition != null) {
24             if (!isAllowBeanDefinitionOverriding()) {
25                 throw new BeanDefinitionStoreException(beanDefinition.getResourceDescription(), beanName,
26                         "Cannot register bean definition [" + beanDefinition + "] for bean ''" + beanName +
27                         "'': There is already [" + existingDefinition + "] bound.");
28             }
29             else if (existingDefinition.getRole() < beanDefinition.getRole()) {
30                 // e.g. was ROLE_APPLICATION, now overriding with ROLE_SUPPORT or ROLE_INFRASTRUCTURE
31                 if (logger.isWarnEnabled()) {
32                     logger.warn("Overriding user-defined bean definition for bean ''" + beanName +
33                             "'' with a framework-generated bean definition: replacing [" +
34                             existingDefinition + "] with [" + beanDefinition + "]");
35                 }
36             }
37             else if (!beanDefinition.equals(existingDefinition)) {
38                 if (logger.isInfoEnabled()) {
39                     logger.info("Overriding bean definition for bean ''" + beanName +
40                             "'' with a different definition: replacing [" + existingDefinition +
41                             "] with [" + beanDefinition + "]");
42                 }
43             }
44             else {
45                 if (logger.isDebugEnabled()) {
46                     logger.debug("Overriding bean definition for bean ''" + beanName +
47                             "'' with an equivalent definition: replacing [" + existingDefinition +
48                             "] with [" + beanDefinition + "]");
49                 }
50             }
51             this.beanDefinitionMap.put(beanName, beanDefinition);
52         }
53         else {
54             if (hasBeanCreationStarted()) {
55                 // Cannot modify startup-time collection elements anymore (for stable iteration)
56                 synchronized (this.beanDefinitionMap) {
57                     this.beanDefinitionMap.put(beanName, beanDefinition);
58                     List<String> updatedDefinitions = new ArrayList<String>(this.beanDefinitionNames.size() + 1);
59                     updatedDefinitions.addAll(this.beanDefinitionNames);
60                     updatedDefinitions.add(beanName);
61                     this.beanDefinitionNames = updatedDefinitions;
62                     if (this.manualSingletonNames.contains(beanName)) {
63                         Set<String> updatedSingletons = new LinkedHashSet<String>(this.manualSingletonNames);
64                         updatedSingletons.remove(beanName);
65                         this.manualSingletonNames = updatedSingletons;
66                     }
67                 }
68             }
69             else {
70                 // Still in startup registration phase
71                 this.beanDefinitionMap.put(beanName, beanDefinition);
72                 this.beanDefinitionNames.add(beanName);
73                 this.manualSingletonNames.remove(beanName);
74             }
75             this.frozenBeanDefinitionNames = null;
76         }
77
78         if (existingDefinition != null || containsSingleton(beanName)) {
79             resetBeanDefinition(beanName);
80         }
81     }

A {
   @Autowired
   private IB b;
}

第一步: 配置类. 配置类可以使用的方式通常由
      1) xml配置
      2) 注解配置
      3) javaconfig方式配置
第二步: 加载spring上下文
      1) 如果是xml,则new ClasspathXmlApplicationContext("xml");
      2) 如果是注解配置: 则new AnnotationConfigApplicationContext(config.class)

第三步: getBean()
我们会讲自定义的类,通过xml或者注解的方式注入到ioc容器中.

public static void main( String[] args ) {
        AnnotationConfigApplicationContext context = new AnnotationConfigApplicationContext();
        context.getBean("***");
    }

首先,通过ClasspathXmlApplicationContext或者AnnotationConfigApplicationContext去读取配置,然后将其交给beanfactory.

第三. beanfactory调用getBean()方法,将Bean注入到IoC容器中

BeanDeFinitionReader对应的就去读取配置类,看看有哪些需求需要搞装修.


它本身也是一个抽象类,可以看到他有AnnotationBeanDeFinitionReader和XmlBeanDeFinitionReader


我们配置了配置包,去扫描这个包下所有的类,然后将扫描到的所有的类交给BeanDeFinitionScanner,它会去过滤带有@Component的类.

第一步: 实例化. bean实例化的时候从BeanDeFinition中得到Bean的名字,然后通过反射机制,将Bean实例化. 实例化以后,这是还只是个壳子,里面什么都没有.

第二步: 填充属性. 经过初始化以后,bean的壳子就有了,bean里面有哪些属性呢? 在这一步填充


第三步: 初始化. 初始化的时候,会调用initMethod()初始化方法,destory()初始化结束方法

这个时候,类就被构造好了.

第四步: 构造好了的类,会被放到IoC的一个Map中. Map的key是beanName,value是bean实例. 这个Map是一个单例池,也就是我们说的一级缓存


第五步: 我们就可以通过getBean("user"),从单例池中获取雷鸣是user的类了.

public class DefinedPost implements beanfactoryPostProcessor {

    /**
     * 重写Bean工厂的后置处理器
     * @param beanfactory
     * @throws BeansException
     */
    @Override
    public void postProcessbeanfactory(ConfigurableListablebeanfactory beanfactory) throws BeansException {
        // beanfactory 拿到工厂了,就可以获取某一个Bean定义了
        GenericBeanDeFinition car = (GenericBeanDeFinition) beanfactory.getBeanDeFinition("Car");
        // 拿到了car,然后修改了Car的类名为com.example.tulingcourse.Tank. 那么后面在获取的Bean里面,将其转换为Car,就会报错了
        car.setBeanClassName("com.example.tulingcourse.Tank");
    }
}

public static void main(String[] args) {


        AnnotationConfigApplicationContext context = new AnnotationConfigApplicationContext(Application.class);
　　　　
        Car car = context.getBean("car",Car.class); // 这里会报错,因为已经被修改
        System.out.println(car.getName());
    }

public class DefinedPost implements BeanDeFinitionRegistryPostProcessor {

    /**
     * 重写Bean工厂的后置处理器
     * @param beanfactory
     * @throws BeansException
     */
    @Override
    public void postProcessbeanfactory(ConfigurableListablebeanfactory beanfactory) throws BeansException {
        // beanfactory 拿到工厂了,就可以获取某一个Bean定义了
        GenericBeanDeFinition car = (GenericBeanDeFinition) beanfactory.getBeanDeFinition("Car");
        // 拿到了car,就会报错了
        car.setBeanClassName("com.example.tulingcourse.Tank");
    }

