android – Rajawali旋转相机与Sensor.TYPE_ROTATION_VECTOR奇怪的行为（旋转相机app）

25-03-18 10

在这里，我们将给大家分享关于android–Rajawali旋转相机与Sensor.TYPE_ROTATION_VECTOR奇怪的行为的知识，让您更了解旋转相机app的本质，同时也会涉及到如何更有效地

在这里，我们将给大家分享关于android – Rajawali旋转相机与Sensor.TYPE_ROTATION_VECTOR奇怪的行为的知识，让您更了解旋转相机app的本质，同时也会涉及到如何更有效地android Conflict with dependency 'com.android.support:support-annotations' in project ':app'.、android DialogFragment出现 Can not perform this action after onSaveInstanceState、Android getActiveNotifications抛出SecurityException、Android OnLongClickListener奇怪/不可靠的行为的内容。

本文目录一览：

android – Rajawali旋转相机与Sensor.TYPE_ROTATION_VECTOR奇怪的行为（旋转相机app）
android Conflict with dependency 'com.android.support:support-annotations' in project ':app'.
android DialogFragment出现 Can not perform this action after onSaveInstanceState
Android getActiveNotifications抛出SecurityException
Android OnLongClickListener奇怪/不可靠的行为

android – Rajawali旋转相机与Sensor.TYPE_ROTATION_VECTOR奇怪的行为（旋转相机app）

我正在创建一个全景视图,允许用户通过旋转智能手机环顾一下球形图像.我将Rajawali的SkyBox与TYPE_ROTATION_VECTOR传感器一起使用.

我得到了它的工作,但只有当我向前看时(它实际上是基于我的旋转(偏航))

这是行为：

>期待：yaw = yaw,pitch = pitch and roll = roll
>向左看：yaw = yaw,pitch = roll and roll = pitch
>向后看：yaw = yaw,pitch = pitch * -1和roll = roll * -1.

现在我确实有预感正在发生什么.似乎“相机对象”一直看着相同的方向,即使它看起来不是这样.这意味着俯仰似乎与滚动相同,但是它仍然在俯仰,因为物体没有旋转.我把它比作飞机上的四处看看.

我需要做些什么来解决这个问题？

我有一种感觉,我将不得不用lookAt()旋转相机,但我不知道如何.

public class SkyBoxFragment extends RajawaliFragment implements SensorEventListener {

    public static final String TAG = "SkyBoxFragment";
    private SensorManager mSensorManager;
    private float[] orientationVals = new float[3];
    private float[] mRotationMatrix = new float[16];
    private Sensor mRotVectSensor;

    @Override
    public View onCreateView(LayoutInflater inflater, ViewGroup container,
                             Bundle savedInstanceState) {
        super.onCreateView(inflater, container, savedInstanceState);

        LinearLayout ll = new LinearLayout(getActivity());
        ll.setorientation(LinearLayout.VERTICAL);
        ll.setGravity(Gravity.CENTER_HORIZONTAL | Gravity.TOP);
        mSensorManager = (SensorManager) getActivity().getSystemService(
                Context.SENSOR_SERVICE);
        mRotVectSensor = mSensorManager.getDefaultSensor(Sensor.TYPE_ROTATION_VECTOR);
        mLayout.addView(ll);
        mSensorManager.registerListener(this,
                mRotVectSensor,
                10000);
        return mLayout;
    }

    @Override
    public AExampleRenderer createRenderer() {
        mRenderer = new SkyBoxRenderer(getActivity());
        return ((SkyBoxRenderer) mRenderer);
    }

    @Override
    public void onClick(View v) {

    }

    @Override
    public void onSensorChanged(SensorEvent event) {

        if (event.sensor.getType() == Sensor.TYPE_ROTATION_VECTOR) {
            SensorManager.getRotationMatrixFromVector(mRotationMatrix, event.values);
            SensorManager.remapCoordinateSystem(mRotationMatrix, SensorManager.AXIS_X, SensorManager.AXIS_Z, mRotationMatrix);
            SensorManager.getorientation(mRotationMatrix, orientationVals);
            orientationVals[0] = (float) Math.todegrees(orientationVals[0]);
            orientationVals[1] = (float) Math.todegrees(orientationVals[1]) * -1;
            orientationVals[2] = (float) Math.todegrees(orientationVals[2]) * -1;
            //Log.d(TAG,  "YAW:" + orientationVals[0] + " PITCH:" + orientationVals[1] + "ROLL:" + orientationVals[2]);
        }

