[Spring4.x]基于spring4.x纯注解的非Web工程搭建（springmvc非注解配置）
Spring框架一直以来是Java开发中的耀眼明星，其IOC/AOP可以大大降低代码的耦合度，但低版本中的xml配置繁杂也让很多人诟病；
Spring4.x以上已经提倡基于注解的开发模式，在非Web项目中，"基于spring纯注解方式如何开发？"就是本文要说明的内容，且看下文：
下面基于Eclipse Oxygen版本，开发一个普通的Java工程，演示如下：
1. 基于 maven-archetype-quickstart 骨架 创建一个普通的Maven工程：
2. 在pom.xml中加入spring、logback及常用jar包的依赖：
3. 在src/main/resources下创建 application.properties、logback.xml、assembly.xml 等配置文件
4. 在Java 代码中创建 @Configuration、@PropertySource 类用于加载配置
package com.morpheus.cmdline.config;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.Configuration;
import org.springframework.context.annotation.PropertySource;
@Configuration
@PropertySource(value = "classpath:application.properties", ignoreResourceNotFound = false, encoding = "UTF-8")
public class AppConfiguration {
@Value("${cmd.decrypt.key}")
private String decryptKey = null;
@Value("${cmd.encrypt.key}")
private String encryptKey = null;
public AppConfiguration() {
}
public String getDecryptKey() {
return decryptKey;
}
public String getEncryptKey() {
return encryptKey;
}
}
5. 在Java 代码中编写 @Component、@Service 等基本组件类
6. 在Java 代码中使用 @Autowired、@Resource 等注入依赖Bean
7. 在Java 代码中使用 @Value 等注入配置值
8. 在主入口类中使用 AnnotationConfigApplicationContext 类启动 spring容器，并通过 getBean() 方法获取需要执行的Bean
package com.morpheus.cmdline;
import org.springframework.context.annotation.AnnotationConfigApplicationContext;
import com.alibaba.fastjson.JSONObject;
import com.morpheus.cmdline.cmd.CmdInvoker;
/**
* 普通Java应用(非web)入口类
*/
public class Application {
public static void main(String[] args) {
AnnotationConfigApplicationContext applicationContext = new AnnotationConfigApplicationContext("com.morpheus.cmdline");
try {
CmdInvoker cmdInvoker = (CmdInvoker) applicationContext.getBean("cmdInvoker");
JSONObject resJSON = cmdInvoker.invoke(args);
System.out.println(resJSON);
} catch (Throwable th) {
th.printStackTrace();
} finally {
applicationContext.close();
}
}
}9. 使用 maven-jar-plugin、 maven-dependency-plugin 打包项目为可执行的jar包
java %JVM_OPTS% -jar CmdLine.jar
就可以执行咯
10. 使用 maven-assembly-plugin 打包项目为可部署的zip包
然后就万事大吉了，可以看到在本项目中不使用任何一个 spring 的xml配置，全部基于注解方式；
在以上步骤开发中，除了第 8 步骤之外，其他步骤同样适用于 springboot 项目的开发。。。
截图后面再补充，准备睡觉咯。。。
6、spring注解+springMVC注解+Mybatis注解+log4j+idea+maven
1、项目结构如下
2、编辑pom.xml文件配置依赖
1 <?xml version="1.0" encoding="UTF-8"?> 2 3 <project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" 4 xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd"> 5 <modelVersion>4.0.0</modelVersion> 6 7 <groupId>com</groupId> 8 <artifactId>ssm_day46</artifactId> 9 <version>1.0-SNAPSHOT</version> 10 <packaging>war</packaging> 11 12 <name>ssm_day46 Maven Webapp</name> 13 <!-- FIXME change it to the project's website --> 14 <url>http://www.example.com</url> 15 16 <properties> 17 <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding> 18 <maven.compiler.source>1.7</maven.compiler.source> 19 <maven.compiler.target>1.7</maven.compiler.target> 20 </properties> 21 22 <dependencies> 23 <dependency> 24 <groupId>junit</groupId> 25 <artifactId>junit</artifactId> 26 <version>4.12</version> 27 </dependency> 28 29 30 <!--1 https://mvnrepository.com/artifact/org.springframework/spring-beans --> 31 <dependency> 32 <groupId>org.springframework</groupId> 33 <artifactId>spring-beans</artifactId> 34 <version>4.3.6.RELEASE</version> 35 </dependency> 36 37 38 <!--2 https://mvnrepository.com/artifact/org.springframework/spring-context --> 39 <dependency> 40 <groupId>org.springframework</groupId> 41 <artifactId>spring-context</artifactId> 42 <version>4.3.6.RELEASE</version> 43 </dependency> 44 45 46 <!-- 3https://mvnrepository.com/artifact/org.springframework/spring-core --> 47 <dependency> 48 <groupId>org.springframework</groupId> 49 <artifactId>spring-core</artifactId> 50 <version>4.3.6.RELEASE</version> 51 </dependency> 52 53 54 <!--4 https://mvnrepository.com/artifact/org.springframework/spring-expression --> 55 <dependency> 56 <groupId>org.springframework</groupId> 57 <artifactId>spring-expression</artifactId> 58 <version>4.3.6.RELEASE</version> 59 </dependency> 60 61 62 <!--5 https://mvnrepository.com/artifact/org.springframework/spring-aop --> 63 <dependency> 64 <groupId>org.springframework</groupId> 65 <artifactId>spring-aop</artifactId> 66 <version>4.3.6.RELEASE</version> 67 </dependency> 68 69 70 <!--6 https://mvnrepository.com/artifact/aopalliance/aopalliance --> 71 <dependency> 72 <groupId>aopalliance</groupId> 73 <artifactId>aopalliance</artifactId> 74 <version>1.0</version> 75 </dependency> 76 77 78 <!--7 https://mvnrepository.com/artifact/org.aspectj/aspectjweaver --> 79 <dependency> 80 <groupId>org.aspectj</groupId> 81 <artifactId>aspectjweaver</artifactId> 82 <version>1.8.10</version> 83 </dependency> 84 85 86 <!--8 https://mvnrepository.com/artifact/log4j/log4j --> 87 <dependency> 88 <groupId>log4j</groupId> 89 <artifactId>log4j</artifactId> 90 <version>1.2.17</version> 91 </dependency> 92 93 94 <!--9 https://mvnrepository.com/artifact/commons-logging/commons-logging --> 95 <dependency> 96 <groupId>commons-logging</groupId> 97 <artifactId>commons-logging</artifactId> 98 <version>1.2</version> 99 </dependency> 100 101 102 <!--10 https://mvnrepository.com/artifact/org.springframework/spring-jdbc --> 103 <dependency> 104 <groupId>org.springframework</groupId> 105 <artifactId>spring-jdbc</artifactId> 106 <version>4.3.6.RELEASE</version> 107 </dependency> 108 109 110 <!--11 https://mvnrepository.com/artifact/org.springframework/spring-orm --> 111 <dependency> 112 <groupId>org.springframework</groupId> 113 <artifactId>spring-orm</artifactId> 114 <version>4.3.6.RELEASE</version> 115 </dependency> 116 117 118 <!--12 https://mvnrepository.com/artifact/org.springframework/spring-tx --> 119 <dependency> 120 <groupId>org.springframework</groupId> 121 <artifactId>spring-tx</artifactId> 122 <version>4.3.6.RELEASE</version> 123 </dependency> 124 125 126 <!--13 https://mvnrepository.com/artifact/org.springframework/spring-web --> 127 <dependency> 128 <groupId>org.springframework</groupId> 129 <artifactId>spring-web</artifactId> 130 <version>4.3.6.RELEASE</version> 131 </dependency> 132 133 134 <!--14 https://mvnrepository.com/artifact/org.springframework/spring-webmvc --> 135 <dependency> 136 <groupId>org.springframework</groupId> 137 <artifactId>spring-webmvc</artifactId> 138 <version>4.3.6.RELEASE</version> 139 </dependency> 140 141 142 <!--15 https://mvnrepository.com/artifact/org.mybatis/mybatis --> 143 <dependency> 144 <groupId>org.mybatis</groupId> 145 <artifactId>mybatis</artifactId> 146 <version>3.4.6</version> 147 </dependency> 148 149 150 <!--16 https://mvnrepository.com/artifact/MysqL/mysql-connector-java --> 151 <dependency> 152 <groupId>MysqL</groupId> 153 <artifactId>mysql-connector-java</artifactId> 154 <version>5.1.38</version> 155 </dependency> 156 157 158 <!--17 https://mvnrepository.com/artifact/org.mybatis/mybatis-spring --> 159 <dependency> 160 <groupId>org.mybatis</groupId> 161 <artifactId>mybatis-spring</artifactId> 162 <version>1.3.2</version> 163 </dependency> 164 165 <!--18 https://mvnrepository.com/artifact/javax.servlet/javax.servlet-api --> 166 <dependency> 167 <groupId>javax.servlet</groupId> 168 <artifactId>javax.servlet-api</artifactId> 169 <version>3.1.0</version> 170 </dependency> 171 172 <!