    @Override
    public void postProcessBeanDeFinitionRegistry(BeanDeFinitionRegistry beanDeFinitionRegistry) throws BeansException {

    }
}

  @Override
    public Object getBean(String name) throws BeansException {
        return doGetBean(name,null,false);
    }

    @Override
    public <T> T getBean(String name,Class<T> requiredType) throws BeansException {
        return doGetBean(name,requiredType,false);
    }

    @Override
    public Object getBean(String name,Object... args) throws BeansException {
        return doGetBean(name,args,false);
    }

    public <T> T getBean(String name,Class<T> requiredType,false);
    }

protected <T> T doGetBean(
      final String name,final Class<T> requiredType,final Object[] args,boolean typeCheckOnly)
      throws BeansException {
   //筛选出null，&符号的代表自身
   final String beanName = transformedBeanName(name);
   Object bean;

   // 先获取从单例缓存中获取单例的bean，无需再进行实例化去创建了
   Object sharedInstance = getSingleton(beanName);
   if (sharedInstance != null && args == null) {
      if (logger.isDebugEnabled()) {
         if (isSingletonCurrentlyInCreation(beanName)) {
            logger.debug("Returning eagerly cached instance of singleton bean '" + beanName +
                  "' that is not fully initialized yet - a consequence of a circular reference");
         }
         else {
            logger.debug("Returning cached instance of singleton bean '" + beanName + "'");
         }
      }
      // 是factorybean情况
      bean = getobjectForBeanInstance(sharedInstance,name,beanName,null);
   }

   else {
      // Fail if we're already creating this bean instance:
      // We're assumably within a circular reference.
      if (isPrototypeCurrentlyInCreation(beanName)) {
         throw new BeanCurrentlyInCreationException(beanName);
      }

      // Check if bean deFinition exists in this factory.
      beanfactory parentbeanfactory = getParentbeanfactory();
      if (parentbeanfactory != null && !containsBeanDeFinition(beanName)) {
         // Not found -> check parent.
         String nametoLookup = originalBeanName(name);
         if (args != null) {
            // Delegation to parent with explicit args.
            return (T) parentbeanfactory.getBean(nametoLookup,args);
         }
         else {
            // No args -> delegate to standard getBean method.
            return parentbeanfactory.getBean(nametoLookup,requiredType);
         }
      }

      if (!typeCheckOnly) {
         markBeanAsCreated(beanName);
      }

      try {
         final RootBeanDeFinition mbd = getMergedLocalBeanDeFinition(beanName);
         checkMergedBeanDeFinition(mbd,args);

         // 获取这个bean依赖的对象，进入for循环迭代调用getBean方法，开始织网
         String[] dependsOn = mbd.getDependsOn();
         if (dependsOn != null) {
            for (String dependsOnBean : dependsOn) {
               if (isDependent(beanName,dependsOnBean)) {
                  throw new BeanCreationException(mbd.getResourceDescription(),"Circular depends-on relationship between '" + beanName + "' and '" + dependsOnBean + "'");
               }
               registerDependentBean(dependsOnBean,beanName);
               // 迭代
               getBean(dependsOnBean);
            }
         }

         // 最终创建bean
         // 单例
         if (mbd.isSingleton()) {
            sharedInstance = getSingleton(beanName,new ObjectFactory<Object>() {
               @Override
               public Object getobject() throws BeansException {
                  try {
                     return createBean(beanName,mbd,args);
                  }
                  catch (BeansException ex) {
                     // Explicitly remove instance from singleton cache: It might have been put there
                     // eagerly by the creation process,to allow for circular reference resolution.
                     // Also remove any beans that received a temporary reference to the bean.
                     destroySingleton(beanName);
                     throw ex;
                  }
               }
            });
            bean = getobjectForBeanInstance(sharedInstance,mbd);
         }
        // 多例
         else if (mbd.isPrototype()) {
            // It's a prototype -> create a new instance.
            Object prototypeInstance = null;
            try {
               beforePrototypeCreation(beanName);
               prototypeInstance = createBean(beanName,args);
            }
            finally {
               afterPrototypeCreation(beanName);
            }
            bean = getobjectForBeanInstance(prototypeInstance,mbd);
         }
        // 自定义配置的scop
         else {
            String scopeName = mbd.getScope();
            final Scope scope = this.scopes.get(scopeName);
            if (scope == null) {
               throw new IllegalStateException("No Scope registered for scope name '" + scopeName + "'");
            }
            try {
               Object scopedInstance = scope.get(beanName,new ObjectFactory<Object>() {
                  @Override
                  public Object getobject() throws BeansException {
                     beforePrototypeCreation(beanName);
                     try {
                        return createBean(beanName,args);
                     }
                     finally {
                        afterPrototypeCreation(beanName);
                     }
                  }
               });
               bean = getobjectForBeanInstance(scopedInstance,mbd);
            }
            catch (IllegalStateException ex) {
               throw new BeanCreationException(beanName,"Scope '" + scopeName + "' is not active for the current thread; consider " +
                     "defining a scoped proxy for this bean if you intend to refer to it from a singleton",ex);
            }
         }
      }
      catch (BeansException ex) {
         cleanupAfterBeanCreationFailure(beanName);
         throw ex;
      }
   }