    }

    @Override
    public void onAccuracyChanged(Sensor sensor, int accuracy) {

    }

    private final class SkyBoxRenderer extends AExampleRenderer implements View.OnClickListener {

        private final Vector3 mAccValues;
        boolean odd = true;

        public SkyBoxRenderer(Context context) {
            super(context);
            mAccValues = new Vector3();
        }

        @Override
        protected void initScene() {
            getCurrentCamera().setFarPlane(1000);
            /**
             * SkyBox images by Emil PeRSSon, aka Humus. http://www.humus.name humus@comhem.se
             */
            try {
                getCurrentScene().setSkyBox(R.drawable.posx, R.drawable.negx,
                        R.drawable.posy, R.drawable.negy, R.drawable.posz, R.drawable.negz);
            } catch (ATexture.TextureException e) {
                e.printstacktrace();
            }
        }

        @Override
        protected void onRender(long ellapsedRealtime, double deltaTime) {
            super.onRender(ellapsedRealtime, deltaTime);
            getCurrentCamera().setRotation(orientationVals[2], orientationVals[0], orientationVals[1]);
        }

        @Override
        public void onClick(View v) {
            try {
                if (odd) {
                    /**
                     * SkyBox images by Emil PeRSSon, aka Humus. http://www.humus.name humus@comhem.se
                     */
                    getCurrentScene().updateSkyBox(R.drawable.posx2, R.drawable.negx2,
                            R.drawable.posy2, R.drawable.negy2, R.drawable.posz2, R.drawable.negz2);
                } else {
                    /**
                     * SkyBox images by Emil PeRSSon, aka Humus. http://www.humus.name humus@comhem.se
                     */
                    getCurrentScene().updateSkyBox(R.drawable.posx, R.drawable.negx,
                            R.drawable.posy, R.drawable.negy, R.drawable.posz, R.drawable.negz);
                }
            } catch (Exception e) {
                e.printstacktrace();
            } finally {
                odd = !odd;
            }
        }

        public void setAccelerometerValues(float x, float y, float z) {
            mAccValues.setAll(-x, -y, -z);
        }
    }

}

解决方法:

你有两个问题.首先是您要描述的问题,但另一个问题是TYPE_ROTATION_VECTOR的传感器会受到附近磁铁的影响,例如手机外壳中的磁铁.

解决磁铁问题

解决方案可以是使用加速度计和陀螺仪的组合.幸运的是,Google Cardboard SDK已经将其抽象了.

您可以通过使用HeadTracker.createFromContext(this.getActivity())实例化com.google.vrtoolkit.cardboard.sensors.HeadTracker的实例并在其上调用startTracking()来跟踪当前轮换.

现在你不再需要onSensorChanged了.相反,在你的onRender中,你可以这样做：

float[] R = new float[16];
headTracker.getLastHeadView(R, 0);

获得旋转矩阵.这解决了您未说明的磁场问题.

让相机正确环顾四周

使用此旋转矩阵将摄像机指向正确方向的最简单方法是将其转换为org.rajawali3d.math.Quaternion,然后调用getCurrentCamera().setCameraOrientation(quaternion);

从float [16]到四元数的转换可能很难正确,但Google Cardboard SDK再一次为您做到了.在这种情况下,它位于不再使用的旧类的源代码中：HeadTransform.

您可以轻松地调整该代码以返回新的Quaternion(w,x,y,z);.

现在,如果没有将orientationVals [1]和orientationVals [2]乘以-1,则会产生与当前代码相同的问题.

然而,通过反转旋转矩阵可以很容易地解决该问题.这将导致onRender中的以下代码(假设getQuaternion(R)返回org.rajawali3d.math.Quaternion)：

@Override
protected void onRender(long ellapsedRealtime, double deltaTime) {
    super.onRender(ellapsedRealtime, deltaTime);

    float[] R = new float[16];
    headTracker.getLastHeadView(R, 0);

    android.opengl.Matrix.invertM(R, 0, R, 0);

    Quaternion q = getQuaternion(R);

    getCurrentCamera().setCameraOrientation(q);
}

android Conflict with dependency 'com.android.support:support-annotations' in project ':app'.

