Adminify - 基于Vuetify的后台管理界面

Adminify

https://github.com/wxs77577/a...

基于Vuetify的后台管理框架，后续会推出基于AdonisJs的后端接口

• An Admin dashboard based on Vuetify .

• Data in demo use axios-mock-adapter

• Better Server API is built on AdonisJs .

• Also welcome to Adonis China .

Screenshots

Features

• Vue + Vue Router + Vuex + Axios.

• Material Design Style - Vuetify

• Data Grid with server side sort,search,pagination and json config.

• Dynamic Form Builder with text,textarea,radios,checkboxes,select,html input types and json config.

• Built in localStorage proxy for any data types.

• Axios Mock with axios-mock-adapter and mockjs

• Configurable side menu with json

• i18n with vue-i18n

• Basic and Main layouts

• Stylus processor

• And more of your requests.

Getting start

1. git clone https://github.com/wxs77577/adminify.git

2. Copy src/config.sample.js to src/config.js

3. npm install

4. npm run dev

Use cnpm instead npm in China

Config

src/config.js

const baseUrl = ''http://localhost:3333''
const config = {
  locale: ''en-US'', //en-US, zh-CN
  url: baseUrl,
  debug: {
    mock: 1, //enable mock
    http: true, //http request log
  },
  api: `${baseUrl}/admin/api`
  // locale: ''en'', //en
  // api: ''http://192.168.1.108:3333/admin/api''
}

Menu Config

src/menu.js

export default [
  { "href": "/", "title": "Home", "icon": "home" },
  { "href": "/crud/types", "title": "Types", "icon": "view_list" },
  { "href": "/crud/posts", "title": "Posts", "icon": "view_list" },
  { "href": "/crud/posts/create", "title": "Create Post", "icon": "note_add" },


  { "href": "/crud/comments", "title": "Comments", "icon": "view_list" },
  { "href": "/crud/users", "title": "Users", "icon": "people" },



  { "href": "/chat", "title": "Chat", "icon": "chat" },
  {
    "title": "Pages",
    "icon": "domain",
    "items": [
      { "href": "/example", "title": "Example" },
      { "href": "/about", "title": "About" }
    ]
  },
  { "href": "/settings", "title": "Settings", "icon": "settings" },

  { "href": "/login", "icon": "lock", "title": "Logout" }
]

No more explaination needed right?

Routes

Part of src/router.js

  // The signature of `route` function :
  function route(path, file, name, children) {}

  //routes
  [
    route(''/login'', ''Login'', ''login''),
    route(''/error'', ''Error'', ''error''),

    //path, file(*.vue), name, children

    route(''/'', ''Main'', null, [
      route(''/'', ''Home'', ''home''),
      route(''/crud/:resource'', ''CrudGrid'', ''grid''),
      route(''/crud/:resource/:id/edit'', ''CrudForm'', ''edit''),
      route(''/crud/:resource/create'', ''CrudForm'', ''create''),
      route(''/crud/:resource/:id/:action'', ''CrudForm'', ''action''),
      route(''/crud/:resource/:action'', ''CrudForm'', ''indexAction''),
      route(''/example'', ''Example''),
      route(''/settings'', ''Settings''),
      route(''/theme'', ''Theme''),
      route(''/chat'', ''Chat''),
      route(''/about'', ''About''),
    ]),


    // Global redirect for 404
    { path: ''*'', redirect: ''/error'', query: {code: 404, message: ''Page Not Found.''} }
  ]

Grid View Config

src/mock/index.js

mock.onGet(''/types/grid'').reply(200, {
  "options": {
    "sort": "id", //default sort column
    "create": false, //show Create button
    "update": true, //show update button
    "delete": false //show delete button
  },
  "filters": {
    "model": {
      "name": "",
      "created_at": ""
    },
    "fields": { //filters fields config
      "name": {
        "label": "Name"
      },
      "created_at": {
        "label": "Created At",
        "type": "date"
      }
    },
    "rules": {}
  },
  "columns": [ //columns config
    {
      "text": "Id", //column header text
      "value": "id" //field name
    },
    {
      "text": "Name",
      left: true, //make text align left, default is right
      "value": "name"
    }
  ]
});

Grid View Data

src/mock/index.js

mock.onGet(/\/(posts|users|types|comments)$/).reply(({ params = { page: 1, perPage: 10 }, url }) => {
  let resource = url.split(''/'')[1]
  let offset = (params.page - 1) * params.perPage
  let models = data[resource]
  return [200, { //return like this format
    currentPage: params.page,
    lastPage: Math.ceil(models.length / params.perPage),
    perPage: params.perPage,
    total: data[resource].length,
    data: models.slice(offset, offset + params.perPage)
  }]
});

