mysql 案例～关于 drop 的那点事（mysql中drop的用法）

25-04-30 1

如果您想了解mysql案例～关于drop的那点事的相关知识，那么本文是一篇不可错过的文章，我们将对mysql中drop的用法进行全面详尽的解释，并且为您提供关于A2-03-12.DDL-MySQLDR

如果您想了解mysql 案例～关于 drop 的那点事的相关知识，那么本文是一篇不可错过的文章，我们将对mysql中drop的用法进行全面详尽的解释，并且为您提供关于A2-03-12.DDL-MySQL DROP COLUMN、alter database datafile offline drop 与 alter tablespace drop datafile 区别、Drop Table 对 MySQL 的性能影响分析、DROP 表正在为元数据锁定 MYSQL 提供状态等待的有价值的信息。

本文目录一览：

mysql 案例～关于 drop 的那点事（mysql中drop的用法）
A2-03-12.DDL-MySQL DROP COLUMN
alter database datafile offline drop 与 alter tablespace drop datafile 区别
Drop Table 对 MySQL 的性能影响分析
DROP 表正在为元数据锁定 MYSQL 提供状态等待

mysql 案例～关于 drop 的那点事（mysql中drop的用法）

1 关于中断 session 操作
mysql 如果在前台执行 drop table 操作，中断了前台 session
1 经过我测试，会执行成功，但是 mysql.err 会记录一些错误。而且删除后确实可以创建同名表
2 中断的时机不同，报错的日志可能不一样
3 手动 ctrl+c kill xshell 断开连接这三者对于 drop table 都一样
4 记住任何前台操作一定要执行后台操作，不然会有危险，养成良好习惯
2 关于 drop 大表
0 选择在业务不繁忙的情况
1 rename table to table_new 这样是为了将 bf 中的关于该表的脏页刷新到磁盘中
2 ln table_new table_new.delete 建立 linux 硬链接
3 drop table
4 linux 实现删除表利用 truncate 命令
TRUNCATE=/usr/local/bin/truncate
for i in `seq 2194 -1 1 `;
do
sleep 2
$TRUNCATE -s ${i}G /data/mysql/mytest/erp.ibd.hdlk
done
rm -rf /data/mysql/mytest/erp.ibd.hdlk

3 drop 操作最新总结

可能触发的动作

1 AHI 短时间内会释放大量的内存

2 表的脏页会刷新到磁盘

3 针对 ibd 文件会执行 delete 操作

可能的观察参数

1 innodb_buffer_pool_pages_misc 大量释放，Innodb_buffer_pool_pages_free 值同时增长，释放和增加的内容总量基本一致

2 在 SEMAPHORES 相关信息中，可以看到 hang 死期间大量 Thread 请求 S-lock

可能导致问题

1 mysql thread hung

2 page cleaner 超时

总结

drop table 引起的 MySQL 短暂 hang 死的问题，是由于 drop 一张使用 AHI 空间较大的表时，调用执行 AHI 的清理动作，会消耗较长时间，执行期间长时间持有 dict_operation_lock 的 X 锁，阻塞了其他后台线程和用户线程；

drop table 执行结束锁释放，MySQL 积压的用户线程集中运行，出现了并发线程和连接数瞬间上升的现象。规避问题的方法，可以考虑在 drop table 前关闭 AHI。

A2-03-12.DDL-MySQL DROP COLUMN

转载自：http://www.mysqltutorial.org/mysql-drop-column/

Home / Basic MySQL Tutorial / MySQL DROP COLUMN

MySQL DROP COLUMN

Summary: in this tutorial, we will show you how to drop a column from a table using the MySQL DROP COLUMN statement.

Introduction to MySQL DROP COLUMN statement

In some situations, you want to remove one or more columns from a table. In such cases, you use the ALTER TABLE DROP COLUMN statement as follows:

1 2	ALTER TABLE table DROP COLUMN column;

Let’s examine the statement in more detail:

First, you specify the table that contains the column you want to remove after the ALTER TABLEclause.
Second, you put the name of the column following the DROP COLUMN clause.