--19 https://mvnrepository.com/artifact/javax.servlet/jstl --> 173 <dependency> 174 <groupId>javax.servlet</groupId> 175 <artifactId>jstl</artifactId> 176 <version>1.2</version> 177 </dependency> 178 179 180 <!--20 https://mvnrepository.com/artifact/taglibs/standard --> 181 <dependency> 182 <groupId>taglibs</groupId> 183 <artifactId>standard</artifactId> 184 <version>1.1.2</version> 185 </dependency> 186 187 <!--文件上传使用的jar--> 188 <!--21 https://mvnrepository.com/artifact/commons-io/commons-io --> 189 <dependency> 190 <groupId>commons-io</groupId> 191 <artifactId>commons-io</artifactId> 192 <version>2.4</version> 193 </dependency> 194 <!--22--> 195 <dependency> 196 <groupId>commons-fileupload</groupId> 197 <artifactId>commons-fileupload</artifactId> 198 <version>1.3.3</version> 199 </dependency> 200 201 <!--23 下载ajax封装数据json格式交互的jar--> 202 <dependency> 203 <groupId>com.fasterxml.jackson.core</groupId> 204 <artifactId>jackson-databind</artifactId> 205 <version>2.9.6</version> 206 </dependency> 207 208 <dependency> 209 <groupId>com.fasterxml.jackson.core</groupId> 210 <artifactId>jackson-core</artifactId> 211 <version>2.9.6</version> 212 </dependency> 213 214 <dependency> 215 <groupId>com.fasterxml.jackson.core</groupId> 216 <artifactId>jackson-annotations</artifactId> 217 <version>2.9.6</version> 218 </dependency> 219 220 <!--使用4的版本否则springmvc的xml--> 221 <dependency> 222 <groupId>com.github.pageHelper</groupId> 223 <artifactId>pageHelper</artifactId> 224 <version>4.1.6</version> 225 </dependency> 226 </dependencies> 227 228 229 </project>pom.xml
3、在java目录下的com.pojo包下创建Scott.java持久化类
1 package com.pojo;
2
3 import org.springframework.stereotype.Component;
4
5 import java.io.Serializable;
6
7 /**
8 * 多方引用一方对象
9 */
10 @Component
11 public class Scott implements Serializable{
12 //多方所需字段
13 private Integer empno ;
14 private String ename ;
15 private Double sal ;
16 private Integer deptno;
17 //一方所需字段
18 private String dname;
19
20 public Scott() {
21 }
22
23 public Scott(Integer empno, String ename, Double sal, Integer deptno, String dname) {
24 this.empno = empno;
25 this.ename = ename;
26 this.sal = sal;
27 this.deptno = deptno;
28 this.dname = dname;
29 }
30
31 public Integer getEmpno() {
32 return empno;
33 }
34
35 public void setEmpno(Integer empno) {
36 this.empno = empno;
37 }
38
39 public String getEname() {
40 return ename;
41 }
42
43 public void setEname(String ename) {
44 this.ename = ename;
45 }
46
47 public Double getSal() {
48 return sal;
49 }
50
51 public void setSal(Double sal) {
52 this.sal = sal;
53 }
54
55 public Integer getDeptno() {
56 return deptno;
57 }
58
59 public void setDeptno(Integer deptno) {
60 this.deptno = deptno;
61 }
62
63 public String getDname() {
64 return dname;
65 }
66
67 public void setDname(String dname) {
68 this.dname = dname;
69 }
70
71 @Override
72 public String toString() {
73 return "Scott{" +
74 "empno=" + empno +
75 ", ename='" + ename + '\'' +
76 ", sal=" + sal +
77 ", deptno=" + deptno +
78 ", dname='" + dname + '\'' +
79 '}';
80 }
81 }
Scott.java
4、在java目录下的com.mapper包下创建ScottMapper.java映射接口
1 package com.mapper;
2 import com.pojo.Scott;
3 import org.apache.ibatis.annotations.Delete;
4 import org.apache.ibatis.annotations.Insert;
5 import org.apache.ibatis.annotations.Select;
6 import org.apache.ibatis.annotations.Update;
7 import org.springframework.stereotype.Repository;
8
9 import java.util.List;
10 @Repository
11 public interface ScottMapper {
12 @Select("select * from dept")
13 List<Scott> selectOneList();
14
15 @Select("select d.dname,e.* from dept d,emp e where e.deptno=d.deptno")
16 List<Scott> selectAll();
17
18 @Select("select d.dname,e.* from dept d,emp e where e.deptno=d.deptno and e.empno=#{primaryKey}")
19 Scott selectPrimaryKey(Integer primaryKey);
20
21 @Select("select d.dname,e.* from dept d,emp e where e.deptno=d.deptno and e.deptno=#{foreignKey}")
22 List<Scott> selectForeign(Integer foreignKey);
23
24 @Insert("insert into emp(empno,ename,sal,deptno) values(#{empno},#{ename},#{sal},#{deptno})")
25 int insertScott(Scott scott);
26
27 @Update("update emp set ename=#{ename},sal=#{sal},deptno=#{deptno} where empno=#{empno}")
28 int updateScott(Scott scott);
29
30 @Delete("delete from emp where empno=#{primaryKey}")
31 int deleteScott(Integer primaryKey);
32 }
ScottMapper.java
5、在java目录下的com.service包下创建业务层接口和实现类
1 package com.service;
2
3 import com.pojo.Scott;
4
5 import java.util.List;
6
7 public interface ScottService {
8 List<Scott> downoption();
9 List<Scott> show();
10 Scott info(Integer primaryKey);
11 List<Scott> optionCondition(Integer foreignKey);
12 int add(Scott emp);
13 int edit(Scott emp);
14 int del(Integer primaryKey);
15 }
ScottService.java
1 package com.service;
2 import com.mapper.ScottMapper;
3 import com.pojo.Scott;
4 import org.springframework.beans.factory.annotation.Autowired;
5 import org.springframework.stereotype.Service;
6
7 import java.util.List;
8 /*
9 @Service的功能等同于代理对象在spring的xml文件中动态添加bean节点,
10 如果不指定名称，则底层代理在构建bean节点的时候id是类的第一个首字母小写
11 <bean id="empServiceImpl"/>
12 @Service(value = "empse")的功能等同于代理对象在spring的xml文件中动态添加id值为empse的bean节点
13 <bean id="empse"/>
14 */
15 @Service
16 public class ScottServiceImpl implements ScottService {
17 /*
18 @Autowired是spring的资源包下注解，按照对象的类型进行自动注入，
19 和对象名称无关，只要类型是匹配的，代理就会在你需要的时候给你注入对象值
20 @Resource是javax包下的注解，按照对象属性名进行注入，
21 和对象名称关系密切，如果对象名称不匹配，则不能完成注入，会报错
22 总结：相比而言，使用@Resource的出错记录更大，因此我们常规选择使用@Autowired
23 */
24 @Autowired
25 private ScottMapper scottMapper;
26
27 @Override
28 public List<Scott> downoption() {
29 return scottMapper.selectOneList();
30 }
31
32 @Override
33 public List<Scott> show() {
34 return scottMapper.selectAll();
35 }
36
37 @Override
38 public Scott info(Integer primaryKey) {
39 return scottMapper.selectPrimaryKey(primaryKey);
40 }
41
42 @Override
43 public List<Scott> optionCondition(Integer foreignKey) {
44 return scottMapper.selectForeign(foreignKey);
45 }
46
47 @Override
48 public int del(Integer primaryKey) {
49 return scottMapper.deleteScott(primaryKey);
50 }
51
52 @Override
53 public int add(Scott scott) {
54 return scottMapper.insertScott(scott);
55 }
56
57 @Override
58 public int edit(Scott scott) {
59 return scottMapper.updateScott(scott);
60 }
61 }
ScottServiceImpl.java
6、在java目录下的com.controller包下创建控制类CenterController.java
1 package com.controller;
2 import com.pojo.Scott;
3 import com.service.ScottService;
4 import org.springframework.beans.factory.annotation.Autowired;
5 import org.springframework.stereotype.Controller;
6 import org.springframework.ui.Model;
7 import org.springframework.web.bind.annotation.RequestMapping;
8 import org.springframework.web.bind.annotation.ResponseBody;
9
10 import javax.servlet.http.HttpSession;
11 import java.util.HashMap;
12 import java.util.List;
13 import java.util.Map;
14 @Controller
15 public class CenterController {
16 @Autowired
17 private ScottService scottService;
18
19 @RequestMapping("/option.do")
20 public String optionData(HttpSession session){
21 List<Scott> deptlist=scottService.downoption();
22 session.setAttribute("deptlist",deptlist);
23 return "redirect:/main.jsp";
24 }
25
26 @RequestMapping("/show.do")
