窗体上需要 TImage、TOpenDialog 和六个按钮.

---

unit Unit1;

interface

uses
  System.SysUtils, System.Types, System.UITypes, System.Classes, System.Variants,
  FMX.Types, FMX.Controls, FMX.Forms, FMX.Dialogs, FMX.Objects;

type
  TForm1 = class(TForm)
    Image1: TImage;
    OpenDialog1: TOpenDialog;
    Button1: TButton;
    Button2: TButton;
    Button3: TButton;
    Button4: TButton;
    Button5: TButton;
    Button6: TButton;
    procedure FormCreate(Sender: TObject);
    procedure FormDestroy(Sender: TObject);
    procedure Button1Click(Sender: TObject);
    procedure Button2Click(Sender: TObject);
    procedure Button3Click(Sender: TObject);
    procedure Button4Click(Sender: TObject);
    procedure Button5Click(Sender: TObject);
    procedure Button6Click(Sender: TObject);
  end;

var
  Form1: TForm1;

implementation

{$R *.fmx}

uses FMX.Filter;

var
  bit: TBitmap;

procedure TForm1.FormCreate(Sender: TObject);
begin
  bit := TBitmap.Create(0, 0);
  if not OpenDialog1.Execute then Exit;
  bit.LoadFromFile(OpenDialog1.FileName);
  Image1.Bitmap.Assign(bit);
  Image1.SetBounds(10, 10, bit.Width, bit.Height);
end;

procedure TForm1.FormDestroy(Sender: TObject);
begin
  bit.Free;
end;

{高斯模糊: 一个参数}
procedure TForm1.Button1Click(Sender: TObject);
var
  filter: TFilter;
begin
  filter := FilterByName(''GaussianBlur'');           //GaussianBlur 是高斯模糊滤镜的名称
  filter.Values[''BlurAmount''] := 0.25;              //BlurAmount 是高斯模糊参数的名称, 默认值是 1(0.1..10)
  filter.ValuesAsBitmap[''input''] := bit;            //input  是给输入图片约定的索引名称, 不区分大小写
  Image1.Bitmap := filter.ValuesAsBitmap[''output'']; //output 是给输出图片约定的索引名称
end;

{颜色翻转: 无参数}
procedure TForm1.Button2Click(Sender: TObject);
var
  filter: TFilter;
begin
  filter := FilterByName(''Invert'');       //颜色翻转
  filter.ValuesAsBitmap[''input''] := bit;
  Image1.Bitmap := filter.ValuesAsBitmap[''output''];
end;

{灰度: 无参数}
procedure TForm1.Button3Click(Sender: TObject);
var
  filter: TFilter;
begin
  filter := FilterByName(''Monochrome'');
  filter.ValuesAsBitmap[''input''] := bit;
  Image1.Bitmap := filter.ValuesAsBitmap[''output''];
end;

{马赛克: 一个参数}
procedure TForm1.Button4Click(Sender: TObject);
var
  filter: TFilter;
begin
  filter := FilterByName(''Pixelate'');
  filter.Values[''BlockCount''] := 30; {25 : 1..1000}
  filter.ValuesAsBitmap[''input''] := bit;
  Image1.Bitmap := filter.ValuesAsBitmap[''output''];
end;

{对比度: 两个参数}
procedure TForm1.Button5Click(Sender: TObject);
var
  filter: TFilter;
begin
  filter := FilterByName(''Contrast'');
  filter.Values[''Brightness''] := -0.5; {-1..1}
  filter.Values[''Contrast'']   := 1.5;  {0..2}
  filter.ValuesAsBitmap[''input''] := bit;
  Image1.Bitmap := filter.ValuesAsBitmap[''output''];
end;

{透视: 参数是四个点}
procedure TForm1.Button6Click(Sender: TObject);
var
  filter: TFilter;
begin
  filter := FilterByName(''PerspectiveTransform'');
  filter.Values[''TopLeft''] := VarFromPointXY(0, 0);
  filter.Values[''TopRight''] := VarFromPointXY(bit.Width, 0);
  filter.Values[''BottomRight''] := VarFromPointXY(bit.Width * 2, bit.Height * 2);
  filter.Values[''BottomLeft''] := VarFromPointXY(0, bit.Height);
  filter.ValuesAsBitmap[''input''] := bit;
  Image1.Bitmap := filter.ValuesAsBitmap[''output''];
  Image1.SetBounds(10, 10, bit.Width * 2, bit.Height * 2);
end;

end.