Note that the keyword COLUMN is optional so you can use the shorter statement as follows:

1 2	ALTER TABLE table DROP column;

To remove multiple columns from a table at the same time, you use the following syntax:

ALTER TABLE table

DROP COLUMN column_1,

DROP COLUMN column_2,

…;

There are some important points you should remember before you remove a column from a table:

Removing a column from a table makes all database objects such as stored procedures, views, triggers, etc., that depend on the column invalid. For example, you may have a stored procedure that references to a column. When you remove the column, the stored procedure will become invalid. To fix it, you have to manually change the stored procedure’s code manually.
The code from other applications that depends on the removed column must be also changed, which takes time and efforts.
Removing a column from a large table can impact the performance of the database.

MySQL DROP COLUMN examples

First, we create a table named posts for the demonstration.

CREATE TABLE posts (

id INT AUTO_INCREMENT PRIMARY KEY,

title VARCHAR(255) NOT NULL,

excerpt VARCHAR(400),

content TEXT,

created_at DATETIME,

updated_at DATETIME

);

Second, to remove the excerpt column, you use the ALTER TABLE statement as follows:

1 2	ALTER TABLE posts DROP COLUMN excerpt;

Third, to remove both created_at and updated_at columns at the same time, you use the following statement:

ALTER TABLE posts

DROP COLUMN created_at,

DROP COLUMN updated_at;

MySQL drop a column which is a foreign key example

If you remove the column that is a foreign key, MySQL will issue an error. Let’s demonstrate the idea.

First, create a table named categories:

CREATE TABLE categories (

id INT AUTO_INCREMENT PRIMARY KEY,

name VARCHAR(255)

);

Second, add the category_id column to the posts table.

1	ALTER TABLE posts ADD COLUMN category_id INT NOT NULL;

Third, make the category_id column as a foreign key that references to the id column of the categories table.

ALTER TABLE posts

ADD CONSTRAINT fk_cat

FOREIGN KEY (category_id)

REFERENCES categories(id) ON DELETE CASCADE;

Fourth, drop the category_id column from the posts table.

1 2	ALTER TABLE posts DROP COLUMN category_id;

MySQL issued an error message:

1	Error Code: 1553. Cannot drop index ''fk_cat'': needed in a foreign key constraint

To avoid this error, you must remove the foreign key constraint before dropping the column.

In this tutorial, we have shown you how to use MySQL DROP COLUMN statement to remove one or more columns from a table.

Related Tutorials

How to Add Columns to a Table Using MySQL ADD COLUMN Statement
How To Rename Table Using MySQL RENAME TABLE Statement
Using MySQL ALTER TABLE To Change Table Structure
MySQL CREATE TABLE Statement By Examples

alter database datafile offline drop 与 alter tablespace drop datafile 区别

1. alter database datafile ''file_name'' offline drop

该命令不会删除数据文件，只是将数据文件的状态更改为recover。 offline drop命令相当于把一个数据文件至于离线状态，并且需要恢复，并非删除数据文件。数据文件的相关信息还会存在数据字典和控制文件中。

1.1 对于归档模式：

alter database datafile ''file_name'' offline 和 offline drop 没有什么区别。因为offline 之后多需要进行recover 才可以online。

如：

sql>ALTER DATABASE DATAFILE ''/u02/oracle/rbdb1/stuff01.dbf'' ONLINE;

sql>ALTER DATABASE DATAFILE ''/u02/oracle/rbdb1/stuff01.dbf'' OFFLINE;

1.2 对于非归档模式：

如果是非归档模式，只能是offline drop. 因为非归档模式没有归档文件来进行recover操作，当然，如果offline 之后，速度足够块，online redo里的数据还没有被覆盖掉，那么这种情况下，还是可以进行recover的。

oracle 11g:

sql>ALTER DATABASE DATAFILE ''/u02/oracle/rbdb1/users03.dbf'' OFFLINE FOR DROP;

2. alter tablesapce tablespace_name drop datafile ''datafile_name''

该语句会删除控制文件和磁盘上的文件，删除之后的原数据文件序列号可以重用。

注意，该语句只能是datafile online的时候才可以使用。如果说对应的数据文件已经是offline for drop，那么仅针对 dictionary managed tablespaces 可用。

3. 示例

sql> select * from v$version;

