<AutoCompleteTextView
属性列表>
</AutoCompleteTextView>

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
  android:layout_width="fill_parent"
  android:layout_height="fill_parent"
  android:orientation="horizontal"
  android:background="#000000">
<AutoCompleteTextView
  android:layout_height="wrap_content"
  android:text=""
  android:id="@+id/autoCompleteTextView1"
  android:completionThreshold="2"
  android:completionHint="请输入内容"
  android:background="#333333"
  android:layout_marginLeft="10dp"
  android:layout_weight="7"
  android:layout_width="wrap_content"
  >
</AutoCompleteTextView>
<Button android:text="搜索"
    android:id="@+id/button0"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:layout_weight="1"
    android:layout_marginLeft="10dp"/>
</LinearLayout>

//此字符串是要在下拉菜单中显示的列表项
private static final String[] COUNTRIES=new String[]{"jb51","jb51编程小技巧","jb51脚本下载","jb51软件下载","www.jb51.net","编程小技巧"};

//获取自动完成文本框
final AutoCompleteTextView textView=(AutoCompleteTextView)findViewById(R.id.autoCompleteTextView1);
//注意ArrayAdapter与SimpleAdapter的区别
//创建一个ArrayAdapter适配器
ArrayAdapter<String> adapter=new ArrayAdapter<String>(this,android.R.layout.simple_dropdown_item_1line,COUNTRIES);
textView.setAdapter(adapter);//为自动完成文本框设置适配器

//为搜索按钮添加事件监听器
button.setonClickListener(new OnClickListener() {
  public void onClick(View arg0) {
    Toast.makeText(MainActivity.this,textView.getText().toString(),Toast.LENGTH_SHORT).show();
  }
});

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
  xmlns:tools="http://schemas.android.com/tools"
  android:layout_width="fill_parent"
  android:layout_height="fill_parent"
  android:orientation="horizontal"
  android:background="#000000">
  <AutoCompleteTextView
    android:layout_width="wrap_content"
    android:text=""
    android:id="@+id/autoCompleteTextView1"
    android:completionThreshold="2"
    android:completionHint="输入搜索内容"
    android:background="#FFFFFF"
    android:layout_marginLeft="10px"
    android:layout_weight="7"
    android:layout_height="wrap_content">
  </AutoCompleteTextView>
  <Button android:text="搜索"
    android:id="@+id/button0"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:layout_weight="1"
    android:layout_marginLeft="10px"/>
</LinearLayout>

package com.example.test;


import android.app.Activity;
import android.os.Bundle;
import android.view.View;
import android.view.View.OnClickListener;
import android.widget.ArrayAdapter;
import android.widget.AutoCompleteTextView;
import android.widget.Button;
import android.widget.Toast;


public class MainActivity extends Activity {
  //此字符串是要在下拉菜单中显示的列表项
  private static final String[] COUNTRIES=new String[]{"HeNan","HeNan大学","HeNan理工大学","HeNan工业大学","HeNan万方科技学院","HeNan第二附属医院二院"};
  @Override
  protected void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.main);

    //获取自动完成文本框
    final AutoCompleteTextView textView=(AutoCompleteTextView)findViewById(R.id.autoCompleteTextView1);
    //注意ArrayAdapter与SimpleAdapter的区别
    //创建一个ArrayAdapter适配器
    ArrayAdapter<String> adapter=new ArrayAdapter<String>(this,android.R.layout.simple_dropdown_item_1line,COUNTRIES);
    textView.setAdapter(adapter);//为自动完成文本框设置适配器

    Button button=(Button)findViewById(R.id.button0);//获取"搜索"按钮
    //为搜索按钮添加事件监听器
    button.setonClickListener(new OnClickListener() {

      @Override
      public void onClick(View arg0) {
        Toast.makeText(MainActivity.this,textView.getText().toString(),Toast.LENGTH_SHORT).show();

      }
    });
  }
}

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
 android:layout_width="fill_parent"
 android:layout_height="fill_parent"
 android:orientation="horizontal"
 android:id="@+id/layout"
 android:gravity="center">
 <gallery
 android:id="@+id/gallery1"
 android:spacing="5px"
 android:unselectedAlpha="0.6"
 android:layout_width="match_parent"
 android:layout_height="wrap_content"/>
</LinearLayout>

<?xml version="1.0" encoding="utf-8"?>
<resources>
 <declare-styleable name="gallery">
 <attr name="android:galleryItemBackground"/>
 </declare-styleable>
</resources>

package com.example.test;


import android.app.Activity;
import android.content.res.TypedArray;
import android.os.Bundle;
import android.view.View;
import android.view.ViewGroup;
import android.widget.AdapterView;
import android.widget.AdapterView.OnItemClickListener;
import android.widget.BaseAdapter;
import android.widget.gallery;
import android.widget.ImageView;
import android.widget.Toast;


public class MainActivity extends Activity{


 @Override
 protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 setContentView(R.layout.main);

 gallery gallery=(gallery)findViewById(R.id.gallery1);
 final int [] imageId=new int[]{R.drawable.img01,R.drawable.img02,R.drawable.img03,R.drawable.img04,R.drawable.img05,R.drawable.img06,R.drawable.img07,R.drawable.img08,R.drawable.img_top,R.drawable.ic_launcher,R.drawable.in,R.drawable.stop,};//定义并初始化保存图片id的数组
 //创建并改写BaseAdapter适配器
 BaseAdapter adapter=new BaseAdapter(){


  @Override
  public View getView(int position,View convertView,ViewGroup parent) {
  ImageView imageView;//声明一个ImageView的对象
  if(convertView==null){
   imageView=new ImageView(MainActivity.this);//实例化ImageView对象
   imageView.setScaleType(ImageView.ScaleType.FIT_XY);//设置缩放方式
   imageView. setLayoutParams(new gallery.LayoutParams(180,135));//设置ImageView宽高
   TypedArray typedArray=obtainStyledAttributes(R.styleable.gallery);//获取自定义属性对象
   //为imageView设置背景图片的资源，使用了自定义属性对象typedArray获取自定义背景资源值
   imageView.setBackgroundResource(
    typedArray.getResourceId(R.styleable.gallery_android_galleryItemBackground,0));
   imageView.setPadding(5,5,0);//设置内边距
  }else{
   //如果以前new过View就使用convertView的缓存
   imageView=(ImageView)convertView;
  }
  imageView.setimageResource(imageId[position]);
  return imageView;
  }

  //功能:获得当前选项的id
  @Override
  public long getItemId(int position) {
  return position;
  }

  //功能：获得当前选项
  @Override
  public Object getItem(int position) {
  return position;
  }

  //获得数量
  @Override
  public int getCount() {
  return imageId.length;
  }


 };

 gallery.setAdapter(adapter);
 gallery.setSelection(imageId.length/2);
 gallery.setonItemClickListener(new OnItemClickListener() {


  @Override
  public void onItemClick(AdapterView<?> parent,View v,int position,long id) {
  Toast.makeText(MainActivity.this,"您选择了第"+String.valueOf(position)+"张图片",Toast.LENGTH_SHORT).show();
  }
 });
 }
}