   // Check if required type matches the type of the actual bean instance.
   if (requiredType != null && bean != null && !requiredType.isAssignableFrom(bean.getClass())) {
      try {
         return getTypeConverter().convertIfNecessary(bean,requiredType);
      }
      catch (TypeMismatchException ex) {
         if (logger.isDebugEnabled()) {
            logger.debug("Failed to convert bean '" + name + "' to required type [" +
                  ClassUtils.getQualifiedname(requiredType) + "]",ex);
         }
         throw new BeanNotOfrequiredTypeException(name,bean.getClass());
      }
   }
   return (T) bean;
}

protected Object createBean(String beanName,RootBeanDeFinition mbd,Object[] args) throws BeanCreationException {
   if (logger.isDebugEnabled()) {
      logger.debug("Creating instance of bean '" + beanName + "'");
   }
   RootBeanDeFinition mbdToUse = mbd;

   // Make sure bean class is actually resolved at this point,and
   // clone the bean deFinition in case of a dynamically resolved Class
   // which cannot be stored in the shared merged bean deFinition.
   Class<?> resolvedClass = resolveBeanClass(mbd,beanName);
   if (resolvedClass != null && !mbd.hasBeanClass() && mbd.getBeanClassName() != null) {
      mbdToUse = new RootBeanDeFinition(mbd);
      mbdToUse.setBeanClass(resolvedClass);
   }

   // Prepare method overrides.
   try {
      mbdToUse.prepareMethodoverrides();
   }
   catch (BeanDeFinitionValidationException ex) {
      throw new BeanDeFinitionStoreException(mbdToUse.getResourceDescription(),"Validation of method overrides Failed",ex);
   }

   try {
      // Give BeanPostProcessors a chance to return a proxy instead of the target bean instance.
      Object bean = resolveBeforeInstantiation(beanName,mbdToUse);
      if (bean != null) {
         return bean;
      }
   }
   catch (Throwable ex) {
      throw new BeanCreationException(mbdToUse.getResourceDescription(),"BeanPostProcessor before instantiation of bean Failed",ex);
   }

   Object beanInstance = doCreateBean(beanName,mbdToUse,args);
   if (logger.isDebugEnabled()) {
      logger.debug("Finished creating instance of bean '" + beanName + "'");
   }
   return beanInstance;
}
protected Object doCreateBean(final String beanName,final RootBeanDeFinition mbd,final Object[] args) {
        // Instantiate the bean.
        BeanWrapper instanceWrapper = null;
        if (mbd.isSingleton()) {
            instanceWrapper = this.factorybeanInstanceCache.remove(beanName);
        }
        if (instanceWrapper == null) {
            instanceWrapper = createBeanInstance(beanName,args);
        }
        final Object bean = (instanceWrapper != null ? instanceWrapper.getWrappedInstance() : null);
        Class<?> beanType = (instanceWrapper != null ? instanceWrapper.getWrappedClass() : null);

        // Allow post-processors to modify the merged bean deFinition.
        synchronized (mbd.postProcessingLock) {
            if (!mbd.postProcessed) {
                applyMergedBeanDeFinitionPostProcessors(mbd,beanType,beanName);
                mbd.postProcessed = true;
            }
        }

        // Eagerly cache singletons to be able to resolve circular references
        // even when triggered by lifecycle interfaces like beanfactoryAware.
        boolean earlySingletonExposure = (mbd.isSingleton() && this.allowCircularReferences &&
                isSingletonCurrentlyInCreation(beanName));
        if (earlySingletonExposure) {
            if (logger.isDebugEnabled()) {
                logger.debug("Eagerly caching bean '" + beanName +
                        "' to allow for resolving potential circular references");
            }
            addSingletonFactory(beanName,new ObjectFactory<Object>() {
                @Override
                public Object getobject() throws BeansException {
                    return getEarlyBeanReference(beanName,bean);
                }
            });
        }

        // Initialize the bean instance.
        Object exposedobject = bean;
        try {
            populateBean(beanName,instanceWrapper);
            if (exposedobject != null) {
                exposedobject = initializeBean(beanName,exposedobject,mbd);
            }
        }
        catch (Throwable ex) {
            if (ex instanceof BeanCreationException && beanName.equals(((BeanCreationException) ex).getBeanName())) {
                throw (BeanCreationException) ex;
            }
            else {
                throw new BeanCreationException(mbd.getResourceDescription(),"Initialization of bean Failed",ex);
            }
        }

        if (earlySingletonExposure) {
            Object earlySingletonReference = getSingleton(beanName,false);
            if (earlySingletonReference != null) {
                if (exposedobject == bean) {
                    exposedobject = earlySingletonReference;
                }
                else if (!this.allowRawInjectionDespiteWrapping && hasDependentBean(beanName)) {
                    String[] dependentBeans = getDependentBeans(beanName);
                    Set<String> actualDependentBeans = new LinkedHashSet<String>(dependentBeans.length);
                    for (String dependentBean : dependentBeans) {
                        if (!removeSingletonIfCreatedForTypeCheckOnly(dependentBean)) {
                            actualDependentBeans.add(dependentBean);
                        }
                    }
                    if (!actualDependentBeans.isEmpty()) {
                        throw new BeanCurrentlyInCreationException(beanName,"Bean with name '" + beanName + "' has been injected into other beans [" +
                                StringUtils.collectionToCommaDelimitedString(actualDependentBeans) +
                                "] in its raw version as part of a circular reference,but has eventually been " +
                                "wrapped. This means that said other beans do not use the final version of the " +
                                "bean. This is often the result of over-eager type matching - consider using " +
                                "'getBeanNamesOfType' with the 'allowEagerInit' flag turned off,for example.");
                    }
                }
            }
        }