BANNER

----------------------------------------------------------------

Oracle Database 10g Enterprise Edition Release 10.2.0.1.0 - Prod

PL/sql Release 10.2.0.1.0 - Production

CORE 10.2.0.1.0 Production

TNS for Linux: Version 10.2.0.1.0 - Production

NLSRTL Version 10.2.0.1.0 - Production

sql> select name from v$datafile;

NAME

--------------------------------------------------------------------------------

+DATA/rac/datafile/system.256.746634087

+DATA/rac/datafile/undotbs1.258.746634089

+DATA/rac/datafile/sysaux.257.746634087

+DATA/rac/datafile/users.259.746634089

+DATA/rac/datafile/undotbs2.264.746634255

sql> create tablespace dave datafile ''+DATA/rac/datafile/dave01.dbf'' size 10M;

Tablespace created.

sql> alter tablespace dave add datafile ''+DATA/rac/datafile/dave02.dbf'' size 10M;

Tablespace altered.

sql> select file#,status,name from v$datafile;

FILE# STATUS NAME

---------- ------- -------------------------------------------------------------

1 SYstem +DATA/rac/datafile/system.256.746634087

2 ONLINE +DATA/rac/datafile/undotbs1.258.746634089

3 ONLINE +DATA/rac/datafile/sysaux.257.746634087

4 ONLINE +DATA/rac/datafile/users.259.746634089

5 ONLINE +DATA/rac/datafile/undotbs2.264.746634255

6 ONLINE +DATA/rac/datafile/dave01.dbf

7 ONLINE +DATA/rac/datafile/dave02.dbf

sql> alter database datafile ''+DATA/rac/datafile/dave01.dbf'' offline;

Database altered.

sql> set wrap off;

sql> select file#,status,name from v$datafile;

FILE# STATUS NAME

---------- ------- -------------------------------------------------------------

1 SYstem +DATA/rac/datafile/system.256.746634087

2 ONLINE +DATA/rac/datafile/undotbs1.258.746634089

3 ONLINE +DATA/rac/datafile/sysaux.257.746634087

4 ONLINE +DATA/rac/datafile/users.259.746634089

5 ONLINE +DATA/rac/datafile/undotbs2.264.746634255

6 RECOVER +DATA/rac/datafile/dave01.dbf

7 ONLINE +DATA/rac/datafile/dave02.dbf

7 rows selected.

sql> alter tablespace dave drop datafile 6;

alter tablespace dave drop datafile 6

ERROR at line 1:

ORA-03263: cannot drop the first file of tablespace DAVE

这里报错了，只有online 的才能删除。我们删除dave02.dbf 看看

sql> alter tablespace dave drop datafile 7;

Tablespace altered.

-- 删除成功。

sql> select file#,status,name from v$datafile;

FILE# STATUS NAME

---------- ------- -------------------------------------------------------------

1 SYstem +DATA/rac/datafile/system.256.746634087

2 ONLINE +DATA/rac/datafile/undotbs1.258.746634089

3 ONLINE +DATA/rac/datafile/sysaux.257.746634087

4 ONLINE +DATA/rac/datafile/users.259.746634089

5 ONLINE +DATA/rac/datafile/undotbs2.264.746634255

6 RECOVER +DATA/rac/datafile/dave01.dbf

6 rows selected.

--去ASM 里看下物理文件是否删除掉了：

[oracle@rac1 ~]$ export ORACLE_SID=+ASM1

[oracle@rac1 ~]$ asmcmd

ASMCMD> ls

DATA/

FRA/

ASMCMD> cd DATA

ASMCMD> ls

DAVE/

DB_UNKNowN/

RAC/

ASMCMD> cd RAC

ASMCMD> ls

CONTROLFILE/

DATAFILE/

TEMPFILE/

spfiledave.ora

spfilerac.ora

ASMCMD> cd DATAFILE

ASMCMD> ls

SYSAUX.257.746634087

SYstem.256.746634087

UNDOTBS1.258.746634089

UNDOTBS2.264.746634255

USERS.259.746634089

dave01.dbf

--对应的物理文件dave02.dbf 已经被删除了

我们将datafile 6 online 看看：

sql> alter database datafile 6 online;

alter database datafile 6 online

ERROR at line 1:

