log-bin=mysql-bin #添加这一行就ok
binlog-format=ROW #选择row模式
server_id=1 #配置mysql replaction需要定义，不能和canal的slaveId重复

drop user ''canal''@''%'';
CREATE USER ''canal''@''%'' IDENTIFIED BY ''canal'';
grant all privileges on *.* to ''canal''@''%'' identified by ''canal'';
flush privileges;

@echo off
REM Licensed to the Apache Software Foundation (ASF) under one or more
REM contributor license agreements.  See the NOTICE file distributed with
REM this work for additional information regarding copyright ownership.
REM The ASF licenses this file to You under the Apache License, Version 2.0
REM (the "License"); you may not use this file except in compliance with
REM the License.  You may obtain a copy of the License at
REM
REM     http://www.apache.org/licenses/LICENSE-2.0
REM
REM Unless required by applicable law or agreed to in writing, software
REM distributed under the License is distributed on an "AS IS" BASIS,
REM WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
REM See the License for the specific language governing permissions and
REM limitations under the License.

setlocal
call "%~dp0zkEnv.cmd"

set ZOOMAIN=org.apache.zookeeper.server.quorum.QuorumPeerMain
echo on
java "-Dzookeeper.log.dir=%ZOO_LOG_DIR%" "-Dzookeeper.root.logger=%ZOO_LOG4J_PROP%" -cp "%CLASSPATH%" %ZOOMAIN% "%ZOOCFG%" %*

endlocal
pause

<!-- springBoot集成kafka -->
        <dependency>
            <groupId>org.springframework.kafka</groupId>
            <artifactId>spring-kafka</artifactId>
        </dependency>
        <!-- SpringBoot整合Web组件 -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>fastjson</artifactId>
            <version>1.2.62</version>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-redis</artifactId>
        </dependency>

# kafka
spring:
  kafka:
    # kafka服务器地址(可以多个)
    bootstrap-servers: 127.0.0.1:9092
    consumer:
      # 指定一个默认的组名
      group-id: kafka2
      # earliest:当各分区下有已提交的offset时，从提交的offset开始消费；无提交的offset时，从头开始消费
      # latest:当各分区下有已提交的offset时，从提交的offset开始消费；无提交的offset时，消费新产生的该分区下的数据
      # none:topic各分区都存在已提交的offset时，从offset后开始消费；只要有一个分区不存在已提交的offset，则抛出异常
      auto-offset-reset: earliest
      # key/value的反序列化
      key-deserializer: org.apache.kafka.common.serialization.StringDeserializer
      value-deserializer: org.apache.kafka.common.serialization.StringDeserializer
    producer:
      # key/value的序列化
      key-serializer: org.apache.kafka.common.serialization.StringSerializer
      value-serializer: org.apache.kafka.common.serialization.StringSerializer
      # 批量抓取
      batch-size: 65536
      # 缓存容量
      buffer-memory: 524288
  redis:
    host: 1.1.1.1
#    password:
    port: 6379
    database: 10
    password: 123456

@Component
public class RedisUtils {

    /**
     * 获取我们的redis模版
     */
    @Autowired
    private StringRedisTemplate stringRedisTemplate;


    public void setString(String key, String value) {
        setString(key, value, null);
    }

    public void setString(String key, String value, Long timeOut) {
        stringRedisTemplate.opsForValue().set(key, value);
        if (timeOut != null) {
            stringRedisTemplate.expire(key, timeOut, TimeUnit.SECONDS);
        }
    }


    public String getString(String key) {
        return stringRedisTemplate.opsForValue().get(key);
    }

    /**
     * redis当成数据库中
     * <p>
     * 注意事项：对我们的redis的key设置一个有效期
     */

    public boolean deleteKey(String key) {
        return stringRedisTemplate.delete(key);
    }


}

@KafkaListener(topics = "maikt-topic")
    public void receive(ConsumerRecord<?, ?> consumer) {
        System.out.println("topic名称:" + consumer.topic() + ",key:" +
                consumer.key() + "," +
                "分区位置:" + consumer.partition()
                + ", 下标" + consumer.offset() + "," + consumer.value());