        // Register bean as disposable.
        try {
            registerdisposableBeanIfNecessary(beanName,bean,mbd);
        }
        catch (BeanDeFinitionValidationException ex) {
            throw new BeanCreationException(mbd.getResourceDescription(),"Invalid destruction signature",ex);
        }

        return exposedobject;
    }

protected BeanWrapper createBeanInstance(String beanName,Object[] args) {
        // Make sure bean class is actually resolved at this point.
        Class<?> beanClass = resolveBeanClass(mbd,beanName);

        if (beanClass != null && !Modifier.isPublic(beanClass.getModifiers()) && !mbd.isNonPublicAccessAllowed()) {
            throw new BeanCreationException(mbd.getResourceDescription(),"Bean class isn't public,and non-public access not allowed: " + beanClass.getName());
        }
    // 工厂方法创建bean
        if (mbd.getFactoryMethodName() != null)  {
            return instantiateUsingFactoryMethod(beanName,args);
        }

        // Shortcut when re-creating the same bean...
        boolean resolved = false;
        boolean autowireNecessary = false;
        if (args == null) {
            synchronized (mbd.constructorargumentLock) {
                if (mbd.resolvedConstructorOrFactoryMethod != null) {
                    resolved = true;
                    autowireNecessary = mbd.constructorargumentsResolved;
                }
            }
        }
        if (resolved) {
            if (autowireNecessary) {
                return autowireConstructor(beanName,null);
            }
            else {
                return instantiateBean(beanName,mbd);
            }
        }

        // 使用构造函数创建bean
        Constructor<?>[] ctors = determineConstructorsFromBeanPostProcessors(beanClass,beanName);
        if (ctors != null ||
                mbd.getResolvedAutowireMode() == RootBeanDeFinition.AUTOWIRE_CONSTRUCTOR ||
                mbd.hasconstructorargumentValues() || !ObjectUtils.isEmpty(args))  {
            return autowireConstructor(beanName,ctors,args);
        }

        // 使用默认的构造函数创建bean
        return instantiateBean(beanName,mbd);
    }
    // 使用默认的构造函数创建bean
    protected BeanWrapper instantiateBean(final String beanName,final RootBeanDeFinition mbd) {
        try {
            Object beanInstance;
            final beanfactory parent = this;
            if (System.getSecurityManager() != null) {
                beanInstance = AccessController.doPrivileged(new PrivilegedAction<Object>() {
                    @Override
                    public Object run() {
                      //
                        return getInstantiationStrategy().instantiate(mbd,parent);
                    }
                },getAccessControlContext());
            }
            else {
                beanInstance = getInstantiationStrategy().instantiate(mbd,parent);
            }
            BeanWrapper bw = new BeanWrapperImpl(beanInstance);
            initBeanWrapper(bw);
            return bw;
        }
        catch (Throwable ex) {
            throw new BeanCreationException(mbd.getResourceDescription(),"Instantiation of bean Failed",ex);
        }
    }

public Object instantiate(RootBeanDeFinition bd,beanfactory owner) {
   // 如果没有override method 就走构造函数 否则走cglib
   if (bd.getmethodOverrides().isEmpty()) {
      Constructor<?> constructorToUse;
      synchronized (bd.constructorargumentLock) {
         constructorToUse = (Constructor<?>) bd.resolvedConstructorOrFactoryMethod;
         if (constructorToUse == null) {
            final Class<?> clazz = bd.getBeanClass();
            if (clazz.isInterface()) {
               throw new BeanInstantiationException(clazz,"Specified class is an interface");
            }
            try {
               if (System.getSecurityManager() != null) {
                  constructorToUse = AccessController.doPrivileged(new PrivilegedExceptionAction<Constructor<?>>() {
                     @Override
                     public Constructor<?> run() throws Exception {
                        return clazz.getDeclaredConstructor((Class[]) null);
                     }
                  });
               }
               else {
                  constructorToUse = clazz.getDeclaredConstructor((Class[]) null);
               }
               bd.resolvedConstructorOrFactoryMethod = constructorToUse;
            }
            catch (Exception ex) {
               throw new BeanInstantiationException(clazz,"No default constructor found",ex);
            }
         }
      }
      // BeanUtils 方法
      return BeanUtils.instantiateClass(constructorToUse);
   }
   else {
      // Must generate cglib subclass.
      return instantiateWithMethodInjection(bd,owner);
   }
}

protected void populateBean(String beanName,BeanWrapper bw) {
    // 需要注入的值
        PropertyValues pvs = mbd.getPropertyValues();

        if (bw == null) {
            if (!pvs.isEmpty()) {
                throw new BeanCreationException(
                        mbd.getResourceDescription(),"Cannot apply property values to null instance");
            }
            else {
                // Skip property population phase for null instance.
                return;
            }
        }

        // Give any InstantiationAwareBeanPostProcessors the opportunity to modify the
        // state of the bean before properties are set. This can be used,for example,// to support styles of field injection.
        boolean continueWithPropertyPopulation = true;

        if (!mbd.isSynthetic() && hasInstantiationAwareBeanPostProcessors()) {
            for (BeanPostProcessor bp : getBeanPostProcessors()) {
                if (bp instanceof InstantiationAwareBeanPostProcessor) {
                    InstantiationAwareBeanPostProcessor ibp = (InstantiationAwareBeanPostProcessor) bp;
                    if (!ibp.postProcessAfterInstantiation(bw.getWrappedInstance(),beanName)) {
                        continueWithPropertyPopulation = false;
                        break;
                    }
                }
            }
        }

        if (!continueWithPropertyPopulation) {
            return;
        }

        if (mbd.getResolvedAutowireMode() == RootBeanDeFinition.AUTOWIRE_BY_NAME ||
                mbd.getResolvedAutowireMode() == RootBeanDeFinition.AUTOWIRE_BY_TYPE) {
            MutablePropertyValues newPvs = new MutablePropertyValues(pvs);