ORA-01113: file 6 needs media recovery

ORA-01110: data file 6: ''+DATA/rac/datafile/dave01.dbf''

--提示需要recover。这也就是需要归档文件的原因。

sql> recover datafile 6;

Media recovery complete.

sql> alter database datafile 6 online;

Database altered.

sql> select file#,status,name from v$datafile;

FILE# STATUS NAME

---------- ------- -------------------------------------------------------------

1 SYstem +DATA/rac/datafile/system.256.746634087

2 ONLINE +DATA/rac/datafile/undotbs1.258.746634089

3 ONLINE +DATA/rac/datafile/sysaux.257.746634087

4 ONLINE +DATA/rac/datafile/users.259.746634089

5 ONLINE +DATA/rac/datafile/undotbs2.264.746634255

6 ONLINE +DATA/rac/datafile/dave01.dbf

6 rows selected.

最后把整个表空间dave drop 掉：

sql> drop tablespace dave including contents and datafiles;

Tablespace dropped.

sql> select file#,status,name from v$datafile;

FILE# STATUS NAME

---------- ------- -------------------------------------------------------------

1 SYstem +DATA/rac/datafile/system.256.746634087

2 ONLINE +DATA/rac/datafile/undotbs1.258.746634089

3 ONLINE +DATA/rac/datafile/sysaux.257.746634087

4 ONLINE +DATA/rac/datafile/users.259.746634089

5 ONLINE +DATA/rac/datafile/undotbs2.264.746634255

去ASM里看一下：

ASMCMD> ls

SYSAUX.257.746634087

SYstem.256.746634087

UNDOTBS1.258.746634089

UNDOTBS2.264.746634255

USERS.259.746634089

对应的物理文件没有了。

alter tablespace test drop datafile 8;

命令不能drop 非空的数据文件，如果要drop 某个数据文件，需要先把对象移除走，等drop 完成后，在移回来。

SELECT owner ownr,

segment_name name,

segment_type TYPE,

extent_id exid,

file_id fiid,

block_id blid,

blocks blks

FROM dba_extents

WHERE file_id = 8

ORDER BY block_id;

alter table temp move tablespace test;

https://blog.csdn.net/tianlesoftware/article/details/6305600

Drop Table 对 MySQL 的性能影响分析

##【作者】王栋：携程技术保障中心数据库专家，对数据库疑难问题的排查和数据库自动化智能化运维工具的开发有强烈的兴趣。

##【问题描述】

最近碰到有台 MySQL 实例出现了 MySQL 服务短暂 hang 死，表现为瞬间的并发线程上升，连接数暴增。排查 Error Log 文件中有 page_cleaner 超时的信息，引起我们的关注:

<pre><code>2019-08-24T23:47:09.361836+08:00 0 [Note] InnoDB: page_cleaner: 1000ms intended loop took 24915ms. The settings might not be optimal. (flushed=182 and evicted=0, during the time.) 2019-08-24T23:47:16.211740+08:00 0 [Note] InnoDB: page_cleaner: 1000ms intended loop took 4849ms. The settings might not be optimal. (flushed=240 and evicted=0, during the time.) 2019-08-24T23:47:23.362286+08:00 0 [Note] InnoDB: page_cleaner: 1000ms intended loop took 6151ms. The settings might not be optimal. (flushed=215 and evicted=0, during the time.) </code></pre>

##【问题分析】

####1、 error log 中 page_cleaner 信息是如何产生的通过源码 storage/innobase/buf/buf0flu.cc 可以看出，当满足 curr_time > next_loop_time + 3000 条件（大于 4 秒）时，会打印上面信息到 error log 中。next_loop_time 为 1000ms，即 1 秒钟做一次刷新页的操作。

<pre><code> if (ret_sleep == OS_SYNC_TIME_EXCEEDED) { ulint curr_time = ut_time_ms(); if (curr_time > next_loop_time + 3000) { if (warn_count == 0) { ib::info() << "page_cleaner: 1000ms" " intended loop took " << 1000 + curr_time - next_loop_time << "ms. The settings might not" " be optimal. (flushed=" << n_flushed_last << " and evicted=" << n_evicted << ", during the time.)"; if (warn_interval > 300) { warn_interval = 600; } else { warn_interval *= 2; } warn_count = warn_interval; } else { --warn_count; } } else { /* reset counter */ warn_interval = 1; warn_count = 0; } next_loop_time = curr_time + 1000; n_flushed_last = n_evicted = 0; } </code></pre>