---

Transition 分类的滤镜需要两张图片:

---

uses FMX.Filter;

var
  bit1,bit2: TBitmap;

{百叶窗效果}
procedure TForm1.FormCreate(Sender: TObject);
var
  filter: TFilter;
begin
  bit1 := TBitmap.Create(0, 0);
  bit2 := TBitmap.Create(0, 0);
  bit1.LoadFromFile(''C:\Temp\test1.jpg'');
  bit2.LoadFromFile(''C:\Temp\test2.jpg'');

  filter := FilterByName(''BlindTransition'');
  filter.Values[''Progress''] := 50;       //变换进度: 0..100; 当以此进度做动画时, PropertyName := ''Value''
  filter.Values[''NumberOfBlinds''] := 10; //分叶数: 2..15

  filter.ValuesAsBitmap[''input''] := bit1;
  filter.ValuesAsBitmap[''target''] := bit2; //target 也是约定的索引名称
  Image1.Bitmap := filter.ValuesAsBitmap[''output''];
  Image1.SetBounds(10, 10, bit1.Width, bit1.Height);
end;

procedure TForm1.FormDestroy(Sender: TObject);
begin
  bit1.Free;
  bit2.Free;
end;

---

Delphi XE2 之 FireMonkey 入门 (2)

FireMonkey 的控件都是自己绘制的 (而不是基于系统组件), 我想它们应该是基于一些基本图形；就从基本图形开始吧.

FMX.Objects 单元给出的类:

---

TShape //基本图形的基类
TLine
TRectangle
TRoundRect
TCalloutRectangle
TEllipse
TCircle
TPie
TArc
TPath
TText

TImage
TPaintBox
TSelection
TSelectionPoint

---

添加一个 TRectangle, 先纵观一下它的可用功能:

---

{ TRectangle }
  public
    constructor Create(AOwner: TComponent); override;
  published
    property Fill;
    property Stroke;
    property StrokeCap;
    property StrokeDash;
    property StrokeJoin;
    property StrokeThickness;
    property XRadius: Single read FXRadius write SetXRadius;
    property YRadius: Single read FYRadius write SetYRadius;
    property Corners: TCorners read FCorners write SetCorners stored IsCornersStored;
    property CornerType: TCornerType read FCornerType write SetCornerType default TCornerType.ctRound;
    property Sides: TSides read FSides write SetSides stored IsSidesStored;

{ TRectangle 的父类 TShape }
  protected
    procedure FillChanged(Sender: TObject); virtual;
    procedure StrokeChanged(Sender: TObject); virtual;
    function GetShapeRect: TRectF;
    procedure Painting; override;
    procedure AfterPaint; override;
  public
    constructor Create(AOwner: TComponent); override;
    destructor Destroy; override;
    property Fill: TBrush read FFill write SetFill;
    property Stroke: TBrush read FStroke write SetStroke;
    property StrokeThickness: Single read FStrokeThickness write SetStrokeThickness stored IsStrokeThicknessStored;
    property StrokeCap: TStrokeCap read FStrokeCap write SetStrokeCap default TStrokeCap.scFlat;
    property StrokeDash: TStrokeDash read FStrokeDash write SetStrokeDash default TStrokeDash.sdSolid;
    property StrokeJoin: TStrokeJoin read FStrokeJoin write SetStrokeJoin default TStrokeJoin.sjMiter;
    property ShapeRect: TRectF read GetShapeRect;