            // Add property values based on autowire by name if applicable.
            if (mbd.getResolvedAutowireMode() == RootBeanDeFinition.AUTOWIRE_BY_NAME) {
                autowireByName(beanName,bw,newPvs);
            }

            // Add property values based on autowire by type if applicable.
            if (mbd.getResolvedAutowireMode() == RootBeanDeFinition.AUTOWIRE_BY_TYPE) {
                autowireByType(beanName,newPvs);
            }

            pvs = newPvs;
        }

        boolean hasInstAwareBpps = hasInstantiationAwareBeanPostProcessors();
        boolean needsDepCheck = (mbd.getDependencyCheck() != RootBeanDeFinition.DEPENDENCY_CHECK_NONE);

        if (hasInstAwareBpps || needsDepCheck) {
            PropertyDescriptor[] filteredPds = filterPropertyDescriptorsForDependencyCheck(bw,mbd.allowCaching);
            if (hasInstAwareBpps) {
                for (BeanPostProcessor bp : getBeanPostProcessors()) {
                    if (bp instanceof InstantiationAwareBeanPostProcessor) {
                        InstantiationAwareBeanPostProcessor ibp = (InstantiationAwareBeanPostProcessor) bp;
                        pvs = ibp.postProcesspropertyValues(pvs,filteredPds,bw.getWrappedInstance(),beanName);
                        if (pvs == null) {
                            return;
                        }
                    }
                }
            }
            if (needsDepCheck) {
                checkDependencies(beanName,pvs);
            }
        }
    // 注入操作
        applyPropertyValues(beanName,pvs);
    }

    protected void applyPropertyValues(String beanName,BeanDeFinition mbd,BeanWrapper bw,PropertyValues pvs) {
        if (pvs == null || pvs.isEmpty()) {
            return;
        }

        MutablePropertyValues mpvs = null;
        List<PropertyValue> original;

        if (System.getSecurityManager() != null) {
            if (bw instanceof BeanWrapperImpl) {
                ((BeanWrapperImpl) bw).setSecurityContext(getAccessControlContext());
            }
        }

        if (pvs instanceof MutablePropertyValues) {
            mpvs = (MutablePropertyValues) pvs;
            if (mpvs.isConverted()) {
                // Shortcut: use the pre-converted values as-is.
                try {
                    bw.setPropertyValues(mpvs);
                    return;
                }
                catch (BeansException ex) {
                    throw new BeanCreationException(
                            mbd.getResourceDescription(),"Error setting property values",ex);
                }
            }
            original = mpvs.getPropertyValueList();
        }
        else {
            original = Arrays.asList(pvs.getPropertyValues());
        }

        TypeConverter converter = getCustomTypeConverter();
        if (converter == null) {
            converter = bw;
        }
        //处理类
        BeanDeFinitionValueResolver valueResolver = new BeanDeFinitionValueResolver(this,converter);

        // Create a deep copy,resolving any references for values.
        List<PropertyValue> deepcopy = new ArrayList<PropertyValue>(original.size());
        boolean resolveNecessary = false;
        for (PropertyValue pv : original) {
            if (pv.isConverted()) {
                deepcopy.add(pv);
            }
            else {
                String propertyName = pv.getName();
                Object originalValue = pv.getValue();
                //
                Object resolvedValue = valueResolver.resolveValueIfNecessary(pv,originalValue);
                Object convertedValue = resolvedValue;
                boolean convertible = bw.isWritableProperty(propertyName) &&
                        !PropertyAccessorUtils.isnestedOrIndexedProperty(propertyName);
                if (convertible) {
                    convertedValue = convertForProperty(resolvedValue,propertyName,converter);
                }
                // Possibly store converted value in merged bean deFinition,// in order to avoid re-conversion for every created bean instance.
                if (resolvedValue == originalValue) {
                    if (convertible) {
                        pv.setConvertedValue(convertedValue);
                    }
                    deepcopy.add(pv);
                }
                else if (convertible && originalValue instanceof TypedStringValue &&
                        !((TypedStringValue) originalValue).isDynamic() &&
                        !(convertedValue instanceof Collection || ObjectUtils.isArray(convertedValue))) {
                    pv.setConvertedValue(convertedValue);
                    deepcopy.add(pv);
                }
                else {
                    resolveNecessary = true;
                    deepcopy.add(new PropertyValue(pv,convertedValue));
                }
            }
        }
        if (mpvs != null && !resolveNecessary) {
            mpvs.setConverted();
        }

        // Set our (possibly massaged) deep copy.
        try {
            bw.setPropertyValues(new MutablePropertyValues(deepcopy));
        }
        catch (BeansException ex) {
            throw new BeanCreationException(
                    mbd.getResourceDescription(),ex);
        }
    }

public <T> T convertIfNecessary(String propertyName,Object oldValue,Object newValue,Class<T> requiredType,TypeDescriptor typeDescriptor) throws IllegalArgumentException {

   // Custom editor for this type?
   propertyeditor editor = this.propertyeditorRegistry.findCustomEditor(requiredType,propertyName);

   ConversionFailedException conversionAttemptEx = null;