后半部分 (flushed=182 and evicted=0, during the time.) 日志，对应 n_flushed_last 和 n_evicted 两个变量，这两个变量来自于下面 2 个变量。

<pre><code> n_evicted += n_flushed_lru; n_flushed_last += n_flushed_list;</code></pre>

从源码注释中可以看出，n_flushed_lru 表示从 LRU list 尾部刷新的页数，也就是日志中如 evicted=0 指标的所表示的值。 n_flushed_list：这个是从 flush_list 刷新列表中刷新的页数，也就是脏页数，日志中 flushed=182 的值。

<pre><code>/** Wait until all flush requests are finished. @param n_flushed_lru number of pages flushed from the end of the LRU list. @param n_flushed_list number of pages flushed from the end of the flush_list. @return true if all flush_list flushing batch were success. */ static bool pc_wait_finished( ulint* n_flushed_lru, ulint* n_flushed_list) </code></pre>

从 pc_wait_finished 函数可以看出 page_cleaner 线程包含了 LRU list 和 flush_list 两部分刷新，而且需要等待两部分都完成刷新。

####2、MySQL5.7.4 引入了多线程 page cleaner，但由于 LRU 列表刷新和脏页列表刷新仍然耦合在一起，在遇到高负载，或是热数据的 buffer pool instance 时，仍存在性能问题。 1） LRU List 刷脏在先，Flush list 的刷脏在后，但是是互斥的。也就是说在进 Flush list 刷脏的时候，LRU list 不能继续去刷脏，必须等到下一个循环周期才能进行。 2）另外一个问题是，刷脏的时候，page cleaner coodinator 会等待所有的 page cleaner 线程完成之后才会继续响应刷脏请求。这带来的问题就是如果某个 buffer pool instance 比较热的话，page cleaner 就不能及时进行响应。 Percona 版本对 LRU list 刷脏做了很多优化。

####3、分析问题实例的 binlog 日志，可以看到从 2019-08-24 23:46:15 到 2019-08-24 23:47:25 之间没有记录任何日志，说明这段时间内 mysql 服务无法正常处理请求，短暂 hang 住了 mysqlbinlog -vvv binlog --start-datetime=''2019-08-24 23:46:15'' --stop-datetime=''2019-08-24 23:47:25''|less

从计数器指标可以看出期间并发线程积压，QPS 处理能力下降，稍后 MySQL 服务恢复，积压的请求集中释放，导致并发连接进一步上升

####4、从 Innodb_buffer_pool_pages_misc 和 Innodb_buffer_pool_pages_free 指标来看，在问题时间段 buffer pool 在 1 分钟内集中释放了约 16*(546893-310868)=3776400，3.7G 可用内存。可能期间 LRU list 的 mutex 资源锁定，导致 page cleaner 线程在 LRU list 刷新时阻塞，从而表现出 page_cleaner 线程执行时间过长。

innodb_buffer_pool_pages_misc 与 adaptive hash index 有关，下面是官网的描述

<pre><code>• Innodb_buffer_pool_pages_misc The number of pages in the InnoDB buffer pool that are busy because they have been allocated for administrative overhead, such as row locks or the adaptive hash index. This value can also be calculated as Innodb_buffer_pool_pages_total − Innodb_buffer_pool_pages_free − Innodb_buffer_pool_pages_data. When using compressed tables, Innodb_buffer_pool_pages_misc may report an out-of-bounds value (Bug #59550). </code></pre>

####5、为什么 AHI 短时间内会释放大量的内存呢，通过慢查询日志我们排查到期间有 drop table 的操作，但 drop 的表容量约 50G，并不是很大，drop table 为什么会导致 MySQL 服务短暂 hang 死，它对服务器性能会产生多大的影响，我们做了模拟测试。

