>用户空间程序开始绑定到用户定义的多播组.
>插入内核模块
>内核模块向此多播组发送消息
>用户空间程序接收消息

这是我的代码：

======用户空间程序======

#include<stdio.h>
#include<string.h>
#include<stdlib.h>
#include<sys/socket.h>
#include<linux/netlink.h>
#include<sys/types.h>
#include<unistd.h>

#define MYPROTO NETLINK_USERSOCK
#define MYMGRP 0x21 //User defined group,consistent in both kernel prog and user prog

int open_netlink()
{
        int sock = socket(AF_NETLINK,SOCK_RAW,MYPROTO);
        struct sockaddr_nl addr;

        memset((void *)&addr,sizeof(addr));

        if (sock<0)
                return sock;
        addr.nl_family = AF_NETLINK;
        addr.nl_pid = getpid();
        addr.nl_groups = MYMGRP;
        if (bind(sock,(struct sockaddr *)&addr,sizeof(addr))<0)
                return -1;
        return sock;
}

int read_event(int sock)
{
        struct sockaddr_nl nladdr;
        struct msghdr msg;
        struct iovec iov[2];
        struct nlmsghdr nlh;
        char buffer[65536];
        int ret;
        iov[0].iov_base = (void *)&nlh;
        iov[0].iov_len = sizeof(nlh);
        iov[1].iov_base = (void *)buffer;
        iov[1].iov_len = sizeof(buffer);
        msg.msg_name = (void *)&(nladdr);
        msg.msg_namelen = sizeof(nladdr);
        msg.msg_iov = iov;
        msg.msg_iovlen = sizeof(iov)/sizeof(iov[0]);
        ret=recvmsg(sock,&msg,0);
        if (ret<0) {
                return ret;
        }
        printf("Received message payload: %s\n",NLMSG_DATA(&nlh));
}

int main(int argc,char *argv[])
{
        int nls = open_netlink();
        if (nls<0) {
                err(1,"netlink");
        }

        while (1)
                read_event(nls);
        return 0;
}

======内核模块======

#include <linux/module.h>
#include <linux/kernel.h>
#include <linux/init.h>
#include <net/sock.h>
#include <linux/socket.h>
#include <linux/net.h>
#include <asm/types.h>
#include <linux/netlink.h>
#include <linux/rtnetlink.h>
#include <linux/skbuff.h>
#include <linux/delay.h>

#define NETLINK_USER 31
#define MYGRP 0x21 //User defined group,consistent in both kernel prog and user prog

struct sock *nl_sk = NULL;

static void send_to_user() {
    struct sk_buff *skb_out;
    struct nlmsghdr *nlh;
    int msg_size;
    char *msg = "Hello from kernel";
    int res;

    printk(KERN_INFO "Entering: %s\n",__FUNCTION__);
    msg_size = strlen(msg);
    skb_out = nlmsg_new(msg_size,0);

    if (!skb_out) {
        printk(KERN_ERR "Failed to allocate new skb\n");
        return;
    }
    nlh = nlmsg_put(skb_out,1,NLMSG_DONE,msg_size,0);
    //NETLINK_CB(skb_out).dst_group = 1; /* Multicast to group 1,1<<0 */
    strncpy(nlmsg_data(nlh),msg,msg_size);

    res = nlmsg_multicast(nl_sk,skb_out,MYGRP,0);
    if (res < 0) {
        printk(KERN_INFO "Error while sending bak to user,err id: %d\n",res);
    }
}

static int __init
hello_init(void) {

    struct netlink_kernel_cfg cfg = {
            .groups = MYGRP,};
    printk("Entering: %s\n",__FUNCTION__);
    nl_sk = netlink_kernel_create(&init_net,NETLINK_USER,&cfg);
    if (!nl_sk) {
        printk(KERN_ALERT "Error creating socket.\n");
        return -10;
    }

    send_to_user();

    return 0;
}

static void __exit
hello_exit(void) {

    printk(KERN_INFO "exiting hello module\n");
    netlink_kernel_release(nl_sk);
}

module_init(hello_init);
module_exit(hello_exit);

由于内核模块只会在初始化期间发送一次消息,因此我首先运行监听程序然后插入模块,尽管我总是遇到这个错误：

Error while sending bak to user,err id: -3

追踪到错误ID时,它反映在netlink / af_netlink.c中的这段代码中：

if (info.delivery_failure) {
    kfree_skb(info.skb2);
    return -ENOBUFS;
}
consume_skb(info.skb2);

if (info.delivered) {
    if (info.congested && (allocation & __GFP_WAIT))
    yield();
    return 0;
}
return -ESRCH;

我认为它不是delivery_failure,但由于某些原因仍未提供.