Form Builder Config

src/mock/index.js

mock.onGet(''/settings/form'').reply(({ params }) => {
  return [200, {
    "model": { //form model
      name: ''Adminify'',
      logo: ''http://placeimg.com/128/128/any'',
      date: null,

      type: 1,
      status: 1,

      tags: [],
      description: ''An Awesome Site'',
      intro: '''',
    },
    "fields": { //form fields
      "name": {label: ''Name''}, //default type is ''text''
      "logo": {label: ''Logo'', type: ''image''}, //working in progress
      "date": {label: ''Created At'', type: ''date''},
      "type": {label: ''Type'', type: ''select'', options: [
        {text: ''Blog'', value: 1},
        {text: ''Company'', value: 2},
        {text: ''Game'', value: 3},
      ]},
      "status": {label: ''Status'', type: ''radios'', width: ''md3'', options: [
        {text: ''Enabled'', value: 1},
        {text: ''Disabled'', value: 2}
      ]},
      "tags": {label: ''Tags'', type: ''checkboxes'', width: ''md3'', options: [
        {text: ''Enabled'', value: 1},
        {text: ''Disabled'', value: 2}
      ]},
      "description": {label: ''Description'', type: ''textarea''},
      "intro": {label: ''Intro'', type: ''html''},
    }
  }]
})

Comunication

Gitter IM

https://gitter.im/vue-adminify/

Wechat Group

Electron: 如何以 Vue.js, Vuetify 开始应用

• Electron: 使用 JavaScript, HTML 和 CSS 等 Web 技术创建原生程序的框架
• Vue.js: Web 前端用于构建用户界面的渐进式框架
• Vuetify: Vue.js 的 Material Design 组件框架

看完以上介绍，也明白了本文要做的事：用 Vue.js 与 Vuetify 组件，基于 Electron 来创建原生桌面应用。

• 环境准备

  • Visual Studio Code
  • Node.js
  • Yarn
  • Vue CLI
• 创建 Vue.js 应用
• 添加 Vuetify 组件
• 添加 Electron 构建
• 发布 Electron 应用
• 参考
• 结语

环境准备

Visual Studio Code

建议使用的 VS Code 编辑代码，下载地址： https://code.visualstudio.com/ 。

同时可安装如下些扩展：

• ESLint: 代码检查
• Prettier - Code formatter: 代码格式化
• Vetur: Vue 代码工具
• Vue 2 Snippets: Vue 代码提示（可选）

查看 VS Code 版本：

$ code -v
1.46.1
cd9ea6488829f560dc949a8b2fb789f3cdc05f5d
x64

Node.js

Node.js 开发环境，下载地址： https://nodejs.org/en/download/ 。

建议选择 Latest LTS Version ，因为 Electron v9 仍旧使用的 Node.js v12 。

查看 Node, NPM 版本：

$ node -v
v12.18.1

$ npm -v
6.14.5

Yarn

Yarn 包管理工具，相比 NPM 而言： Fast, Reliable, Secure 。

GitHub: https://github.com/yarnpkg/yarn

全局安装 Yarn ：

npm config set registry https://registry.npm.taobao.org
npm install -g yarn

查看 Yarn 版本：

$ yarn -v
1.22.4

Vue CLI

Vue CLI 是 Vue.js 开发的标准工具。

GitHub: https://github.com/vuejs/vue-cli

全局安装 Vue CLI ：

yarn global add @vue/cli

查看 Vue CLI 版本：

$ vue -V
@vue/cli 4.4.6

创建 Vue.js 应用

vue create my-app

跟随引导进行工程配置，如下：

Vue CLI v4.4.6
? Please pick a preset: Manually select features
? Check the features needed for your project: Babel, TS, Router, Vuex, Linter
? Use class-style component syntax? Yes
? Use Babel alongside TypeScript (required for modern mode, auto-detected polyfills, transpiling JSX)? Yes
? Use history mode for router? (Requires proper server setup for index fallback in production) Yes
? Pick a linter / formatter config: Prettier
? Pick additional lint features: Lint on save
? Where do you prefer placing config for Babel, ESLint, etc.? In dedicated config files
? Save this as a preset for future projects? No
? Pick the package manager to use when installing dependencies: Yarn

~/.vuerc 会保存一些可复用的 preset ：

$ cat ~/.vuerc
{
  "useTaobaoRegistry": true,
  "packageManager": "yarn"
}

运行应用：

cd my-app
yarn serve

浏览器打开 http://localhost:8080/ ：

添加 Vuetify 组件

Vuetify 是 Vue.js 的 Material Design 组件库。也可以换用其他的，如 Element 等。

GitHub: https://github.com/vuetifyjs/...