##【测试重现过程】

为了进一步验证，我们在测试环境下模拟测试了 drop table 对高并发 MySQL 性能的影响。 1、使用 sysbench 工具做压测，首先在测试环境下创建了 8 张 2 亿条记录的表，单表容量 48G 2、开启 innodb_adaptive_hash_index，用 olap 模板压测 1 个小时，填充目标 8 张表所对应的 AHI 内存 3、再次开启压测线程只对 sbtest1 表做访问，观察 MySQL 的访问情况 4、新建会话运行 drop table test.sbtest2，看到 drop 一张 48G 的表消耗了 64.84 秒 5、用自定义脚本检测每秒 Innodb_buffer_pool_pages_misc 和 Innodb_buffer_pool_pages_free 指标的变化情况，看到在 drop table 期间 Innodb_buffer_pool_pages_misc 大量释放，Innodb_buffer_pool_pages_free 值同时增长，释放和增加的内容总量基本一致，如下图所示 6、drop table 期间，MySQL 处于 hang 死状态，QPS 长时间跌 0

7、errorlog 中也重现了 page_cleaner 的日志信息至此复现了问题现象。

###【为什么 MySQL 会短暂 hang 死】

1、压测期间，抓取了 pstack，show engine innodb status，以及 performance_schema 下 events_waits_summary_global_by_event_name 表中相关 mutex 等现场信息 2、在 SEMAPHORES 相关信息中，可以看到 hang 死期间大量 Thread 请求 S-lock，被同一个线程 140037411514112 持有的锁所阻塞，时间持续了 64 秒

<pre><code>--Thread 140037475792640 has waited at row0purge.cc line 862 for 64.00 seconds the semaphore: S-lock on RW-latch at 0x966f6e38 created in file dict0dict.cc line 1183 a writer (thread id 140037411514112) has reserved it in mode exclusive number of readers 0, waiters flag 1, lock_word: 0 Last time read locked in file row0purge.cc line 862 Last time write locked in file /mysql-5.7.23/storage/innobase/row/row0mysql.cc line 4253 --Thread 140037563102976 has waited at srv0srv.cc line 1982 for 57.00 seconds the semaphore: X-lock on RW-latch at 0x966f6e38 created in file dict0dict.cc line 1183 a writer (thread id 140037411514112) has reserved it in mode exclusive number of readers 0, waiters flag 1, lock_word: 0 Last time read locked in file row0purge.cc line 862 Last time write locked in file /mysql-5.7.23/storage/innobase/row/row0mysql.cc line 4253 </code></pre>

3、通过 ROW OPERATIONS 相关信息，可以看到 MySQL 的 Main Thread 也被同一个线程 140037411514112 阻塞，状态处于 enforcing dict cache limit 状态

<pre><code>3 queries inside InnoDB, 0 queries in queue 17 read views open inside InnoDB Process ID=39257, Main thread ID=140037563102976, state: enforcing dict cache limit Number of rows inserted 1870023456, updated 44052478, deleted 22022445, read 9301843315 0.00 inserts/s, 0.00 updates/s, 0.00 deletes/s, 0.00 reads/s </code></pre>

4、可以看到线程 140037411514112 执行的 SQL 就是 drop table test.sbtest2 语句，说明 drop table 期间持有的锁，阻塞了 Main Thread 及其他线程

<pre><code>---TRANSACTION 44734025, ACTIVE 64 sec dropping table—— 10 lock struct(s), heap size 1136, 7 row lock(s), undo log entries 1 MySQL thread id 440836, OS thread handle 140037411514112, query id 475074428 localhost root checking permissions drop table test.sbtest2</code></pre>

5、下面是抓到的 drop table 的简化后的调用栈信息，对比可以看出，64 秒的时间，drop table 都在执行函数 btr_search_drop_page_hash_index，清空对应的 AHI 记录信息