   // No custom editor but custom ConversionService specified?
   ConversionService conversionService = this.propertyeditorRegistry.getConversionService();
   if (editor == null && conversionService != null && newValue != null && typeDescriptor != null) {
      TypeDescriptor sourceTypeDesc = TypeDescriptor.forObject(newValue);
      if (conversionService.canConvert(sourceTypeDesc,typeDescriptor)) {
         try {
            return (T) conversionService.convert(newValue,sourceTypeDesc,typeDescriptor);
         }
         catch (ConversionFailedException ex) {
            // fallback to default conversion logic below
            conversionAttemptEx = ex;
         }
      }
   }

   Object convertedValue = newValue;

   // Value not of required type?
   if (editor != null || (requiredType != null && !ClassUtils.isAssignableValue(requiredType,convertedValue))) {
      if (requiredType != null && Collection.class.isAssignableFrom(requiredType) && convertedValue instanceof String) {
         TypeDescriptor elementType = typeDescriptor.getElementTypeDescriptor();
         if (elementType != null && Enum.class.isAssignableFrom(elementType.getType())) {
            convertedValue = StringUtils.commaDelimitedListToStringArray((String) convertedValue);
         }
      }
      if (editor == null) {
         editor = findDefaultEditor(requiredType);
      }
      convertedValue = doConvertValue(oldValue,convertedValue,editor);
   }

   boolean standardConversion = false;

   if (requiredType != null) {
      // Try to apply some standard type conversion rules if appropriate.

      if (convertedValue != null) {
         if (Object.class == requiredType) {
            return (T) convertedValue;
         }
         else if (requiredType.isArray()) {
            // Array required -> apply appropriate conversion of elements.
            if (convertedValue instanceof String && Enum.class.isAssignableFrom(requiredType.getComponentType())) {
               convertedValue = StringUtils.commaDelimitedListToStringArray((String) convertedValue);
            }
            return (T) convertToTypedArray(convertedValue,requiredType.getComponentType());
         }
         else if (convertedValue instanceof Collection) {
            // Convert elements to target type,if determined.
            convertedValue = convertToTypedCollection(
                  (Collection<?>) convertedValue,typeDescriptor);
            standardConversion = true;
         }
         else if (convertedValue instanceof Map) {
            // Convert keys and values to respective target type,if determined.
            convertedValue = convertToTypedMap(
                  (Map<?,?>) convertedValue,typeDescriptor);
            standardConversion = true;
         }
         if (convertedValue.getClass().isArray() && Array.getLength(convertedValue) == 1) {
            convertedValue = Array.get(convertedValue,0);
            standardConversion = true;
         }
         if (String.class == requiredType && ClassUtils.isPrimitiveOrWrapper(convertedValue.getClass())) {
            // We can stringify any primitive value...
            return (T) convertedValue.toString();
         }
         else if (convertedValue instanceof String && !requiredType.isinstance(convertedValue)) {
            if (conversionAttemptEx == null && !requiredType.isInterface() && !requiredType.isEnum()) {
               try {
                  Constructor<T> strCtor = requiredType.getConstructor(String.class);
                  return BeanUtils.instantiateClass(strCtor,convertedValue);
               }
               catch (NoSuchMethodException ex) {
                  // proceed with field lookup
                  if (logger.isTraceEnabled()) {
                     logger.trace("No String constructor found on type [" + requiredType.getName() + "]",ex);
                  }
               }
               catch (Exception ex) {
                  if (logger.isDebugEnabled()) {
                     logger.debug("Construction via String Failed for type [" + requiredType.getName() + "]",ex);
                  }
               }
            }
            String trimmedValue = ((String) convertedValue).trim();
            if (requiredType.isEnum() && "".equals(trimmedValue)) {
               // It's an empty enum identifier: reset the enum value to null.
               return null;
            }
            convertedValue = attemptToConvertStringToEnum(requiredType,trimmedValue,convertedValue);
            standardConversion = true;
         }
         else if (convertedValue instanceof Number && Number.class.isAssignableFrom(requiredType)) {
            convertedValue = NumberUtils.convertNumberToTargetClass(
                  (Number) convertedValue,(Class<Number>) requiredType);
            standardConversion = true;
         }
      }
      else {
         // convertedValue == null
         if (javaUtilOptionalEmpty != null && requiredType.equals(javaUtilOptionalEmpty.getClass())) {
            convertedValue = javaUtilOptionalEmpty;
         }
      }

      if (!ClassUtils.isAssignableValue(requiredType,convertedValue)) {
         if (conversionAttemptEx != null) {
            // Original exception from former ConversionService call above...
            throw conversionAttemptEx;
         }
         else if (conversionService != null) {
            // ConversionService not tried before,probably custom editor found
            // but editor Couldn't produce the required type...
            TypeDescriptor sourceTypeDesc = TypeDescriptor.forObject(newValue);
            if (conversionService.canConvert(sourceTypeDesc,typeDescriptor)) {
               return (T) conversionService.convert(newValue,typeDescriptor);
            }
         }

         // Definitely doesn't match: throw IllegalArgumentException/IllegalStateException
         StringBuilder msg = new StringBuilder();
         msg.append("Cannot convert value of type [").append(ClassUtils.getDescriptiveType(newValue));
         msg.append("] to required type [").append(ClassUtils.getQualifiedname(requiredType)).append("]");
         if (propertyName != null) {
            msg.append(" for property '").append(propertyName).append("'");
         }
         if (editor != null) {
            msg.append(": propertyeditor [").append(editor.getClass().getName()).append(
                  "] returned inappropriate value of type [").append(
                  ClassUtils.getDescriptiveType(convertedValue)).append("]");
            throw new IllegalArgumentException(msg.toString());
         }
         else {
            msg.append(": no matching editors or conversion strategy found");
            throw new IllegalStateException(msg.toString());
         }
      }
   }