如题所示只是新建了一个项目就报这个错了。

问题以后解决了如下：

这样就可以了。但是原因了我还是不知道。我也没有修改或者升级什么东西。。知道原因的大佬请告知一下。

转载自：https://blog.csdn.net/qq_33313551/article/details/80240332

android DialogFragment出现 Can not perform this action after onSaveInstanceState

在使用android的DialogFragment的时候如果实在Activity在后台的时候调用dismiss函数的时候会出现Can not perform this action after onSaveInstanceState的异常，这个异常跟activity状态被保存之后又尝试提交一个 FragmentTransaction，原因是因为DialogFragment在调用dismiss函数的时候需要提交一个FragmentTransaction事务，但是在 onSaveInstanceState()函数调用之后，提交事务就会导致状态丢失，这样就会出现异常。不同的系统显示异常的方式不同。

为了避免这个问题就是在Activity在后台时或者onSaveInstanceState()和onStop()方法被调用后，就不直接调用dismiss函数改调用dismissAllowingStateLoss。还有一种方式是把这个DialogFragment状态记录下俩在Activity 启动的时候在调用dismiss函数。

Android getActiveNotifications抛出SecurityException

我有一个监听通知的NotificationService类.但是,当我调用getActiveNotifications()时,它会抛出SecurityException.是的,我在调用此方法之前已经检查了许可.

我在NotificationService中使用AsyncTask来获取通知.代码如下.

private class AsyncProcessNotification extends AsyncTask<Void,Void,Void> {

        @Override
        protected Void doInBackground(Void... params) {
            int notificationType = MainApplication.settingNotificationType;
            MainApplication.clearNotificationItems();

            if (MainApplication.settingNotificationType == Constants.KEY_NOTIFICATION_TYPE_disABLED) {
                Log.i(TAG,"Notifications disabled");
                return null;
            }

            if (PermissionHelper.isNotificationPermissionGranted(getApplicationContext())) {
                if (getActiveNotifications() == null || getActiveNotifications().length == 0) {
                    Log.i(TAG,"No notifications found");
                    return null;
                }

                Log.i(TAG,"Getting " + getActiveNotifications().length +" notifications");
                Log.i(TAG,"Notification type  " + notificationType);
                for (StatusBarNotification statusBarNotification : getActiveNotifications()) {
                    // Process notifications
                }
            } else {
                //
            }

            return null;
        }

        @Override
        protected void onPostExecute(Void result) {
            Intent notify = new Intent(Constants.ACTION_NOTIFICATION_LISTENER);
            sendbroadcast(notify);
        }
    }

奇怪的是根据
Crashlytics,有时它在if(getActiveNotifications()== null || getActiveNotifications().length == 0)失败,有时它在Log.i失败(TAG,“获取”getActiveNotifications().length“notifications”);

要检查权限,我使用以下方法.

public static boolean isNotificationPermissionGranted(Context context) {
        Set<String> appList = notificationmanagerCompat.getEnabledListenerPackages(context);
        for (String l:appList) {
            if (l.equals(context.getPackageName())) {
                return true;
            }
        }