我指的是这个example,其中作者的程序一直在改变监听路线.虽然我想使用用户定义的多播组.

有任何想法吗？提前致谢！

>协议族和组播组都需要在内核prog和用户prog中保持一致.您的协议系列是用户空间中的NETLINK_USERSOCK(2)和内核空间中的NETLINK_USER(31).
> addr.nl_groups = MYMGRP;由于某种原因不起作用.但这确实如下：setsockopt(sock,270,NETLINK_ADD_MEMBERSHIP,& group,sizeof(group)).

不致命：

>在这种情况下,模块不会侦听组消息,因此您不需要在netlink_kernel_create()参数中包含多播组.

此外,并非真正与netlink相关,但有用：

> strlen()不包含null chara.在消息分配期间,您应该添加一个字节来弥补这一点.
>在这种情况下,NLMSG_DATA(& nlh)是未定义的行为.这是因为你的标题和数据都在单独的内存块中,不能保证被粘合,并且所有宏都在nlh之后访问内存块：

#define NLMSG_DATA(nlh)((void *)(((char *)nlh)NLMSG_LENGTH(0)))

这是我的代码版本：

用户空间程序：

#include <stdio.h>
#include <string.h>
#include <stdlib.h>
#include <sys/socket.h>
#include <linux/netlink.h>
#include <unistd.h>

/* Protocol family,consistent in both kernel prog and user prog. */
#define MYPROTO NETLINK_USERSOCK
/* Multicast group,consistent in both kernel prog and user prog. */
#define MYMGRP 21

int open_netlink(void)
{
    int sock;
    struct sockaddr_nl addr;
    int group = MYMGRP;

    sock = socket(AF_NETLINK,MYPROTO);
    if (sock < 0) {
        printf("sock < 0.\n");
        return sock;
    }

    memset((void *) &addr,sizeof(addr));
    addr.nl_family = AF_NETLINK;
    addr.nl_pid = getpid();
    /* This doesn't work for some reason. See the setsockopt() below. */
    /* addr.nl_groups = MYMGRP; */

    if (bind(sock,(struct sockaddr *) &addr,sizeof(addr)) < 0) {
        printf("bind < 0.\n");
        return -1;
    }

    /*
     * 270 is SOL_NETLINK. See
     * http://lxr.free-electrons.com/source/include/linux/socket.h?v=4.1#L314
     * and
     * https://stackoverflow.com/questions/17732044/
     */
    if (setsockopt(sock,&group,sizeof(group)) < 0) {
        printf("setsockopt < 0\n");
        return -1;
    }

    return sock;
}

void read_event(int sock)
{
    struct sockaddr_nl nladdr;
    struct msghdr msg;
    struct iovec iov;
    char buffer[65536];
    int ret;

    iov.iov_base = (void *) buffer;
    iov.iov_len = sizeof(buffer);
    msg.msg_name = (void *) &(nladdr);
    msg.msg_namelen = sizeof(nladdr);
    msg.msg_iov = &iov;
    msg.msg_iovlen = 1;

    printf("Ok,listening.\n");
    ret = recvmsg(sock,0);
    if (ret < 0)
        printf("ret < 0.\n");
    else
        printf("Received message payload: %s\n",NLMSG_DATA((struct nlmsghdr *) &buffer));
}

int main(int argc,char *argv[])
{
    int nls;

    nls = open_netlink();
    if (nls < 0)
        return nls;

    while (1)
        read_event(nls);

    return 0;
}

这是内核模块：

#include <linux/module.h>
#include <linux/kernel.h>
#include <linux/netlink.h>
#include <net/netlink.h>
#include <net/net_namespace.h>