{ TShape 的父类 TControl(来自 FMX.Types) }
  public
    constructor Create(AOwner: TComponent); override;
    destructor Destroy; override;
    procedure AddObject(AObject: TFmxObject); override;
    procedure RemoveObject(AObject: TFmxObject); override;
    procedure SetNewScene(AScene: IScene); virtual;
    procedure SetBounds(X, Y, AWidth, AHeight: Single); virtual;
    { matrix }
    function AbsoluteToLocal(P: TPointF): TPointF; virtual;
    function LocalToAbsolute(P: TPointF): TPointF; virtual;
    function AbsoluteToLocalVector(P: TVector): TVector; virtual;
    function LocalToAbsoluteVector(P: TVector): TVector; virtual;
    function PointInObject(X, Y: Single): Boolean; virtual;
    { optimizations }
    procedure RecalcUpdateRect; virtual;
    procedure RecalcNeedAlign; virtual;
    procedure RecalcOpacity; virtual;
    procedure RecalcAbsolute; virtual;
    procedure RecalcEnabled; virtual;
    procedure RecalcHasEffect; virtual;
    { drag and drop }
    function MakeScreenshot: TBitmap;
    { caret }
    procedure ShowCaretProc;
    procedure SetCaretPos(const APoint: TPointF);
    procedure SetCaretSize(const ASize: TPointF);
    procedure SetCaretColor(const AColor: TAlphaColor);
    procedure HideCaret;
    { align }
    procedure BeginUpdate; virtual;
    procedure EndUpdate; virtual;
    procedure Realign; virtual;
    { paining }
    procedure ApplyEffect;
    procedure Painting; virtual;
    procedure DoPaint; virtual;
    procedure AfterPaint; virtual;
    { effects }
    procedure UpdateEffects;
    { }
    procedure SetFocus;
    procedure PaintTo(const ACanvas: TCanvas; const ARect: TRectF; const AParent: TFmxObject = nil);
    procedure Repaint;
    procedure InvalidateRect(ARect: TRectF);
    procedure Lock;
    property AbsoluteMatrix: TMatrix read GetAbsoluteMatrix;
    property AbsoluteOpacity: Single read GetAbsoluteOpacity;
    property AbsoluteWidth: Single read GetAbsoluteWidth;
    property AbsoluteHeight: Single read GetAbsoluteHeight;
    property AbsoluteScale: TPointF read GetAbsoluteScale;
    property AbsoluteEnabled: Boolean read GetAbsoluteEnabled;
    property HasEffect: Boolean read GetAbsoluteHasEffect;
    property HasDisablePaintEffect: Boolean read GetAbsoluteHasDisablePaintEffect;
    property HasAfterPaintEffect: Boolean read GetAbsoluteHasAfterPaintEffect;
    property ChildrenRect: TRectF read GetChildrenRect;
    property InvertAbsoluteMatrix: TMatrix read GetInvertAbsoluteMatrix;
    property InPaintTo: Boolean read FInPaintTo;
    property LocalRect: TRectF read GetLocalRect;
    property AbsoluteRect: TRectF read GetAbsoluteRect;
    property UpdateRect: TRectF read GetUpdateRect;
    property BoundsRect: TRectF read GetBoundsRect write SetBoundsRect;
    property ParentedRect: TRectF read GetParentedRect;
    property ParentedVisible: Boolean read GetParentedVisible;
    property ClipRect: TRectF read GetClipRect;
    property Canvas: TCanvas read GetCanvas;
    property Scene: IScene read FScene;
    property AutoCapture: Boolean read FAutoCapture write FAutoCapture default False;
    property CanFocus: Boolean read FCanFocus write FCanFocus default False;
    property DisableFocusEffect: Boolean read FDisableFocusEffect write FDisableFocusEffect default False;
    property DisableDefaultAlign: Boolean read FDisableDefaultAlign write FDisableDefaultAlign;
    property TabOrder: TTabOrder read GetTabOrder write SetTabOrder default -1;
  published
    { triggers }
    property IsMouseOver: Boolean read FIsMouseOver;
    property IsDragOver: Boolean read FIsDragOver;
    property IsFocused: Boolean read FIsFocused;
    property IsVisible: Boolean read FVisible;
    { props }
    property Align: TAlignLayout read FAlign write SetAlign default TAlignLayout.alNone;
    property Cursor: TCursor read GetCursor write SetCursor default crDefault;
    property DragMode: TDragMode read GetDragMode write SetDragMode default TDragMode.dmManual;
    property EnableDragHighlight: Boolean read FEnableDragHighlight write FEnableDragHighlight default True;
    property Enabled: Boolean read FEnabled write SetEnabled default True;
    property Position: TPosition read FPosition write SetPosition;
    property RotationAngle: Single read FRotationAngle write SetRotationAngle;
    property RotationCenter: TPosition read FRotationCenter write FRotationCenter;
    property Locked: Boolean read FLocked write SetLocked default False;
    property Width: Single read FWidth write SetWidth;
    property Height: Single read FHeight write SetHeight;
    property Margins: TBounds read FMargins write FMargins;
    property Padding: TBounds read FPadding write FPadding;
    property Opacity: Single read FOpacity write SetOpacity stored IsOpacityStored;
    property ClipChildren: Boolean read FClipChildren write SetClipChildren default False;
    property ClipParent: Boolean read FClipParent write FClipParent default False;
    property HitTest: Boolean read FHitTest write SetHitTest default True;
    property CanClip: Boolean read FCanClip write FCanClip default True;
    property PopupMenu: TCustomPopupMenu read FPopupMenu write SetPopupMenu;
    property Scale: TPosition read FScale write FScale;
    property Visible: Boolean read FVisible write SetVisible default True;
    property DesignVisible: Boolean read FDesignVisible write SetDesignVisible default True;
    property OnDragEnter: TDragEnterEvent read FOnDragEnter write FOnDragEnter;
    property OnDragLeave: TNotifyEvent read FOnDragLeave write FOnDragLeave;
    property OnDragOver: TDragOverEvent read FOnDragOver write FOnDragOver;
    property OnDragDrop: TDragDropEvent read FOnDragDrop write FOnDragDrop;
    property OnDragEnd: TNotifyEvent read FOnDragEnd write FOnDragEnd;
    property OnKeyDown: TKeyEvent read FOnKeyDown write FOnKeyDown;
    property OnKeyUp: TKeyEvent read FOnKeyUp write FOnKeyUp;
    property OnClick: TNotifyEvent read FOnClick write FOnClick;
    property OnDblClick: TNotifyEvent read FOnDblClick write FOnDblClick;
    property OnCanFocus: TCanFocusEvent read FOnCanFocus write FOnCanFocus;
    property OnEnter: TNotifyEvent read FOnEnter write FOnEnter;
    property OnExit: TNotifyEvent read FOnExit write FOnExit;
    property OnMouseDown: TMouseEvent read FOnMouseDown write FOnMouseDown;
    property OnMouseMove: TMouseMoveEvent read FOnMouseMove write FOnMouseMove;
    property OnMouseUp: TMouseEvent read FOnMouseUp write FOnMouseUp;
    property OnMouseWheel: TMouseWheelEvent read FOnMouseWheel write FOnMouseWheel;
    property OnMouseEnter: TNotifyEvent read FOnMouseEnter write FOnMouseEnter;
    property OnMouseLeave: TNotifyEvent read FOnMouseLeave write FOnMouseLeave;
    property OnPainting: TOnPaintEvent read FOnPainting write FOnPainting;
    property OnPaint: TOnPaintEvent read FOnPaint write FOnPaint;
    property OnResize: TNotifyEvent read FOnResize write FOnResize;
    property OnApplyStyleLookup: TNotifyEvent read FOnApplyStyleLookup write FOnApplyStyleLookup;