27 @ResponseBody
28 public Map<String,Object> showData(Integer foreignKey){
29 Map<String,Object> map=new HashMap<String,Object>();
30 List<Scott> emplist=null;
31 //根据部门编号条件查询
32 if(foreignKey!=-1){
33 emplist=scottService.optionCondition(foreignKey);
34 }else{ //查询所有
35 emplist=scottService.show();
36 }
37 map.put("emplist",emplist);
38 return map;
39 }
40
41
42 @RequestMapping("/info.do")
43 public String info(Integer primaryKey, Model model){
44 Scott emp=scottService.info(primaryKey);
45 model.addAttribute("emp2",emp);
46 return "/edit.jsp";
47 }
48
49
50 @RequestMapping("/edit.do")
51 public String edit(Scott emp){
52 //根据主键编号查询只有一条数据
53 System.out.println(scottService.edit(emp)>0?"edit success":"edit fail");;
54 //使用重定向跳转
55 return "redirect:/main.jsp";
56 }
57
58 @RequestMapping("/add.do")
59 public String add(Scott emp){
60 //根据主键编号查询只有一条数据
61 System.out.println(scottService.add(emp)>0?"add success":"add fail");;
62 //使用重定向跳转
63 return "redirect:/main.jsp";
64 }
65
66 @RequestMapping("/del.do")
67 public String del(Integer primaryKey){
68 //根据主键编号查询只有一条数据
69 System.out.println(scottService.del(primaryKey)>0?"del success":"del fail");;
70 //使用重定向跳转
71 return "redirect:/main.jsp";
72 }
73 }
CenterController.java
7、在resouces目录下创建log4j.properties日志文件
1 log4j.rootLogger=DEBUG, Console 2 #Console 3 log4j.appender.Console=org.apache.log4j.ConsoleAppender 4 log4j.appender.Console.layout=org.apache.log4j.PatternLayout 5 log4j.appender.Console.layout.ConversionPattern=%d [%t] %-5p [%c] - %m%n 6 7 log4j.logger.org.apache=INFO 8 log4j.logger.java.sql.ResultSet=INFO 9 log4j.logger.java.sql.Connection=DEBUG 10 log4j.logger.java.sql.Statement=DEBUG 11 log4j.logger.java.sql.PreparedStatement=DEBUGlog4j.properties
8、在webapp目录下的WEB-INF文件夹下创建springmvc-servlet.xml核心配置文件，和web.xml文件
1 <?xml version="1.0" encoding="UTF-8"?> 2 <beans xmlns="http://www.springframework.org/schema/beans" 3 xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" 4 xmlns:aop="http://www.springframework.org/schema/aop" 5 xmlns:context="http://www.springframework.org/schema/context" 6 xmlns:tx="http://www.springframework.org/schema/tx" 7 xmlns:mvc="http://www.springframework.org/schema/mvc" 8 xsi:schemaLocation="http://www.springframework.org/schema/beans 9 http://www.springframework.org/schema/beans/spring-beans.xsd 10 http://www.springframework.org/schema/aop 11 http://www.springframework.org/schema/aop/spring-aop.xsd 12 http://www.springframework.org/schema/context 13 http://www.springframework.org/schema/context/spring-context.xsd 14 http://www.springframework.org/schema/tx 15 http://www.springframework.org/schema/tx/spring-tx.xsd 16 http://www.springframework.org/schema/mvc 17 http://www.springframework.org/schema/mvc/spring-mvc.xsd 18 "> 19 <!--1.mvc注解驱动--> 20 <mvc:annotation-driven/> 21 <!--2.全局扫描包--> 22 <context:component-scan base-package="com"/> 23 <!--3.驱动管理数据源--> 24 <bean id="dataSource"> 25 <property name="driverClassName" value="com.MysqL.jdbc.Driver"/> 26 <property name="url" value="jdbc:MysqL://localhost:3306/ar"/> 27 <property name="username" value="root"/> 28 <property name="password" value="123456"/> 29 </bean> 30 <!--4.数据源事务管理--> 31 <bean id="transactionManager"> 32 <property name="dataSource" ref="dataSource"/> 33 </bean> 34 <!--5.事务注解驱动--> 35 <tx:annotation-driven transaction-manager="transactionManager"/> 36 <!--6.sqlsessionfacotrybean--> 37 <bean id="sqlSessionFactory"https://www.jb51.cc/tag/sql/" target="_blank">sqlSessionfactorybean"> 38 <property name="dataSource" ref="dataSource"/> 39 </bean> 40 <!--7.映射扫描参数--> 41 <beanhttps://www.jb51.cc/tag/fig/" target="_blank">figurer"> 42 <property name="basePackage" value="com.mapper"/> 43 </bean> 44 </beans>springmvc-servlet.xml
1 <!DOCTYPE web-app PUBLIC 2 "-//Sun Microsystems, Inc.//DTD Web Application 2.3//EN" 3 "http://java.sun.com/dtd/web-app_2_3.dtd" > 4 5 <web-app> 6 <filter> 7 <filter-name>Character</filter-name> 8 <filter-class>org.springframework.web.filter.CharacterEncodingFilter</filter-class> 9 <init-param> 10 <param-name>encoding</param-name> 11 <param-value>UTF-8</param-value> 12 </init-param> 13 </filter> 14 <filter-mapping> 15 <filter-name>Character</filter-name> 16 <url-pattern>/*</url-pattern> 17 </filter-mapping> 18 <servlet> 19 <servlet-name>springmvc</servlet-name> 20 <servlet-class>org.springframework.web.servlet.dispatcherServlet</servlet-class> 21 </servlet> 22 <servlet-mapping> 23 <servlet-name>springmvc</servlet-name> 24 <url-pattern>*.do</url-pattern> 25 </servlet-mapping> 26 <welcome-file-list> 27 <welcome-file>option.do</welcome-file> 28 </welcome-file-list> 29 </web-app>web.xml
10、在webapp目录下创建js目录，且将jquery的库文件jquery-1.8.3.js拷贝进去
11、在webapp目录下创建main.jsp文件
1 <%@ taglib prefix="c" uri="http://java.sun.com/jsp/jstl/core" %>
2 <%@ page contentType="text/html;charset=UTF-8" language="java" %>
3 <%@ page isELIgnored="false" %>
4 <html>
5 <head>
6 <title>首页</title>
7 <script type="text/javascript" src="js/jquery-1.8.3.js"></script>
8 <script type="text/javascript" src="js/show.js"></script>
9 </head>
10 <body>
11 <a href="add.jsp">添加</a>
12 <p>
13 <span>部门：</span>
14 <select name="foreignKey">
15 <option value="-1">--请选择--</option>
16 <c:forEach var="i" items="${deptlist}">
17 <option value="${i.deptno}">${i.dname}</option>
18 </c:forEach>
19 </select>
20 <input type="button" value="查询">
21 </p>
22 <table></table>
23 </body>
24 </html>
main.jsp
12、在webapp目录的js目录下创建show.js文件
1 $(function () {
2 //初始化查询所有
3 initData(-1);
4 //下拉列表条件查
5 $("[type=button]").click(function () {
6 var foreignKey=$("[name=foreignKey]").val();
7 initData(foreignKey)
8 });
9
10 });
11
12 function initData(foreignKey) {
13 $.ajax({
14 url:"show.do",
15 type:"post",
16 dataType:"json",
17 data:{"foreignKey":foreignKey},
18 async:true,
19 success:function (obj) {
20 //将值打印在控制台
21 console.log(obj);
22 //为了防止频繁发送请求重复拼接问题，因此在拼接数据之前，先清楚原有的数据内容
23 $("table").html(" ");
24 var str=" <tr>";
25 str+=" <th>员工编号</th>";
26 str+=" <th>员工姓名</th>";
27 str+=" <th>员工工资</th>";
28 str+=" <th>部门名称</th>";
29 str+=" <th>操作</th>";
30 str+=" </tr>";
31 for(var i=0;i<obj.emplist.length;i++){
32 str+="<tr>";
33 str+="<td>"+obj.emplist[i].empno +"</td>";
34 str+="<td>"+obj.emplist[i].ename +"</td>";
35 str+="<td>"+obj.emplist[i].sal +"</td>";
36 str+="<td>"+obj.emplist[i].dname+"</td>";
37 str+="<td>" +
38 "<a href='info.do?primaryKey="+obj.emplist[i].empno+"'>修改</a>" +
39 "|" +
40 "<a href='del.do?primaryKey="+obj.emplist[i].empno+"'>删除</a>" +
41 "</td>";
42 str+="</tr>";
43 }
44 $("table").append(str);
45 },
46 error:function () {
47 alert("get data error");
48 }
49 });
50 }
show.js
13、在webapp目录下创建add.jsp文件
1 <%@ taglib prefix="c" uri="http://java.sun.com/jsp/jstl/core" %>
2 <%@ page contentType="text/html;charset=UTF-8" language="java" %>
3 <%@ page isELIgnored="false" %>
4 <html>
5 <head>
6 <title>添加信息</title>
7 </head>
8 <body>
9 <fieldset>
10 <legend>添加员工信息</legend>
11 <form action="add.do" method="post">
12 <table>
13 <tr>
14 <th>部门名称：</th>
15 <td>
16 <select name="dept.deptno">
17 <option value="-1">--请选择--</option>
18 <c:forEach var="i" items="${deptlist}">
19 <option value="${i.deptno}">${i.dname}</option>
20 </c:forEach>
21 </select>
22 </td>
23 </tr>