<pre><code>Thread 32 (Thread 0x7f5d002b2700 (LWP 8156)): \#0 ha_remove_all_nodes_to_page \#1 btr_search_drop_page_hash_index \#2 btr_search_drop_page_hash_when_freed \#3 fseg_free_extent \#4 fseg_free_step \#5 btr_free_but_not_root \#6 btr_free_if_exists \#7 dict_drop_index_tree \#8 row_upd_clust_step \#9 row_upd \#10 row_upd_step \#11 que_thr_step \#12 que_run_threads_low \#13 que_run_threads \#14 que_eval_sql \#15 row_drop_table_for_mysql \#16 ha_innobase::delete_table \#17 ha_delete_table \#18 mysql_rm_table_no_locks \#19 mysql_rm_table \#20 mysql_execute_command \#21 mysql_parse \#22 dispatch_command \#23 do_command \#24 handle_connection \#25 pfs_spawn_thread \#26 start_thread () \#27 clone () </code></pre>

6、通过代码我们可以看到 drop table 调用 row_drop_table_for_mysql 函数时，在 row_mysql_lock_data_dictionary (trx); 位置对元数据加了排它锁

<pre><code>row_drop_table_for_mysql( const char* name, trx_t* trx, bool drop_db, bool nonatomic, dict_table_t* handler) { dberr_t err; dict_foreign_t* foreign; dict_table_t* table = NULL; char* filepath = NULL; char* tablename = NULL; bool locked_dictionary = false; pars_info_t* info = NULL; mem_heap_t* heap = NULL; bool is_intrinsic_temp_table = false; DBUG_ENTER("row_drop_table_for_mysql"); DBUG_PRINT("row_drop_table_for_mysql", ("table: ''%s''", name)); ut_a(name != NULL); /* Serialize data dictionary operations with dictionary mutex: no deadlocks can occur then in these operations */ trx->op_info = "dropping table"; if (handler != NULL && dict_table_is_intrinsic(handler)) { table = handler; is_intrinsic_temp_table = true; } if (table == NULL) { if (trx->dict_operation_lock_mode != RW_X_LATCH) { /* Prevent foreign key checks etc. while we are dropping the table */ row_mysql_lock_data_dictionary(trx); locked_dictionary = true; nonatomic = true; }</code></pre>

7、以 Main Thread 为例，在调用 srv_master_evict_from_table_cache 函数获取 X-lock on RW-latch 时被阻塞

<pre><code>/********************************************************************//** Make room in the table cache by evicting an unused table. @return number of tables evicted. */ static ulint srv_master_evict_from_table_cache( /*==============================*/ ulint pct_check) /*!< in: max percent to check */ { ulint n_tables_evicted = 0; rw_lock_x_lock(dict_operation_lock); dict_mutex_enter_for_mysql(); n_tables_evicted = dict_make_room_in_cache( innobase_get_table_cache_size(), pct_check); dict_mutex_exit_for_mysql(); rw_lock_x_unlock(dict_operation_lock); return(n_tables_evicted); }</code></pre>

8、查看 dict_operation_lock 的注释，create drop table 操作时需要 X 锁，而一些其他后台线程，比如 Main Thread 检查 dict cache 时，也需要获取 dict_operation_lock 的 X 锁，因此被阻塞

<pre><code>/** @brief the data dictionary rw-latch protecting dict_sys table create, drop, etc. reserve this in X-mode; implicit or backround operations purge, rollback, foreign key checks reserve this in S-mode; we cannot trust that MySQL protects implicit or background operations a table drop since MySQL does not know of them; therefore we need this; NOTE: a transaction which reserves this must keep book on the mode in trx_t::dict_operation_lock_mode */ rw_lock_t* dict_operation_lock; </code></pre>

9、期间用户线程由于获取不到锁而处于挂起状态，当无法立刻获得锁时，会调用 row_mysql_handle_errors 将错误码传到上层进行处理

<pre><code>/****************************************************************//* Handles user errors and lock waits detected by the database engine. @return true if it was a lock wait and we should continue running the query thread and in that case the thr is ALREADY in the running state. */ bool row_mysql_handle_errors</code></pre>

下面是简化后的用户线程调用栈信息：

<pre><code>Thread 29 (Thread 0x7f5d001ef700 (LWP 8159)): #0 pthread_cond_wait@@GLIBC_2.3.2 #1 wait #2 os_event::wait_low #3 os_event_wait_low #4 lock_wait_suspend_thread #5 row_mysql_handle_errors #6 row_search_mvcc #7 ha_innobase::index_read #8 handler::ha_index_read_map #9 handler::read_range_first #10 handler::multi_range_read_next #11 QUICK_RANGE_SELECT::get_next #12 rr_quick #13 mysql_update #14 Sql_cmd_update::try_single_table_update #15 Sql_cmd_update::execute #16 mysql_execute_command #17 mysql_parse #18 dispatch_command #19 do_command #20 handle_connection #21 pfs_spawn_thread #22 start_thread #23 clone</code></pre>