{ TControl 的父类 TFmxObject (来自 FMX.Types) }
  public
    constructor Create(AOwner: TComponent); override;
    destructor Destroy; override;
    procedure Release(Delay: Single = 0.1);
    { check for support interface }
    function IsIControl: Boolean;
    function AsIControl: IControl;
    procedure SetRoot(ARoot: IRoot);
    { design }
    procedure SetDesign(Value: Boolean; SetChildren: Boolean = True);
    function ItemClass: string; virtual;
    { clone }
    function Clone(const AOwner: TComponent): TFmxObject;
    procedure CloneChildFromStream(AStream: TStream);
    { childs }
    procedure AddObject(AObject: TFmxObject); virtual;
    procedure InsertObject(Index: Integer; AObject: TFmxObject); virtual;
    procedure RemoveObject(AObject: TFmxObject); overload; virtual;
    procedure RemoveObject(Index: Integer); overload; virtual;
    procedure Exchange(AObject1, AObject2: TFmxObject); virtual;
    procedure DeleteChildren; virtual;
    procedure BringToFront;
    procedure SendToBack;
    procedure AddObjectsToList(const AList: TList);
    procedure AddControlsToList(const AList: TList);
    procedure Sort(Compare: TFmxObjectSortCompare); virtual;
    { notify }
    procedure AddFreeNotify(const AObject: IFreeNotification);
    procedure RemoveFreeNotify(const AObject: IFreeNotification);
    { tab }
    procedure GetTabOrderList(const List: TList; AChildren: Boolean);
    { i/o }
    procedure LoadFromStream(const AStream: TStream);
    procedure SaveToStream(const Stream: TStream);
    procedure LoadFromBinStream(const AStream: TStream);
    procedure SaveToBinStream(const AStream: TStream);
    { resource }
    function FindStyleResource(const AStyleLookup: string): TFmxObject; virtual;
    procedure UpdateStyle; virtual;
    { animations }
    procedure StartAnimation(const AName: string); virtual;
    procedure StopAnimation(const AName: string); virtual;
    procedure StartTriggerAnimation(AInstance: TFmxObject; const ATrigger: string); virtual;
    procedure StartTriggerAnimationWait(AInstance: TFmxObject; const ATrigger: string); virtual;
    procedure StopTriggerAnimation(AInstance: TFmxObject); virtual;
    procedure ApplyTriggerEffect(AInstance: TFmxObject; const ATrigger: string); virtual;
    { animation property }
    procedure AnimateFloat(const APropertyName: string; const NewValue: Single; Duration: ...);
    procedure AnimateColor(const APropertyName: string; NewValue: TAlphaColor; Duration: ...);
    procedure AnimateFloatDelay(const APropertyName: string; const NewValue: Single; Duration: ...);
    procedure AnimateFloatWait(const APropertyName: string; const NewValue: Single; Duration: ...);
    procedure StopPropertyAnimation(const APropertyName: string);
    { }
    property Root: IRoot read FRoot;
    property Stored: Boolean read FStored write SetStored;
    { }
    property TagObject: TObject read FTagObject write FTagObject;
    property TagFloat: Single read FTagFloat write FTagFloat;
    property TagString: string read FTagString write FTagString;
    { children }
    property ChildrenCount: Integer read GetChildrenCount;
    property Children[Index: Integer]: TFmxObject read GetChild;
    { binding }
    function FindBinding(const ABinding: string): TFmxObject;
    property Data: Variant read GetData write SetData;
    property Binding[const Index: string]: Variant read GetBinding write SetBinding;
    property Parent: TFmxObject read FParent write SetParent;
    property Index: Integer read GetIndex write SetIndex;
  published
    property BindingName: string read FBindingName write SetBindingName;
    property StyleName: string read FStyleName write SetStyleName;