        String json = (String) consumer.value();
        JSONObject jsonObject = JSONObject.parseObject(json);
        String sqlType = jsonObject.getString("type");
        JSONArray data = jsonObject.getJSONArray("data");
        if(data!=null)
        {
            JSONObject userObject = data.getJSONObject(0);
            String id = userObject.getString("id");
            String database = jsonObject.getString("database");
            String table = jsonObject.getString("table");
            String key = database + "_" + table + "_" + id;
            if ("UPDATE".equals(sqlType) || "INSERT".equals(sqlType)) {
                redisUtils.setString(key, userObject.toJSONString());
                return;
            }
            if ("DELETE".equals(sqlType)) {
                redisUtils.deleteKey(key);
            }
        }



    }

[root@localhost software]# mkdir canal
[root@localhost software]# cd canal/
[root@localhost canal]# rz
rz waiting to receive.
?a? zmodem ′??.  °′ Ctrl+C ??.
Transferring canal.deployer-1.1.5-SNAPSHOT.tar.gz...
  100%   51102 KB 8517 KB/s 00:00:06       0 ′?

?[root@localhost canal]# tar -zxvf canal.deployer-1.1.5-SNAPSHOT.tar.gz

#配置好mysql的数据库地址和帐号密码
#canal.instance.master.address=127.0.0.1:3306
#canal.instance.dbUsername=root
#canal.instance.dbPassword=root
[root@localhost canal]# vi conf/example/instance.properties
[root@localhost canal]# ./bin/startup.sh
#看到successful表示启动成功
[root@localhost canal]# cat logs/example/example.log
2020-03-15 22:45:07.762 [main] INFO  c.a.o.c.i.spring.support.PropertyPlaceholderConfigurer - Loading properties file from class path resource [canal.properties]
2020-03-15 22:45:07.765 [main] INFO  c.a.o.c.i.spring.support.PropertyPlaceholderConfigurer - Loading properties file from class path resource [example/instance.properties]
2020-03-15 22:45:07.905 [main] WARN  o.s.beans.GenericTypeAwarePropertyDescriptor - Invalid JavaBean property ''connectionCharset'' being accessed! Ambiguous write methods found next to actually used [public void com.alibaba.otter.canal.parse.inbound.mysql.AbstractMysqlEventParser.setConnectionCharset(java.lang.String)]: [public void com.alibaba.otter.canal.parse.inbound.mysql.AbstractMysqlEventParser.setConnectionCharset(java.nio.charset.Charset)]
2020-03-15 22:45:07.934 [main] INFO  c.a.o.c.i.spring.support.PropertyPlaceholderConfigurer - Loading properties file from class path resource [canal.properties]
2020-03-15 22:45:07.935 [main] INFO  c.a.o.c.i.spring.support.PropertyPlaceholderConfigurer - Loading properties file from class path resource [example/instance.properties]
2020-03-15 22:45:08.270 [main] INFO  c.a.otter.canal.instance.spring.CanalInstanceWithSpring - start CannalInstance for 1-example
2020-03-15 22:45:08.276 [main] WARN  c.a.o.canal.parse.inbound.mysql.dbsync.LogEventConvert - --> init table filter : ^.*\..*$
2020-03-15 22:45:08.276 [main] WARN  c.a.o.canal.parse.inbound.mysql.dbsync.LogEventConvert - --> init table black filter :
2020-03-15 22:45:08.282 [main] INFO  c.a.otter.canal.instance.core.AbstractCanalInstance - start successful....
2020-03-15 22:45:08.345 [destination = example , address = /127.0.0.1:3306 , EventParser] WARN  c.a.o.c.p.inbound.mysql.rds.RdsBinlogEventParserProxy - ---> begin to find start position, it will be long time for reset or first position
2020-03-15 22:45:08.345 [destination = example , address = /127.0.0.1:3306 , EventParser] WARN  c.a.o.c.p.inbound.mysql.rds.RdsBinlogEventParserProxy - prepare to find start position just show master status
2020-03-15 22:45:08.937 [destination = example , address = /127.0.0.1:3306 , EventParser] WARN  c.a.o.c.p.inbound.mysql.rds.RdsBinlogEventParserProxy - ---> find start position successfully, EntryPosition[included=false,journalName=mysql-bin.000001,position=4,serverId=1,gtid=<null>,timestamp=1584282800000] cost : 582ms , the next step is binlog dump