24 <tr>
25 <th>员工编号：</th>
26 <td><input type="text" name="empno"/></td>
27 </tr>
28 <tr>
29 <th>员工姓名：</th>
30 <td><input type="text" name="ename" /></td>
31 </tr>
32 <tr>
33 <th>员工薪资：</th>
34 <td><input type="text" name="sal" /></td>
35 </tr>
36 <tr>
37 <td colspan="2" align="center">
38 <input type="submit" value="提交"/>
39 <input type="reset" value="重置"/>
40 </td>
41 </tr>
42 </table>
43 </form>
44 </fieldset>
45 </body>
46 </html>
add.jsp
14、在webapp目录下创建edit.jsp文件
1 <%@ taglib prefix="c" uri="http://java.sun.com/jsp/jstl/core" %>
2 <%@ page contentType="text/html;charset=UTF-8" language="java" %>
3 <%@ page isELIgnored="false" %>
4 <html>
5 <head>
6 <title>编辑信息</title>
7 </head>
8 <body>
9 <fieldset>
10 <legend>编辑员工信息</legend>
11 <form action="edit.do?empno=${emp2.empno}" method="post">
12 <table>
13 <tr>
14 <th>部门名称：</th>
15 <td>
16 <select name="dept.deptno">
17 <option value="-1">--请选择--</option>
18 <c:forEach var="i" items="${deptlist}">
19 <c:choose>
20 <c:when test="${emp2.dept.deptno eq i.deptno}">
21 <option value="${i.deptno}" selected="selected">${i.dname}</option>
22 </c:when>
23 <c:otherwise>
24 <option value="${i.deptno}">${i.dname}</option>
25 </c:otherwise>
26 </c:choose>
27 </c:forEach>
28 </select>
29 </td>
30 </tr>
31 <tr>
32 <th>员工姓名：</th>
33 <td><input type="text" name="ename" value="${emp2.ename}"/></td>
34 </tr>
35 <tr>
36 <th>员工薪资：</th>
37 <td><input type="text" name="sal" value="${emp2.sal}"/></td>
38 </tr>
39 <tr>
40 <td colspan="2" align="center">
41 <input type="submit" value="提交"/>
42 <input type="reset" value="重置"/>
43 </td>
44 </tr>
45 </table>
46 </form>
47 </fieldset>
48
49 </body>
50 </html>
edit.jsp
15、部署启动运行
此文章为原创，转载请注明出处！需要本案例源码，理论讲解视频，代码操作视频的，请私信联系作者！
Maven 工程搭建 spring boot+spring mvc+JPA
添加 Spring boot 支持，引入相关包：
1、maven 工程，少不了 pom.xml，spring boot 的引入可参考官网：
<parent>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter-parent</artifactId>
<version>1.5.9.RELEASE</version>
</parent>
<dependencies>
<dependency>
<groupId>javax.servlet</groupId>
<artifactId>javax.servlet-api</artifactId>
<scope>provided</scope><!-- 编译需要而发布不需要的jar包 -->
</dependency>
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-webmvc</artifactId>
</dependency>
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter-web</artifactId>
</dependency>
<!--jpa的jar包 ，操作数据库的-->
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter-data-jpa</artifactId>
</dependency>
<dependency>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-starter-data-redis</artifactId>
</dependency>
<!--mysql驱动-->
<dependency>
<groupId>mysql</groupId>
<artifactId>mysql-connector-java</artifactId>
</dependency>
<dependency>
<groupId>org.apache.shiro</groupId>
<artifactId>shiro-core</artifactId>
<version>1.2.2</version>
</dependency>
<dependency>
<groupId>org.apache.shiro</groupId>
<artifactId>shiro-spring</artifactId>
<version>1.2.2</version>
</dependency>
<!-- shiro ehcache -->
<dependency>
<groupId>org.apache.shiro</groupId>
<artifactId>shiro-ehcache</artifactId>
<version>1.2.2</version>
</dependency>
</dependencies>
<build>
<plugins>
<plugin>
<groupId>org.springframework.boot</groupId>
<artifactId>spring-boot-maven-plugin</artifactId>
<executions>
<execution>
<goals>
<goal>repackage</goal>
</goals>
</execution>
</executions>
</plugin>
</plugins>
<finalName>name</finalName>
</build>2、以上代码引入了 spring boot。spring mvc 和 jpa，以及 mysql 数据库的驱动 jar；
编写启动类，并加装配置文件：
1、启动类如下：
import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.EnableAutoConfiguration;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.data.jpa.repository.config.EnableJpaAuditing;
import java.io.IOException;
import com.my.config.CommonProperties;
@SpringBootApplication
@EnableAutoConfiguration
@EnableJpaAuditing
public class Application {
public static void main(String[] args) throws IOException{
String loc = CommonProperties.loadProperties2System(System.getProperty("spring.config.location"));
System.getProperties().setProperty("application.version", CommonProperties.getVersion(Application.class));
System.getProperties().setProperty("app.home", loc + "/..");
SpringApplication.run(Application.class, args);
}
}2、配置文件的位置放到 classpath 外边，方便在不重新打包的情况下修改，spring boot 工程一般都打成 jar 包：
import java.io.File;
import java.io.FileInputStream;
import java.io.IOException;
import java.util.Properties;
import org.springframework.util.StringUtils;
public final class CommonProperties {
public static final String PPT_KEY_APP_HOME = "app.home";
public static final String DEFAULT_APP_HOME = "./";
public static final String getAppHome() {
return System.getProperty("./", "./");
}
public static String loadProperties2System(String location) throws IOException {
String configLocation = location;
File cnf;
if (!StringUtils.hasLength(location)) {
configLocation = "./config";
cnf = new File(configLocation);
if (!cnf.exists() || !cnf.isDirectory()) {
configLocation = "../config";
cnf = new File(configLocation);
}
} else {
cnf = new File(location);
}
File[] arg2 = cnf.listFiles();
int arg3 = arg2.length;
for (int arg4 = 0; arg4 < arg3; ++arg4) {
File file = arg2[arg4];
if (file.isFile() && file.getName().endsWith(".properties")) {
Properties ppt = new Properties();
FileInputStream fi = new FileInputStream(file);
Throwable arg8 = null;
try {
ppt.load(fi);
System.getProperties().putAll(ppt);
} catch (Throwable arg17) {
arg8 = arg17;
throw arg17;
} finally {
if (fi != null) {
if (arg8 != null) {
try {
fi.close();
} catch (Throwable arg16) {
arg8.addSuppressed(arg16);
}
} else {
fi.close();
}
}
}
}
}
return configLocation;
}
public static String getVersion(Class<?> clazz) {
Package pkg = clazz.getPackage();
String ver = pkg != null ? pkg.getImplementationVersion() : "undefined";
return ver == null ? "undefined" : ver;
}将配置文件放到 jar 包同级目录的 config 文件夹下，包括日志配置，application.yml 文件，其他配置文件等；
编写自动配置类
用于扫描 compan* , 代替 spring mvc 的 spring.xml 配置文件：
import org.springframework.context.annotation.ComponentScan;
import org.springframework.context.annotation.Configuration;
@Configuration
@ComponentScan(basePackages = {
"com.my.rs",
"com.my.service",
"com.my.repository"})
public class AppAutoConfiguration {
}
import org.springframework.boot.autoconfigure.web.HttpMessageConverters;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.servlet.config.annotation.ResourceHandlerRegistry;
import org.springframework.web.servlet.config.annotation.WebMvcConfigurerAdapter;
/**
* 预配置
* */
@Configuration
public class MyConfiguration extends WebMvcConfigurerAdapter{
@Bean
public HttpMessageConverters customConverters() {
return new HttpMessageConverters();
}
@Override
public void addResourceHandlers(ResourceHandlerRegistry registry) {
//registry.addResourceHandler("/**")
// .addResourceLocations("classpath:/META-INF/resources/**");
}
编写 rs,service,repository
package com.my.rs;
import java.util.List;
import org.springframework.web.bind.annotation.RequestBody;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestMethod;
import org.springframework.web.bind.annotation.RequestParam;
import org.springframework.web.bind.annotation.ResponseBody;
import com.my.entity.User;
@RequestMapping({"/api/user"})
public interface UserRS {
@RequestMapping(value="/add",method={RequestMethod.POST})
@ResponseBody