{ TFmxObject 的父类 TComponent (来自 System.Classes), 到这里不新鲜了 }
  public
    constructor Create(AOwner: TComponent); virtual;
    destructor Destroy; override;
    procedure BeforeDestruction; override;
    procedure DestroyComponents;
    procedure Destroying;
    function ExecuteAction(Action: TBasicAction): Boolean; dynamic;
    function FindComponent(const AName: string): TComponent;
    procedure FreeNotification(AComponent: TComponent);
    procedure RemoveFreeNotification(AComponent: TComponent);
    procedure FreeOnRelease;
    function GetEnumerator: TComponentEnumerator;
    function GetParentComponent: TComponent; dynamic;
    function GetNamePath: string; override;
    function HasParent: Boolean; dynamic;
    procedure InsertComponent(AComponent: TComponent);
    procedure RemoveComponent(AComponent: TComponent);
    procedure SetSubComponent(IsSubComponent: Boolean);
    function SafeCallException(ExceptObject: TObject; ExceptAddr: Pointer): HResult; override;
    function UpdateAction(Action: TBasicAction): Boolean; virtual;
    function IsImplementorOf(const I: IInterface): Boolean;
    function ReferenceInterface(const I: IInterface; Operation: TOperation): Boolean;
    property ComObject: IUnknown read GetComObject;
    property Components[Index: Integer]: TComponent read GetComponent;
    property ComponentCount: Integer read GetComponentCount;
    property ComponentIndex: Integer read GetComponentIndex write SetComponentIndex;
    property ComponentState: TComponentState read FComponentState;
    property ComponentStyle: TComponentStyle read FComponentStyle;
    property DesignInfo: Longint read FDesignInfo write FDesignInfo;
    property Owner: TComponent read FOwner;
    property VCLComObject: Pointer read FVCLComObject write FVCLComObject;
    property Observers: TObservers read GetObservers;
  published
    property Name: TComponentName read FName write SetName stored False;
    property Tag: NativeInt read FTag write FTag default 0;