添加 Vuetify ：

cd my-app
vue add vuetify

preset 选择 Default ：

? Choose a preset: Default (recommended)

添加完成后，编辑下 tsconfig.json ：

{
  "compilerOptions": {
    ...
    "types": [
-      "webpack-env"
+      "webpack-env",
+      "vuetify"
    ],
    ...
  },
  ...
}

运行应用：

yarn serve

浏览器打开 http://localhost:8080/ ：

编辑 tsconfig.json 是为了修正如下错误

ERROR in /Users/John/Codes/ikuokuo/start-electron/my-app/src/plugins/vuetify.ts(2,21):
2:21 Could not find a declaration file for module ''vuetify/lib''. ''/Users/John/Codes/ikuokuo/start-electron/my-app/node_modules/vuetify/lib/index.js'' implicitly has an ''any'' type.
  Try `npm install @types/vuetify` if it exists or add a new declaration (.d.ts) file containing `declare module ''vuetify/lib'';`
    1 | import Vue from "vue";
  > 2 | import Vuetify from "vuetify/lib";
      |                     ^
    3 |
    4 | Vue.use(Vuetify);
    5 |

添加 Electron 构建

如果你可以建一个网站，你就可以建一个桌面应用程序。 Electron 负责将 Web 构建成原生桌面应用。

而将 Vue.js 应用构建成 Electron 应用，现在用 Vue CLI Plugin Electron Builder 即可。

首先，指明下 node 版本：

yarn add @types/node@12 --dev

之后，添加 Electron Builder ：

cd my-app
vue add electron-builder

Electron 版本选择 9.0.0 ：

? Choose Electron Version ^9.0.0

添加完成后，编辑下 src/router/index.ts ：

...
const router = new VueRouter({
-  mode: "history",
+  mode: process.env.IS_ELECTRON ? "hash" : "history",
  base: process.env.BASE_URL,
  routes
});

export default router;

运行应用：

yarn electron:serve

现在是桌面窗口了：

命令定义在了 package.json ：

{
  ...
  "scripts": {
    "serve": "vue-cli-service serve",
    "build": "vue-cli-service build",
    "lint": "vue-cli-service lint",
    "electron:build": "vue-cli-service electron:build",
    "electron:serve": "vue-cli-service electron:serve",
    "postinstall": "electron-builder install-app-deps",
    "postuninstall": "electron-builder install-app-deps"
  },
  ...
}

yarn 执行即可，如下:

$ yarn lint
yarn run v1.22.4
$ vue-cli-service lint
 DONE  No lint errors found!
✨  Done in 3.17s.

yarn add @types/node@12 --dev 是为了修正如下错误

ERROR in /Users/John/Codes/ikuokuo/start-electron/my-app/node_modules/electron/electron.d.ts(1659,31):
1659:31 Cannot extend an interface ''NodeJS.EventEmitter''. Did you mean ''implements''?
...

编辑 src/router/index.ts 是为了修正如下警告

 WARN  It is detected that you are using Vue Router. If you are using history mode, you must push the default route when the root component is loaded. Learn more at https://goo.gl/GM1xZG .

发布 Electron 应用

Vue 应用了 Electron Builder 插件，所以直接用此工具即可。

GitHub: https://github.com/electron-u...

yarn electron:build 编译发布：

# 淘宝镜像，国内下载 Electron 更快
export ELECTRON_MIRROR="https://cdn.npm.taobao.org/dist/electron/"

# macOS 下禁用签名。若要签名，见最后参考
export CSC_IDENTITY_AUTO_DISCOVERY=false

cd my-app
yarn electron:build

dist_electron/ 下即是发布内容。

例如 macOS 可见打包好的 dmg ：

双击 dmg 试用或安装：

若要修改发布格式或内容，见 Electron Builder 文档： https://www.electron.build/ 。

export CSC_IDENTITY_AUTO_DISCOVERY=false 是为了避免如下错误

...
  • signing         file=dist_electron/mac/my-app.app identityName=gdb_codesign identityHash=BC899AF362F80B3FDB39F966A1601E2AFAFA100B provisioningProfile=none
(node:10223) UnhandledPromiseRejectionWarning: Error: Command failed: codesign --sign BC899AF362F80B3FDB39F966A1601E2AFAFA100B --force --timestamp --options runtime --entitlements /Users/John/Workspace/Codes/start-electron/my-app/node_modules/app-builder-lib/templates/entitlements.mac.plist /Users/John/Workspace/Codes/start-electron/my-app/dist_electron/mac/my-app.app/Contents/Frameworks/Electron Framework.framework/Versions/A/Helpers/chrome_crashpad_handler
error: The specified item could not be found in the keychain.
...
(node:10223) UnhandledPromiseRejectionWarning: Unhandled promise rejection. This error originated either by throwing inside of an async function without a catch block, or by rejecting a promise which was not handled with .catch(). To terminate the node process on unhandled promise rejection, use the CLI flag `--unhandled-rejections=strict` (see https://nodejs.org/api/cli.html#cli_unhandled_rejections_mode). (rejection id: 1)
(node:10223) [DEP0018] DeprecationWarning: Unhandled promise rejections are deprecated. In the future, promise rejections that are not handled will terminate the Node.js process with a non-zero exit code.

参考

• electron-app
• start-electron

• Electron

  • Application Distribution

• Electron Builder

  • Code Signing
  • Notarize app for macOS

结语

Go coding!