public User saveUser(@RequestBody User user);
@RequestMapping(value="/update",method={RequestMethod.POST})
@ResponseBody
public User updateUser(@RequestBody User user);
@RequestMapping(value="/delete",method={RequestMethod.POST,RequestMethod.DELETE})
public void deleteUser(@RequestParam String[] userIds);
@RequestMapping(value="/get",method={RequestMethod.GET})
@ResponseBody
public User getUser(@RequestParam String userId);
@RequestMapping(value="/query/all",method={RequestMethod.GET})
public List<User> queryAll();
@RequestMapping(value="/query/byName",method={RequestMethod.GET})
public List<User> queryByName(@RequestParam String name);
@RequestMapping(value="/query/byParentId",method={RequestMethod.GET})
public List<User> queryChildren(@RequestParam String parentId);
//无参数分页查询
@RequestMapping(value="/query/page",method={RequestMethod.GET})
public List<User> queryByPage(@RequestParam int pageNo,
@RequestParam int pageSize,
@RequestBody(required=false) User user);
}
package com.my.rs.impl;
import java.util.List;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.RequestBody;
import org.springframework.web.bind.annotation.RestController;
import com.my.entity.User;
import com.my.rs.UserRS;
import com.my.service.UserService;
@RestController
public class UserRSImpl implements UserRS{
public static Logger logger = LoggerFactory.getLogger(UserRSImpl.class);
@Autowired
UserService _userService;
@Override
public User saveUser(@RequestBody User user){
try {
return _userService.save(user);
} catch (Throwable e) {
logger.error(e.getMessage(),e);
throw e;
}
}
@Override
public User updateUser(@RequestBody User user) {
return _userService.update(user);
}
@Override
public void deleteUser(String[] userIds) {
for (String userId : userIds) {
_userService.deleteById(userId);
}
}
@Override
public List<User> queryAll() {
return _userService.queryAll();
}
@Override
public List<User> queryByName(String name) {
return _userService.findByName(name);
}
@Override
public List<User> queryChildren(String parentId) {
return _userService.findByParentId(parentId);
}
@Override
public User getUser(String userId) {
return _userService.findById(userId);
}
@Override
public List<User> queryByPage(int pageNo, int pageSize, User user) {
return null;
}
}
package com.my.service;
import java.util.List;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;
import com.my.entity.User;
import com.my.repository.UserRepository;
@Service
public class UserService extends BaseService<User>{
@Autowired
UserRepository _userRepository;
public List<User> findByName(String name){
return _userRepository.findByName(name);
}
public List<User> findByParentId(String parentId){
return _userRepository.findByParentId(parentId);
}
}package com.my.repository;
import java.util.List;
import com.my.entity.User;
public interface UserRepository extends BaseRepository<User>{
List<User> findByName(String name);
List<User> findByParentId(String parentId);
}
以上采用了分层模式，有点繁琐，但是对之后修改每层的业务逻辑比较方便
JPA 相关的类如下：
package com.my.service;
import java.io.Serializable;
import javax.persistence.EntityManager;
import javax.transaction.Transactional;
import org.springframework.beans.factory.annotation.Autowired;
import com.my.repository.BaseRepository;
/**
* 一些共有的方法放这里
* */
@Transactional
public class BaseService<E extends Serializable> {
@Autowired
BaseRepository<E> _baseRepository;
@Autowired
EntityManager em;
public E save(E baseUnit){
return _baseRepository.saveAndFlush(baseUnit);
}
public E update(E baseUnit){
return _baseRepository.saveAndFlush(baseUnit);
}
public void deleteById(String id) {
_baseRepository.delete(id);
}
public java.util.List<E> queryAll(){
return _baseRepository.findAll();
}
public E findById(String id){
return _baseRepository.getOne(id);
}
}package com.my.repository;
import java.io.Serializable;
import org.springframework.data.jpa.repository.JpaRepository;
import org.springframework.data.repository.NoRepositoryBean;
@NoRepositoryBean
public interface BaseRepository<E> extends JpaRepository<E, Serializable>{
}实体类：与数据库字段相关，需要注意下父类中的注解 @MappedSuperclass
package com.my.entity;
import java.util.ArrayList;
import java.util.List;
import javax.persistence.Entity;
import javax.persistence.ManyToMany;
import org.hibernate.annotations.DynamicInsert;
import org.hibernate.annotations.DynamicUpdate;
import org.hibernate.validator.constraints.Email;
@Entity(name = "db_user")
@DynamicInsert
@DynamicUpdate
public class User extends BaseUnit {
/**
* 账户状态
*/
public static enum AccountStatus {
/**
* 正常
*/
Enable, //
/**
* 停用
*/
Disable
}
private static final long serialVersionUID = -3101319619397064425L;
private String password;
private String salt;
/** 账户状态 */
private AccountStatus status;
/** 认证邮箱 */
@Email(message = "User.email属性必须符合邮箱格式")
private String email;
/** 移动电话号码 */
private String mobileNo;
/** 身份证号码 */
private String cardId;
@ManyToMany(targetEntity=Role.class)
private List<String> roleIds;
/** 昵称。可选。 */
private String nickName;
public String getCardId() {
return cardId;
}
public String getEmail() {
return email;
}
public String getMobileNo() {
return mobileNo;
}
public String getNickName() {
return nickName;
}
public String getPassword() {
return password;
}
public List<String> getRoleIds() {
if (roleIds == null) {
roleIds = new ArrayList<>();
}
return roleIds;
}
public String getSalt() {
return salt;
}
public AccountStatus getStatus() {
return status;
}
public void setCardId(String cardId) {
this.cardId = cardId;
}
public void setEmail(String email) {
this.email = email;
}
public void setMobileNo(String mobileNo) {
this.mobileNo = mobileNo;
}
public void setNickName(String nickName) {
this.nickName = nickName;
}
public void setPassword(String password) {
this.password = password;
}
public void setRoleIds(List<String> roleIds) {
this.roleIds = roleIds;
}
public void setSalt(String salt) {
this.salt = salt;
}
public void setStatus(AccountStatus status) {
this.status = status;
}
}package com.my.entity;
import java.io.Serializable;
import java.util.Date;
import javax.persistence.Id;
import javax.persistence.MappedSuperclass;
import javax.validation.constraints.NotNull;
import javax.validation.constraints.Size;
import org.springframework.data.annotation.CreatedBy;
import org.springframework.data.annotation.CreatedDate;
import org.springframework.data.annotation.LastModifiedBy;
import org.springframework.data.annotation.LastModifiedDate;
@MappedSuperclass
public class BaseUnit implements Serializable {
@Id
@NotNull
public String id;
/**
* 父单元ID
*/
@Size(max = 32, message = "BaseUnit.parentId属性长度不能大于32")
public String parentId;
/** 父单元的类型 */
public ParentType parentType;
/**
* 单元的名称
*/
@NotNull(message = "BaseUnit.name属性不能为空")
public String name;
@CreatedBy
public String createBy;
@CreatedDate
public Date createDate;
@LastModifiedBy
public String lastModifiedBy;
/**
* 最后更新日期
*/
@LastModifiedDate
public Date lastModifiedDate;
public String getId() {
return id;
}
public void setId(String id) {
this.id = id;
}
/**
* 获取单元的名称
*
* @return 必填
*/
public String getName() {
return name;
}
/**
*
*
* @return UUID，不含{}和-
*/
public String getParentId() {
return parentId;
}
public ParentType getParentType() {
return parentType;
}
public String getStationId() {