10、page_cleaner 后台线程没有抓到明显的阻塞关系，只看到如下正常的调用栈信息

<pre><code>Thread 55 (Thread 0x7f5c7fe15700 (LWP 39287)): \#0 pthread_cond_timedwait@@GLIBC_2.3.2 () \#1 os_event::timed_wait \#2 os_event::wait_time_low \#3 os_event_wait_time_low \#4 pc_sleep_if_needed \#5 buf_flush_page_cleaner_coordinator \#6 start_thread \#7 clone Thread 54 (Thread 0x7f5c7f614700 (LWP 39288)): \#0 pthread_cond_wait@@GLIBC_2.3.2 () \#1 wait \#2 os_event::wait_low \#3 os_event_wait_low \#4 buf_flush_page_cleaner_worker \#5 start_thread \#6 clone</code></pre>

##【结论 & 解决思路】

drop table 引起的 MySQL 短暂 hang 死的问题，是由于 drop 一张使用 AHI 空间较大的表时，调用执行 AHI 的清理动作，会消耗较长时间，执行期间长时间持有 dict_operation_lock 的 X 锁，阻塞了其他后台线程和用户线程；drop table 执行结束锁释放，MySQL 积压的用户线程集中运行，出现了并发线程和连接数瞬间上升的现象。规避问题的方法，可以考虑在 drop table 前关闭 AHI。

原文出处：https://www.cnblogs.com/CtripDBA/p/11465315.html

DROP 表正在为元数据锁定 MYSQL 提供状态等待

如何解决DROP 表正在为元数据锁定 MYSQL 提供状态等待

我正在尝试删除一个包含 1M 行的表，但它需要很长时间，所以当我尝试运行时

SHOW PROCCESSLIST;

我发现它正在等待获取锁这是输出

--------------------------------------+
| Id | User            | Host            | db     | Command | Time   | State                           | Info                                                                                                 |
+----+-----------------+-----------------+--------+---------+--------+---------------------------------+------------------------------------------------------------------------------------------------------+
|  5 | event_scheduler | localhost       | NULL   | Daemon  | 254322 | Waiting on empty queue          | NULL                                                                                                 |
| 76 | root            | localhost:53735 | NULL   | Sleep   |  10117 |                                 | NULL                                                                                                 |
| 77 | root            | localhost:53736 | noodle | Sleep   |  10115 |                                 | NULL                                                                                                 |
| 81 | root            | localhost:52690 | noodle | Query   |   2731 | Waiting for table Metadata lock | Drop TABLE indexedurls                                                                               |
| 83 | nodeuser        | localhost:64957 | noodle | Query   |   1303 | Waiting for table Metadata lock | SELECT COUNT(*) as numberOfURLs from indexedurls where word = ''imdb''                                 |
| 84 | root            | localhost:54714 | NULL   | Sleep   |   4100 |                                 | NULL                                                                                                 |
| 85 | root            | localhost:54715 | noodle | Killed  |   4062 | query end                       | delete from indexedurls                                                                              |
| 89 | root            | localhost:59492 | noodle | Query   |      0 | init                            | SHOW PROCESSLIST                                                                                     |
| 98 | noodleadmin     | localhost:56596 | noodle | Query   |      4 | update                          | INSERT IGnorE INTO indexedUrlstest (url,word,tf,snippet) VA

关于mysql 案例～关于 drop 的那点事和mysql中drop的用法的问题就给大家分享到这里，感谢你花时间阅读本站内容，更多关于A2-03-12.DDL-MySQL DROP COLUMN、alter database datafile offline drop 与 alter tablespace drop datafile 区别、Drop Table 对 MySQL 的性能影响分析、DROP 表正在为元数据锁定 MYSQL 提供状态等待等相关知识的信息别忘了在本站进行查找喔。

本文标签：