/* Protocol family,consistent in both kernel prog and user prog. */
#define MYGRP 21

static struct sock *nl_sk = NULL;

static void send_to_user(void)
{
    struct sk_buff *skb;
    struct nlmsghdr *nlh;
    char *msg = "Hello from kernel";
    int msg_size = strlen(msg) + 1;
    int res;

    pr_info("Creating skb.\n");
    skb = nlmsg_new(NLMSG_ALIGN(msg_size + 1),GFP_KERNEL);
    if (!skb) {
        pr_err("Allocation failure.\n");
        return;
    }

    nlh = nlmsg_put(skb,msg_size + 1,0);
    strcpy(nlmsg_data(nlh),msg);

    pr_info("Sending skb.\n");
    res = nlmsg_multicast(nl_sk,skb,GFP_KERNEL);
    if (res < 0)
        pr_info("nlmsg_multicast() error: %d\n",res);
    else
        pr_info("Success.\n");
}

static int __init hello_init(void)
{
    pr_info("Inserting hello module.\n");

    nl_sk = netlink_kernel_create(&init_net,MYPROTO,NULL);
    if (!nl_sk) {
        pr_err("Error creating socket.\n");
        return -10;
    }

    send_to_user();

    netlink_kernel_release(nl_sk);
    return 0;
}

static void __exit hello_exit(void)
{
    pr_info("Exiting hello module.\n");
}

module_init(hello_init);
module_exit(hello_exit);

MODULE_LICENSE("GPL");

在内核3.13中测试过.

(我可以建议人们使用libnl-3而不是原始套接字用于用户空间程序.它的多播Netlink文档是actually decent.)

struct sockaddr_nl
{
   sa_family_t nl_family; /*该字段总是为AF_NETLINK */
   unsigned short nl_pad; /* 目前未用到，填充为0*/
   __u32 nl_pid; /* process pid */
   __u32 nl_groups; /* multicast groups mask */
};

struct sockaddr_nl
{
   sa_family_t nl_family; /*该字段总是为AF_NETLINK */
   unsigned short nl_pad; /* 目前未用到，填充为0*/
   __u32 nl_pid; /* process pid */
   __u32 nl_groups; /* multicast groups mask */
};

int netlink_unicast(struct sock *ssk, struct sk_buff *skb, u32 pid, int nonblock)

int netlink_unicast(struct sock *ssk, struct sk_buff *skb, u32 pid, int nonblock)

我阅读了有关用户空间 – 内核空间通信的Netlink实现,看起来这是一个好主意,但不确定它是否是最佳解决方案.但我读到UDEV设备管理器使用Netlink等待来自内核空间的“uevent”,但我不清楚如何做到这一点.

我读到了关于轮询sysfs但看起来轮询文件系统不是一个好主意.

你认为我应该在我的服务中使用什么实现？我应该使用netlink(硬/不知道如何)或只是轮询sysfs(不确定它是否有效)？

谢谢

udevtrigger是一个很好的实用程序,可以对udev更改做出反应.

http://www.linuxjournal.com/article/7356

http://smacked.org/docs/netlink.pdf

http://guichaz.free.fr/misc/iotop.py

http://manpages.ubuntu.com/manpages/gutsy/man8/udevtrigger.8.html

用户空间应用：

signal(SIGIO,&signal_handler_func);
fcntl(fd,F_SetoWN,getpid());
oflags = fcntl(fd,F_GETFL);
fcntl(fd,F_SETFL,oflags | FASYNC);

定义signal_handler_func函数：

void signal_handler_func (int sig)
{

//handle the action corresponding to the signal here
}

内核空间模块：

int ret = 0;
struct siginfo info;
memset(&info,sizeof(struct siginfo));
info.si_signo = SIG_TEST;
info.si_code = SI_QUEUE;
info.si_int = 1234;

send_sig_info(SIG_TEST,&info,t);//send signal to user land

t是用户应用程序的PID.

在用户空间中,您可以监听(例如,某些阻塞读取,或者只是尾部测试)到/ dev / input / yourevent for events.