return stationId;
}
public String getThumbnailId() {
return thumbnailId;
}
public String getCreateBy() {
return createBy;
}
public void setCreateBy(String createBy) {
this.createBy = createBy;
}
public Date getCreateDate() {
return createDate;
}
public void setCreateDate(Date createDate) {
this.createDate = createDate;
}
/**
* 设置单元的名称
*
* @param name
* 必填
*/
public void setName(String name) {
this.name = name;
}
/**
* 设置父单元ID
*
* @param parentId
* UUID，不含{}和-
*/
public void setParentId(String parentId) {
this.parentId = parentId;
}
public String getLastModifiedBy() {
return lastModifiedBy;
}
public void setLastModifiedBy(String lastModifiedBy) {
this.lastModifiedBy = lastModifiedBy;
}
public Date getLastModifiedDate() {
return lastModifiedDate;
}
public void setLastModifiedDate(Date lastModifiedDate) {
this.lastModifiedDate = lastModifiedDate;
}
}配置文件：
server:
port: 16800
contextPath: /
logging:
config: ./config/logback.xml
spring:
http:
multipart:
enabled: false
datasource:
url : jdbc:mysql://127.0.0.1:3306/db?useUnicode=true&characterEncoding=utf-8
username : root
password : 123456
driverClassName : com.mysql.jdbc.Driver
jpa:
database : MYSQL
show-sql : true
hibernate:
ddl-auto : update
jackson:
serialization:
INDENT_OUTPUT : true#hibernate:配置了实体类维护数据库表结构的具体行为，update表示当实体类的属性发生变化时，表结构跟着更新，
这里我们也可以取值create，这个create表示启动的时候删除上一次生成的表，并根据实体类重新生成表，
这个时候之前表中的数据就会被清空；还可以取值create-drop，这个表示启动时根据实体类生成表，但是当sessionFactory关闭的时候表会被删除；
validate表示启动时验证实体类和数据表是否一致；none表示啥都不做。
#show-sql表示hibernate在操作的时候在控制台打印真实的sql语句
#jackson表示格式化输出的json字符串
Maven工程搭建spring boot+spring mvc+JPA的示例
本文介绍了Maven工程搭建spring boot+spring mvc+JPA的示例，分享给大家，具体如下：
添加Spring boot支持，引入相关包：
1、maven工程，少不了pom.xml，spring boot的引入可参考官网：
<parent> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-parent</artifactId> <version>1.5.9.RELEASE</version> </parent> <dependencies> <dependency> <groupId>javax.servlet</groupId> <artifactId>javax.servlet-api</artifactId> <scope>provided</scope><!-- 编译需要而发布不需要的jar包 --> </dependency> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-webmvc</artifactId> </dependency> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-web</artifactId> </dependency> <!--jpa的jar包 ，操作数据库的--> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-data-jpa</artifactId> </dependency> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-data-redis</artifactId> </dependency> <!--MysqL驱动--> <dependency> <groupId>MysqL</groupId> <artifactId>mysql-connector-java</artifactId> </dependency> <dependency> <groupId>org.apache.shiro</groupId> <artifactId>shiro-core</artifactId> <version>1.2.2</version> </dependency> <dependency> <groupId>org.apache.shiro</groupId> <artifactId>shiro-spring</artifactId> <version>1.2.2</version> </dependency> <!-- shiro ehcache --> <dependency> <groupId>org.apache.shiro</groupId> <artifactId>shiro-ehcache</artifactId> <version>1.2.2</version> </dependency> </dependencies> <build> <plugins> <plugin> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-maven-plugin</artifactId> <executions> <execution> <goals> <goal>repackage</goal> </goals> </execution> </executions> </plugin> </plugins> <finalName>name</finalName> </build>
2、以上代码引入了spring boot。spring mvc 和jpa，以及MysqL数据库的驱动jar；
编写启动类，并加装配置文件：
1、启动类如下：
import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.EnableAutoConfiguration;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.data.jpa.repository.config.EnableJpaAuditing;
import java.io.IOException;
import com.my.config.CommonProperties;
@SpringBootApplication
@EnableAutoConfiguration
@EnableJpaAuditing
public class Application {
public static void main(String[] args) throws IOException{
String loc = CommonProperties.loadProperties2System(System.getProperty("spring.config.location"));
System.getProperties().setProperty("application.version",CommonProperties.getVersion(Application.class));
System.getProperties().setProperty("app.home",loc + "/..");
SpringApplication.run(Application.class,args);
}
}
2、配置文件的位置放到classpath外边，方便在不重新打包的情况下修改，spring boot工程一般都打成jar包：
import java.io.File;
import java.io.FileInputStream;
import java.io.IOException;
import java.util.Properties;
import org.springframework.util.StringUtils;
public final class CommonProperties {
public static final String PPT_KEY_APP_HOME = "app.home";
public static final String DEFAULT_APP_HOME = "./";
public static final String getAppHome() {
return System.getProperty("./","./");
}
public static String loadProperties2System(String location) throws IOException {
String configLocation = location;
File cnf;
if (!StringUtils.hasLength(location)) {
configLocation = "./config";
cnf = new File(configLocation);
if (!cnf.exists() || !cnf.isDirectory()) {
configLocation = "../config";
cnf = new File(configLocation);
}
} else {
cnf = new File(location);
}
File[] arg2 = cnf.listFiles();
int arg3 = arg2.length;
for (int arg4 = 0; arg4 < arg3; ++arg4) {
File file = arg2[arg4];
if (file.isFile() && file.getName().endsWith(".properties")) {
Properties ppt = new Properties();
FileInputStream fi = new FileInputStream(file);
Throwable arg8 = null;
try {
ppt.load(fi);
System.getProperties().putAll(ppt);
} catch (Throwable arg17) {
arg8 = arg17;
throw arg17;
} finally {
if (fi != null) {
if (arg8 != null) {
try {
fi.close();
} catch (Throwable arg16) {
arg8.addSuppressed(arg16);
}
} else {
fi.close();
}
}
}
}
}
return configLocation;
}
public static String getVersion(Class<?> clazz) {
Package pkg = clazz.getPackage();
String ver = pkg != null ? pkg.getImplementationVersion() : "undefined";
return ver == null ? "undefined" : ver;
}
将配置文件放到jar包同级目录的config文件夹下，包括日志配置，application.yml文件,其他配置文件等；
编写自动配置类
用于扫描compan*,代替spring mvc的spring.xml配置文件：
import org.springframework.context.annotation.ComponentScan;
import org.springframework.context.annotation.Configuration;
@Configuration
@ComponentScan(basePackages = {
"com.my.rs","com.my.service","com.my.repository"})
public class AppAutoConfiguration {
}
import org.springframework.boot.autoconfigure.web.HttpMessageConverters;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.servlet.config.annotation.ResourceHandlerRegistry;
import org.springframework.web.servlet.config.annotation.WebMvcConfigurerAdapter;
/**
* 预配置
* */
@Configuration
public class MyConfiguration extends WebMvcConfigurerAdapter{
@Bean
public HttpMessageConverters customConverters() {
return new HttpMessageConverters();
}
@Override
public void addResourceHandlers(ResourceHandlerRegistry registry) {
//registry.addResourceHandler("/**")
// .addResourceLocations("classpath:/meta-inf/resources/**");
}
编写rs,service,repository
package com.my.rs;
import java.util.List;
import org.springframework.web.bind.annotation.RequestBody;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestMethod;
import org.springframework.web.bind.annotation.RequestParam;
import org.springframework.web.bind.annotation.ResponseBody;
import com.my.entity.User;
@RequestMapping({"/api/user"})
public interface UserRS {
@RequestMapping(value="/add",method={RequestMethod.POST})
@ResponseBody
public User saveUser(@RequestBody User user);
@RequestMapping(value="/update",method={RequestMethod.POST})
@ResponseBody
public User updateUser(@RequestBody User user);