{ TComponent 的父类 TPersistent (来自 System.Classes) }
  public
    destructor Destroy; override;
    procedure Assign(Source: TPersistent); virtual;
    function GetNamePath: string; dynamic;

{ TPersistent 的父类 TObject (来自 System) }
  public
    constructor Create;
    procedure Free;
    class function InitInstance(Instance: Pointer): TObject;
    procedure CleanupInstance;
    function ClassType: TClass; inline;
    class function ClassName: string;
    class function ClassNameIs(const Name: string): Boolean;
    class function ClassParent: TClass;
    class function ClassInfo: Pointer; inline;
    class function InstanceSize: Longint; inline;
    class function InheritsFrom(AClass: TClass): Boolean;
    class function MethodAddress(const Name: ShortString): Pointer; overload;
    class function MethodAddress(const Name: string): Pointer; overload;
    class function MethodName(Address: Pointer): string;
    class function QualifiedClassName: string;
    function FieldAddress(const Name: ShortString): Pointer; overload;
    function FieldAddress(const Name: string): Pointer; overload;
    function GetInterface(const IID: TGUID; out Obj): Boolean;
    class function GetInterfaceEntry(const IID: TGUID): PInterfaceEntry;
    class function GetInterfaceTable: PInterfaceTable;
    class function UnitName: string;
    class function UnitScope: string;
    function Equals(Obj: TObject): Boolean; virtual;
    function GetHashCode: Integer; virtual;
    function ToString: string; virtual;
    function SafeCallException(ExceptObject: TObject; ExceptAddr: Pointer): HResult; virtual;
    procedure AfterConstruction; virtual;
    procedure BeforeDestruction; virtual;
    procedure Dispatch(var Message); virtual;
    procedure DefaultHandler(var Message); virtual;
    class function NewInstance: TObject; virtual;
    procedure FreeInstance; virtual;
    destructor Destroy; virtual;

---

慢慢消化...

---

关于Delphi XE2 之 FireMonkey 入门(8) - TImage和delphi firedac教程的问题我们已经讲解完毕，感谢您的阅读，如果还想了解更多关于Delphi XE2 FireMonkey Xcode安装问题、Delphi XE2 FireMonkey报告选项、Delphi XE2 之 FireMonkey 入门 (16) - 滤镜：实例测试、Delphi XE2 之 FireMonkey 入门 (2)等相关内容，可以在本站寻找。

本文标签：

• Delphi
• FireMonkey
• TImage
• DelfiFiredac教程