        return false;
    }

堆栈跟踪：

Fatal Exception: java.lang.RuntimeException: An error occurred while executing doInBackground()
       at android.os.AsyncTask$3.done(AsyncTask.java:309)
       at java.util.concurrent.FutureTask.finishCompletion(FutureTask.java:354)
       at java.util.concurrent.FutureTask.setException(FutureTask.java:223)
       at java.util.concurrent.FutureTask.run(FutureTask.java:242)
       at android.os.AsyncTask$SerialExecutor$1.run(AsyncTask.java:234)
       at java.util.concurrent.ThreadPoolExecutor.runWorker(ThreadPoolExecutor.java:1113)
       at java.util.concurrent.ThreadPoolExecutor$Worker.run(ThreadPoolExecutor.java:588)
       at java.lang.Thread.run(Thread.java:818)
Caused by java.lang.SecurityException: disallowed call from unkNown notification listener: android.service.notification.INotificationListener$Stub$Proxy@3e9880d
       at android.os.Parcel.readException(Parcel.java:1599)
       at android.os.Parcel.readException(Parcel.java:1552)
       at android.app.Inotificationmanager$Stub$Proxy.getActiveNotificationsFromListener(Inotificationmanager.java:1046)
       at android.service.notification.NotificationListenerService.getActiveNotifications(NotificationListenerService.java:467)
       at android.service.notification.NotificationListenerService.getActiveNotifications(NotificationListenerService.java:420)
       at com.afd.app.lockscreen.ios11.lib.service.NotificationService$AsyncProcessNotification.doInBackground(NotificationService.java:120)
       at com.afd.app.lockscreen.ios11.lib.service.NotificationService$AsyncProcessNotification.doInBackground(NotificationService.java:97)
       at android.os.AsyncTask$2.call(AsyncTask.java:295)
       at java.util.concurrent.FutureTask.run(FutureTask.java:237)
       at android.os.AsyncTask$SerialExecutor$1.run(AsyncTask.java:234)
       at java.util.concurrent.ThreadPoolExecutor.runWorker(ThreadPoolExecutor.java:1113)
       at java.util.concurrent.ThreadPoolExecutor$Worker.run(ThreadPoolExecutor.java:588)
       at java.lang.Thread.run(Thread.java:818)

我知道我必须做一些愚蠢但却无法弄清楚是什么.有人可以帮忙吗？谢谢！

解决方法

I hit the same error in my notification listener service. I was able
to solve it by waiting for the listener service to get connected to the
notification manager before calling any of the
NotificationListenerService methods.

@Override
public void onListenerConnected() {
    Log.i(TAG,"Listener connected");
    listenerConnected = true;
}

private class AsyncProcessNotification extends AsyncTask<Void,Void> {
    protected Void doInBackground(Void... params) {
              ...
            // wait until our notification listener service is connected
            // to the notification manager
            Log.i(TAG,"Waiting for listener to be connected...");

            while(!listenerConnected);

            // Call getActiveNotifications after this
            for (StatusBarNotification sbn : getActiveNotifications()) {
                   processNotifications(sbn);
            }
    }

    // rest of the AsyncTask here
}

Android OnLongClickListener奇怪/不可靠的行为

我目前正在与Android Api Lvl 8上的OnLongClickListener作战.

拿这个代码：

this.webView.setonLongClickListener(new OnLongClickListener() {
    @Override
    public boolean onLongClick(View v) {
        System.out.println("long click");
        return true;
    }
});

它完美地运作.我可以按下WebView上的任意位置,每次都触发事件触发器.

现在来看看这个：

this.webView.setonLongClickListener(new OnLongClickListener() {
    @Override
    public boolean onLongClick(View v) {
        final EditText editText = getUrlTextField();

        switch (editText.getVisibility()) {
        case View.VISIBLE:
            editText.setVisibility(View.GONE);
            return true;
        case View.GONE:
            editText.setVisibility(View.VISIBLE);
            return true;
        default:
            return false;
        }
    }
});

假设URL EditText组件当前可见,它将从显示中消失,并在触发另一个长按事件时再次显示.
但是如果你运行它,当一个人在WebView上的任何一个位置上执行长按时,该事件只运行一次(！).为了使事情变得复杂,当在网站上的链接上执行时,长按会再次起作用…

任何人都可以解释它是否是sdk中的错误和/或我是否认为OnLongClickListener是如何工作的？：/

编辑：

我现在已经在Nexus One上运行了几个不同的场景,并得出以下结论：在运行时或多或少地更改布局会杀死OnLongClickListener ……我还没有找到让它可靠地工作的方法……

我真的很感激,如果有人能给我一个提示……我在我的智慧结束:(

解决方法:

个人而言,我最终在每次重播后重新设置了听众.

今天关于android – Rajawali旋转相机与Sensor.TYPE_ROTATION_VECTOR奇怪的行为和旋转相机app的分享就到这里，希望大家有所收获，若想了解更多关于android Conflict with dependency 'com.android.support:support-annotations' in project ':app'.、android DialogFragment出现 Can not perform this action after onSaveInstanceState、Android getActiveNotifications抛出SecurityException、Android OnLongClickListener奇怪/不可靠的行为等相关知识，可以在本站进行查询。