@RequestMapping(value="/delete",method={RequestMethod.POST,RequestMethod.DELETE})
public void deleteUser(@RequestParam String[] userIds);
@RequestMapping(value="/get",method={RequestMethod.GET})
@ResponseBody
public User getUser(@RequestParam String userId);
@RequestMapping(value="/query/all",method={RequestMethod.GET})
public List<User> queryAll();
@RequestMapping(value="/query/byName",method={RequestMethod.GET})
public List<User> queryByName(@RequestParam String name);
@RequestMapping(value="/query/byParentId",method={RequestMethod.GET})
public List<User> queryChildren(@RequestParam String parentId);
//无参数分页查询
@RequestMapping(value="/query/page",method={RequestMethod.GET})
public List<User> queryByPage(@RequestParam int pageNo,@RequestParam int pageSize,@RequestBody(required=false) User user);
}
package com.my.rs.impl;
import java.util.List;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.RequestBody;
import org.springframework.web.bind.annotation.RestController;
import com.my.entity.User;
import com.my.rs.UserRS;
import com.my.service.UserService;
@RestController
public class UserRSImpl implements UserRS{
public static Logger logger = LoggerFactory.getLogger(UserRSImpl.class);
@Autowired
UserService _userService;
@Override
public User saveUser(@RequestBody User user){
try {
return _userService.save(user);
} catch (Throwable e) {
logger.error(e.getMessage(),e);
throw e;
}
}
@Override
public User updateUser(@RequestBody User user) {
return _userService.update(user);
}
@Override
public void deleteUser(String[] userIds) {
for (String userId : userIds) {
_userService.deleteById(userId);
}
}
@Override
public List<User> queryAll() {
return _userService.queryAll();
}
@Override
public List<User> queryByName(String name) {
return _userService.findByName(name);
}
@Override
public List<User> queryChildren(String parentId) {
return _userService.findByParentId(parentId);
}
@Override
public User getUser(String userId) {
return _userService.findById(userId);
}
@Override
public List<User> queryByPage(int pageNo,int pageSize,User user) {
return null;
}
}
package com.my.service;
import java.util.List;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;
import com.my.entity.User;
import com.my.repository.UserRepository;
@Service
public class UserService extends BaseService<User>{
@Autowired
UserRepository _userRepository;
public List<User> findByName(String name){
return _userRepository.findByName(name);
}
public List<User> findByParentId(String parentId){
return _userRepository.findByParentId(parentId);
}
}
package com.my.repository;
import java.util.List;
import com.my.entity.User;
public interface UserRepository extends BaseRepository<User>{
List<User> findByName(String name);
List<User> findByParentId(String parentId);
}
以上采用了分层模式，有点繁琐，但是对之后修改每层的业务逻辑比较方便
JPA相关的类如下：
package com.my.service;
import java.io.Serializable;
import javax.persistence.EntityManager;
import javax.transaction.Transactional;
import org.springframework.beans.factory.annotation.Autowired;
import com.my.repository.BaseRepository;
/**
* 一些共有的方法放这里
* */
@Transactional
public class BaseService<E extends Serializable> {
@Autowired
BaseRepository<E> _baseRepository;
@Autowired
EntityManager em;
public E save(E baseUnit){
return _baseRepository.saveAndFlush(baseUnit);
}
public E update(E baseUnit){
return _baseRepository.saveAndFlush(baseUnit);
}
public void deleteById(String id) {
_baseRepository.delete(id);
}
public java.util.List<E> queryAll(){
return _baseRepository.findAll();
}
public E findById(String id){
return _baseRepository.getone(id);
}
}
package com.my.repository;
import java.io.Serializable;
import org.springframework.data.jpa.repository.JpaRepository;
import org.springframework.data.repository.norepositoryBean;
@norepositoryBean
public interface BaseRepository<E> extends JpaRepository<E,Serializable>{
}
实体类：与数据库字段相关，需要注意下父类中的注解@MappedSuperclass
package com.my.entity;
import java.util.ArrayList;
import java.util.List;
import javax.persistence.Entity;
import javax.persistence.ManyToMany;
import org.hibernate.annotations.DynamicInsert;
import org.hibernate.annotations.DynamicUpdate;
import org.hibernate.validator.constraints.Email;
@Entity(name = "db_user")
@DynamicInsert
@DynamicUpdate
public class User extends BaseUnit {
/**
* 账户状态
*/
public static enum AccountStatus {
/**
* 正常
*/
Enable,//
/**
* 停用
*/
disable
}
private static final long serialVersionUID = -3101319619397064425L;
private String password;
private String salt;
/** 账户状态 */
private AccountStatus status;
/** 认证邮箱 */
@Email(message = "User.email属性必须符合邮箱格式")
private String email;
/** 移动电话号码 */
private String mobileNo;
/** 身份证号码 */
private String cardId;
@ManyToMany(targetEntity=Role.class)
private List<String> roleIds;
/** 昵称。可选。 */
private String nickName;
public String getCardId() {
return cardId;
}
public String getEmail() {
return email;
}
public String getMobileNo() {
return mobileNo;
}
public String getNickName() {
return nickName;
}
public String getpassword() {
return password;
}
public List<String> getRoleIds() {
if (roleIds == null) {
roleIds = new ArrayList<>();
}
return roleIds;
}
public String getSalt() {
return salt;
}
public AccountStatus getStatus() {
return status;
}
public void setCardId(String cardId) {
this.cardId = cardId;
}
public void setEmail(String email) {
this.email = email;
}
public void setMobileNo(String mobileNo) {
this.mobileNo = mobileNo;
}
public void setNickName(String nickName) {
this.nickName = nickName;
}
public void setPassword(String password) {
this.password = password;
}
public void setRoleIds(List<String> roleIds) {
this.roleIds = roleIds;
}
public void setSalt(String salt) {
this.salt = salt;
}
public void setStatus(AccountStatus status) {
this.status = status;
}
}
package com.my.entity;
import java.io.Serializable;
import java.util.Date;
import javax.persistence.Id;
import javax.persistence.MappedSuperclass;
import javax.validation.constraints.NotNull;
import javax.validation.constraints.Size;
import org.springframework.data.annotation.CreatedBy;
import org.springframework.data.annotation.CreatedDate;
import org.springframework.data.annotation.LastModifiedBy;
import org.springframework.data.annotation.LastModifiedDate;
@MappedSuperclass
public class BaseUnit implements Serializable {
@Id
@NotNull
public String id;
/**
* 父单元ID
*/
@Size(max = 32,message = "BaseUnit.parentId属性长度不能大于32")
public String parentId;
/** 父单元的类型 */
public ParentType parentType;
/**
* 单元的名称
*/
@NotNull(message = "BaseUnit.name属性不能为空")
public String name;
@CreatedBy
public String createBy;
@CreatedDate
public Date createDate;
@LastModifiedBy
public String lastModifiedBy;
/**
* 最后更新日期
*/
@LastModifiedDate
public Date lastModifiedDate;
public String getId() {
return id;
}
public void setId(String id) {
this.id = id;
}
/**
* 获取单元的名称
*
* @return 必填
*/
public String getName() {
return name;
}
/**
*
*
* @return UUID，不含{}和-
*/
public String getParentId() {
return parentId;
}
public ParentType getParentType() {
return parentType;
}
public String getStationId() {
return stationId;
}
public String getThumbnailId() {
return thumbnailId;
}
public String getCreateBy() {
return createBy;
}
public void setCreateBy(String createBy) {
this.createBy = createBy;