   if (conversionAttemptEx != null) {
      if (editor == null && !standardConversion && requiredType != null && Object.class != requiredType) {
         throw conversionAttemptEx;
      }
      logger.debug("Original ConversionService attempt Failed - ignored since " +
            "propertyeditor based conversion eventually succeeded",conversionAttemptEx);
   }

   return (T) convertedValue;
}

protected void setPropertyValue(PropertyTokenHolder tokens,PropertyValue pv) throws BeansException {
        String propertyName = tokens.canonicalName;
        String actualName = tokens.actualName;

        if (tokens.keys != null) {
            // Apply indexes and map keys: fetch value for all keys but the last one.
            PropertyTokenHolder getterTokens = new PropertyTokenHolder();
            getterTokens.canonicalName = tokens.canonicalName;
            getterTokens.actualName = tokens.actualName;
            getterTokens.keys = new String[tokens.keys.length - 1];
            System.arraycopy(tokens.keys,0,getterTokens.keys,tokens.keys.length - 1);
            Object propValue;
            try {
                propValue = getPropertyValue(getterTokens);
            }
            catch (NotReadablePropertyException ex) {
                throw new NotWritablePropertyException(getRootClass(),this.nestedpath + propertyName,"Cannot access indexed value in property referenced " +
                                "in indexed property path '" + propertyName + "'",ex);
            }
            // Set value for last key.
            String key = tokens.keys[tokens.keys.length - 1];
            if (propValue == null) {
                // null map value case
                if (isautogrownestedpaths()) {
                    // Todo: cleanup,this is pretty hacky
                    int lastKeyIndex = tokens.canonicalName.lastIndexOf('[');
                    getterTokens.canonicalName = tokens.canonicalName.substring(0,lastKeyIndex);
                    propValue = setDefaultValue(getterTokens);
                }
                else {
                    throw new NullValueInnestedpathException(getRootClass(),"Cannot access indexed value in property referenced " +
                                    "in indexed property path '" + propertyName + "': returned null");
                }
            }
            if (propValue.getClass().isArray()) {
                PropertyHandler ph = getLocalPropertyHandler(actualName);
                Class<?> requiredType = propValue.getClass().getComponentType();
                int arrayIndex = Integer.parseInt(key);
                Object oldValue = null;
                try {
                    if (isExtractOldValueForEditor() && arrayIndex < Array.getLength(propValue)) {
                        oldValue = Array.get(propValue,arrayIndex);
                    }
                    Object convertedValue = convertIfNecessary(propertyName,oldValue,pv.getValue(),ph.nested(tokens.keys.length));
                    int length = Array.getLength(propValue);
                    if (arrayIndex >= length && arrayIndex < this.autogrowCollectionLimit) {
                        Class<?> componentType = propValue.getClass().getComponentType();
                        Object newArray = Array.newInstance(componentType,arrayIndex + 1);
                        System.arraycopy(propValue,newArray,0,length);
                        setPropertyValue(actualName,newArray);
                        propValue = getPropertyValue(actualName);
                    }
                    Array.set(propValue,arrayIndex,convertedValue);
                }
                catch (indexoutofboundsexception ex) {
                    throw new InvalidPropertyException(getRootClass(),"Invalid array index in property path '" + propertyName + "'",ex);
                }
            }
            else if (propValue instanceof List) {
                PropertyHandler ph = getPropertyHandler(actualName);
                Class<?> requiredType = ph.getCollectionType(tokens.keys.length);
                List<Object> list = (List<Object>) propValue;
                int index = Integer.parseInt(key);
                Object oldValue = null;
                if (isExtractOldValueForEditor() && index < list.size()) {
                    oldValue = list.get(index);
                }
                Object convertedValue = convertIfNecessary(propertyName,ph.nested(tokens.keys.length));
                int size = list.size();
                if (index >= size && index < this.autogrowCollectionLimit) {
                    for (int i = size; i < index; i++) {
                        try {
                            list.add(null);
                        }
                        catch (NullPointerException ex) {
                            throw new InvalidPropertyException(getRootClass(),"Cannot set element with index " + index + " in List of size " +
                                            size + ",accessed using property path '" + propertyName +
                                            "': List does not support filling up gaps with null elements");
                        }
                    }
                    list.add(convertedValue);
                }
                else {
                    try {
                        list.set(index,convertedValue);
                    }
                    catch (indexoutofboundsexception ex) {
                        throw new InvalidPropertyException(getRootClass(),"Invalid list index in property path '" + propertyName + "'",ex);
                    }
                }
            }
            else if (propValue instanceof Map) {
                PropertyHandler ph = getLocalPropertyHandler(actualName);
                Class<?> mapKeyType = ph.getMapKeyType(tokens.keys.length);
                Class<?> mapValueType = ph.getMapValueType(tokens.keys.length);
                Map<Object,Object> map = (Map<Object,Object>) propValue;
                // IMPORTANT: Do not pass full property name in here - property editors
                // must not kick in for map keys but rather only for map values.
                TypeDescriptor typeDescriptor = TypeDescriptor.valueOf(mapKeyType);
                Object convertedMapKey = convertIfNecessary(null,null,key,mapKeyType,typeDescriptor);
                Object oldValue = null;
                if (isExtractOldValueForEditor()) {
                    oldValue = map.get(convertedMapKey);
                }
                // Pass full property name and old value in here,since we want full
                // conversion ability for map values.
                Object convertedMapValue = convertIfNecessary(propertyName,mapValueType,ph.nested(tokens.keys.length));
                map.put(convertedMapKey,convertedMapValue);
            }
            else {
                throw new InvalidPropertyException(getRootClass(),"Property referenced in indexed property path '" + propertyName +
                                "' is neither an array nor a List nor a Map; returned value was [" + propValue + "]");
            }
        }