<dependencies>
    <dependency>
        <groupId>com.alibaba.otter</groupId>
        <artifactId>canal.client</artifactId>
        <version>1.1.0</version>
    </dependency>
    <dependency>
        <groupId>redis.clients</groupId>
        <artifactId>jedis</artifactId>
        <version>2.9.0</version>
    </dependency>
</dependencies>

import com.alibaba.fastjson.JSONObject;
import com.alibaba.otter.canal.client.CanalConnector;
import com.alibaba.otter.canal.client.CanalConnectors;
import com.alibaba.otter.canal.protocol.CanalEntry.*;
import com.alibaba.otter.canal.protocol.Message;

import java.net.InetSocketAddress;
import java.util.List;


public class CanalClient {

    public static void main(String args[]) {
        CanalConnector connector = CanalConnectors.newSingleConnector(new InetSocketAddress("127.0.0.1",
                11111), "example", "", "");
        int batchSize = 100;
        try {
            connector.connect();
            connector.subscribe("user.users");
            connector.rollback();
            while (true) {
                // 获取指定数量的数据
                Message message = connector.getWithoutAck(batchSize);
                long batchId = message.getId();
                int size = message.getEntries().size();
                System.out.println("batchId = " + batchId);
                System.out.println("size = " + size);
                if (batchId == -1 || size == 0) {
                    try {
                        Thread.sleep(1000);
                    } catch (InterruptedException e) {
                        e.printStackTrace();
                    }
                } else {
                    printEntry(message.getEntries());
                }
                // 提交确认
                connector.ack(batchId);
                // connector.rollback(batchId); // 处理失败, 回滚数据
            }
        } finally {
            connector.disconnect();
        }
    }

    private static void printEntry(List<Entry> entrys) {
        for (Entry entry : entrys) {
            if (entry.getEntryType() == EntryType.TRANSACTIONBEGIN || entry.getEntryType() == EntryType.TRANSACTIONEND) {
                continue;
            }
            RowChange rowChage = null;
            try {
                rowChage = RowChange.parseFrom(entry.getStoreValue());
            } catch (Exception e) {
                throw new RuntimeException("ERROR ## parser of eromanga-event has an error , data:" + entry.toString(),
                        e);
            }
            EventType eventType = rowChage.getEventType();
            System.out.println(String.format("================> binlog[%s:%s] , name[%s,%s] , eventType : %s",
                    entry.getHeader().getLogfileName(), entry.getHeader().getLogfileOffset(),
                    entry.getHeader().getSchemaName(), entry.getHeader().getTableName(),
                    eventType));

            for (RowData rowData : rowChage.getRowDatasList()) {
                if (eventType == EventType.DELETE) {
                    redisDelete(rowData.getBeforeColumnsList());
                } else if (eventType == EventType.INSERT) {
                    redisInsert(rowData.getAfterColumnsList());
                } else {
                    System.out.println("-------> before");
                    printColumn(rowData.getBeforeColumnsList());
                    System.out.println("-------> after");
                    redisUpdate(rowData.getAfterColumnsList());
                }
            }
        }
    }

    private static void printColumn(List<Column> columns) {
        for (Column column : columns) {
            System.out.println(column.getName() + " : " + column.getValue() + "    update=" + column.getUpdated());
        }
    }

    private static void redisInsert(List<Column> columns) {
        JSONObject json = new JSONObject();
        for (Column column : columns) {
            json.put(column.getName(), column.getValue());
        }
        if (columns.size() > 0) {
            RedisUtil.stringSet(columns.get(0).getValue(), json.toJSONString());
        }
    }

    private static void redisUpdate(List<Column> columns) {
        JSONObject json = new JSONObject();
        for (Column column : columns) {
            json.put(column.getName(), column.getValue());
        }
        if (columns.size() > 0) {
            RedisUtil.stringSet(columns.get(0).getValue(), json.toJSONString());
        }
    }

    private static void redisDelete(List<Column> columns) {
        JSONObject json = new JSONObject();
        for (Column column : columns) {
            json.put(column.getName(), column.getValue());
        }
        if (columns.size() > 0) {
            RedisUtil.delKey(columns.get(0).getValue());
        }
    }
}

import redis.clients.jedis.Jedis;

public class RedisUtil {

    private static Jedis jedis = null;

    public static synchronized Jedis getJedis() {
        if (jedis == null) {
            jedis = new Jedis("127.0.0.1", 6379);
        }
        return jedis;
    }

    public static boolean existKey(String key) {
        return getJedis().exists(key);
    }

    public static void delKey(String key) {
        getJedis().del(key);
    }

    public static String stringGet(String key) {
        return getJedis().get(key);
    }

    public static String stringSet(String key, String value) {
        return getJedis().set(key, value);
    }

    public static void hashSet(String key, String field, String value) {
        getJedis().hset(key, field, value);
    }
}