        else {
            PropertyHandler ph = getLocalPropertyHandler(actualName);
            if (ph == null || !ph.isWritable()) {
                if (pv.isOptional()) {
                    if (logger.isDebugEnabled()) {
                        logger.debug("Ignoring optional value for property '" + actualName +
                                "' - property not found on bean class [" + getRootClass().getName() + "]");
                    }
                    return;
                }
                else {
                    throw createNotWritablePropertyException(propertyName);
                }
            }
            Object oldValue = null;
            try {
                Object originalValue = pv.getValue();
                Object valuetoApply = originalValue;
                if (!Boolean.FALSE.equals(pv.conversionNecessary)) {
                    if (pv.isConverted()) {
                        valuetoApply = pv.getConvertedValue();
                    }
                    else {
                        if (isExtractOldValueForEditor() && ph.isReadable()) {
                            try {
                                oldValue = ph.getValue();
                            }
                            catch (Exception ex) {
                                if (ex instanceof PrivilegedActionException) {
                                    ex = ((PrivilegedActionException) ex).getException();
                                }
                                if (logger.isDebugEnabled()) {
                                    logger.debug("Could not read prevIoUs value of property '" +
                                            this.nestedpath + propertyName + "'",ex);
                                }
                            }
                        }
                        valuetoApply = convertForProperty(
                                propertyName,originalValue,ph.toTypeDescriptor());
                    }
                    pv.getoriginalPropertyValue().conversionNecessary = (valuetoApply != originalValue);
                }
                ph.setValue(object,valuetoApply);
            }
            catch (TypeMismatchException ex) {
                throw ex;
            }
            catch (InvocationTargetException ex) {
                PropertyChangeEvent propertyChangeEvent =
                        new PropertyChangeEvent(this.rootObject,pv.getValue());
                if (ex.getTargetException() instanceof ClassCastException) {
                    throw new TypeMismatchException(propertyChangeEvent,ph.getPropertyType(),ex.getTargetException());
                }
                else {
                    Throwable cause = ex.getTargetException();
                    if (cause instanceof UndeclaredThrowableException) {
                        // May happen e.g. with Groovy-generated methods
                        cause = cause.getCause();
                    }
                    throw new MethodInvocationException(propertyChangeEvent,cause);
                }
            }
            catch (Exception ex) {
                PropertyChangeEvent pce =
                        new PropertyChangeEvent(this.rootObject,pv.getValue());
                throw new MethodInvocationException(pce,ex);
            }
        }
    }
    // 使用反射机制，执行注入set方法注入bean
    public void setValue(final Object object,Object valuetoApply) throws Exception {
            final Method writeMethod = (this.pd instanceof GenericTypeAwarePropertyDescriptor ?
                    ((GenericTypeAwarePropertyDescriptor) this.pd).getWriteMethodForActualAccess() :
                    this.pd.getWriteMethod());
            if (!Modifier.isPublic(writeMethod.getDeclaringClass().getModifiers()) && !writeMethod.isAccessible()) {
                if (System.getSecurityManager() != null) {
                    AccessController.doPrivileged(new PrivilegedAction<Object>() {
                        @Override
                        public Object run() {
                            writeMethod.setAccessible(true);
                            return null;
                        }
                    });
                }
                else {
                    writeMethod.setAccessible(true);
                }
            }
            final Object value = valuetoApply;
            if (System.getSecurityManager() != null) {
                try {
                    AccessController.doPrivileged(new PrivilegedExceptionAction<Object>() {
                        @Override
                        public Object run() throws Exception {
                            writeMethod.invoke(object,value);
                            return null;
                        }
                    },acc);
                }
                catch (PrivilegedActionException ex) {
                    throw ex.getException();
                }
            }
            else {
                writeMethod.invoke(getWrappedInstance(),value);
            }
        }

@Entity
public class User {

    @Id
    @GeneratedValue
    private Long id;

    @Column(nullable = false)
    private String name;

    @Column(nullable = false)
    private Integer age;

    // 省略构造函数

    // 省略getter和setter

}

public interface UserRepository extends JpaRepository<User, Long> {

    User findByName(String name);

    User findByNameAndAge(String name, Integer age);

    @Query("from User u where u.name=:name")
    User findUser(@Param("name") String name);

}

@RunWith(SpringJUnit4ClassRunner.class)
@SpringApplicationConfiguration(Application.class)
public class ApplicationTests {

	@Autowired
	private UserRepository userRepository;

	@Test
	public void test() throws Exception {

		// 创建10条记录
		userRepository.save(new User("AAA", 10));
		userRepository.save(new User("BBB", 20));
		userRepository.save(new User("CCC", 30));
		userRepository.save(new User("DDD", 40));
		userRepository.save(new User("EEE", 50));
		userRepository.save(new User("FFF", 60));
		userRepository.save(new User("GGG", 70));
		userRepository.save(new User("HHH", 80));
		userRepository.save(new User("III", 90));
		userRepository.save(new User("JJJ", 100));

		// 测试findAll, 查询所有记录
		Assert.assertEquals(10, userRepository.findAll().size());

		// 测试findByName, 查询姓名为FFF的User
		Assert.assertEquals(60, userRepository.findByName("FFF").getAge().longValue());

		// 测试findUser, 查询姓名为FFF的User
		Assert.assertEquals(60, userRepository.findUser("FFF").getAge().longValue());

		// 测试findByNameAndAge, 查询姓名为FFF并且年龄为60的User
		Assert.assertEquals("FFF", userRepository.findByNameAndAge("FFF", 60).getName());

		// 测试删除姓名为AAA的User
		userRepository.delete(userRepository.findByName("AAA"));

		// 测试findAll, 查询所有记录, 验证上面的删除是否成功
		Assert.assertEquals(9, userRepository.findAll().size());

	}


}