}
public Date getCreateDate() {
return createDate;
}
public void setCreateDate(Date createDate) {
this.createDate = createDate;
}
/**
* 设置单元的名称
*
* @param name
* 必填
*/
public void setName(String name) {
this.name = name;
}
/**
* 设置父单元ID
*
* @param parentId
* UUID，不含{}和-
*/
public void setParentId(String parentId) {
this.parentId = parentId;
}
public String getLastModifiedBy() {
return lastModifiedBy;
}
public void setLastModifiedBy(String lastModifiedBy) {
this.lastModifiedBy = lastModifiedBy;
}
public Date getLastModifiedDate() {
return lastModifiedDate;
}
public void setLastModifiedDate(Date lastModifiedDate) {
this.lastModifiedDate = lastModifiedDate;
}
}
配置文件：
server: port: 16800 contextpath: / logging: config: ./config/logback.xml spring: http: multipart: enabled: false datasource: url : jdbc:MysqL://127.0.0.1:3306/db?useUnicode=true&characterEncoding=utf-8 username : root password : 123456 driverClassName : com.MysqL.jdbc.Driver jpa: database : MysqL show-sql : true hibernate: ddl-auto : update jackson: serialization: INDENT_OUTPUT : true
#hibernate:配置了实体类维护数据库表结构的具体行为，update表示当实体类的属性发生变化时，表结构跟着更新， 这里我们也可以取值create，这个create表示启动的时候删除上一次生成的表，并根据实体类重新生成表， 这个时候之前表中的数据就会被清空；还可以取值create-drop，这个表示启动时根据实体类生成表，但是当sessionFactory关闭的时候表会被删除； validate表示启动时验证实体类和数据表是否一致；none表示啥都不做。 #show-sql表示hibernate在操作的时候在控制台打印真实的sql语句 #jackson表示格式化输出的json字符串
以上就是本文的全部内容，希望对大家的学习有所帮助，也希望大家多多支持编程小技巧。
您可能感兴趣的文章:
- 从SpringMVC迁移到Springboot的方法步骤
- springboot springmvc抛出全局异常的解决方法
- 基于SpringBoot与Mybatis实现SpringMVC Web项目
Spring 4 学习笔记 - Spring4 MVC 项目搭建（Java Config 配置）
以下源码连接： https://git.oschina.net/jerryxiao/Spring.git
1. 使用 Eclipse 创建 Maven Web 项目。 如下配置 pom.xml 文件：
<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd">
<modelVersion>4.0.0</modelVersion>
<groupId>Spring</groupId>
<artifactId>Spring</artifactId>
<packaging>war</packaging>
<version>0.0.1-SNAPSHOT</version>
<name>Spring Maven Webapp</name>
<url>http://maven.apache.org</url>
<dependencies>
<dependency>
<groupId>junit</groupId>
<artifactId>junit</artifactId>
<version>4.12</version>
</dependency>
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-web</artifactId>
<version>4.3.1.RELEASE</version>
</dependency>
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-webmvc</artifactId>
<version>4.2.7.RELEASE</version>
</dependency>
<dependency>
<groupId>org.slf4j</groupId>
<artifactId>slf4j-log4j12</artifactId>
<version>1.7.6</version>
</dependency>
<dependency>
<groupId>javax.servlet.jsp.jstl</groupId>
<artifactId>jstl-api</artifactId>
<version>1.2</version>
</dependency>
<dependency>
<groupId>javax.servlet.jsp.jstl</groupId>
<artifactId>javax.servlet.jsp.jstl-api</artifactId>
<version>1.2.1</version>
</dependency>
<dependency>
<groupId>taglibs</groupId>
<artifactId>standard</artifactId>
<version>1.1.2</version>
<scope>compile</scope>
</dependency>
<dependency>
<groupId>org.springframework.security</groupId>
<artifactId>spring-security-test</artifactId>
<version>4.1.1.RELEASE</version>
</dependency>
</dependencies>
<build>
<finalName>Spring</finalName>
</build>
</project>
2. 添加 Web APP 初始化启动类，主要采用集成 WebMvcConfigurerAdapter 类即可。 该类会创建 org.springframework.web.context.ContextLoaderListener 对象和 org.springframework.web.servlet.DispatcherServlet 对象。 代码如下所示：
/**
* @Project Spring
* @author Xiaowentao
* @Time 2016年7月17日
*/
package tom.spring.init;
import org.springframework.web.servlet.support.AbstractAnnotationConfigDispatcherServletInitializer;
import tom.spring.config.RootConfig;
import tom.spring.config.WebConfig;
public class SpringWebAppInitializer extends AbstractAnnotationConfigDispatcherServletInitializer {
@Override
protected Class<?>[] getRootConfigClasses() {
return new Class<?>[] {RootConfig.class};
}
@Override
protected Class<?>[] getServletConfigClasses() {
return new Class<?>[] {WebConfig.class};
}
@Override
protected String[] getServletMappings() {
return new String[] {"/"};
}
}
该类相当于在 web.xml 文件中添加如下配置：
<listener>
<listener-class>org.springframework.web.context.ContextLoaderListener</listener-class>
</listener>
<servlet>
<servlet-name>dispatcher</servlet-name>
<servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
<init-param>
<param-name>contextConfigLocation</param-name>
<param-value>classpath*:/servlet/*.xml</param-value>
</init-param>
<load-on-startup>1</load-on-startup>
</servlet>
<servlet-mapping>
<servlet-name>dispatcher</servlet-name>
<url-pattern>/</url-pattern>
</servlet-mapping>
3. 添加 Web App 配置类， 主要是给 JSP 文件配置一个 ViewResolvet ， 代码如下所示：
/**
* @Project Spring
* @author Xiaowentao
* @Time 2016年7月17日
*/
package tom.spring.config;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.ComponentScan;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.servlet.ViewResolver;
import org.springframework.web.servlet.config.annotation.DefaultServletHandlerConfigurer;
import org.springframework.web.servlet.config.annotation.EnableWebMvc;
import org.springframework.web.servlet.config.annotation.WebMvcConfigurerAdapter;
import org.springframework.web.servlet.view.InternalResourceViewResolver;
/**
* @author Xiaowentao
*
*/
@Configuration
@EnableWebMvc
@ComponentScan(value="tom.spring.controller")
public class WebConfig extends WebMvcConfigurerAdapter {
@Bean
public ViewResolver viewResolver(){
InternalResourceViewResolver resolver = new InternalResourceViewResolver();
resolver.setPrefix("/WEB-INF/views/");
resolver.setSuffix(".jsp");
resolver.setExposeContextBeansAsAttributes(true);
return resolver;
}
@Override
public void configureDefaultServletHandling(
DefaultServletHandlerConfigurer configure){
configure.enable();
}
}
以上代码相当于在 XML 中配置 一个 名叫 “viewResolver” 类型为 InternalResourceViewResolvet 的 Bean. 和在 Servlet 配置文件中添加 <mvc:default-servlet-handler/>
4. 添加 Servlet 配置，开启 Spring Web MVC 功能。如下所示代码， 无需任何实现，添加注解即可：
package tom.spring.config;
import org.springframework.context.annotation.ComponentScan;
import org.springframework.context.annotation.ComponentScan.Filter;
import org.springframework.context.annotation.Configuration;
import org.springframework.context.annotation.FilterType;
import org.springframework.web.servlet.config.annotation.EnableWebMvc;
@Configuration
@ComponentScan(basePackages={"tom.spring"},
excludeFilters={
@Filter(type=FilterType.ANNOTATION, value=EnableWebMvc.class)
})
public class RootConfig {
}
5. 添加控制器，该控制器仅返回一个视图的名称， 比如代码中返回 “home” 字符串。DispatcherServlet 会根据返回的字符串去查找对象的视图文件即：.jsp 文件。本例为： home.jsp . 根据之前的配置，视图文件在目录 /WEB-INF/views/ 下。
/**
* @Project Spring
* @author Xiaowentao
* @Time 2016年7月17日
*/
package tom.spring.controller;
import org.springframework.stereotype.Controller;
import org.springframework.web.bind.annotation.RequestMapping;
/**
* @author Xiaowentao
*
*/
@Controller
@RequestMapping("/")
public class HomeController {
@RequestMapping({"/"})
public String home(){
return "home";
}
}
7. 在目录 /WEB-INF/views/ 创建 home.jsp 文件。 随便写一点内容。 我们已经把首页隐射到 home.jsp 视图上了。
注： 去掉项目创建是生成的 index.jsp . 系统默认会渲染 index.jsp 文件。
今天关于[Spring4.x]基于spring4.x纯注解的非Web工程搭建和springmvc非注解配置的介绍到此结束，谢谢您的阅读，有关6、spring注解+springMVC注解+Mybatis注解+log4j+idea+maven、Maven 工程搭建 spring boot+spring mvc+JPA、Maven工程搭建spring boot+spring mvc+JPA的示例、Spring 4 学习笔记 - Spring4 MVC 项目搭建（Java Config 配置）等更多相关知识的信息可以在本站进行查询。
本文标签：
![[转帖]Ubuntu 安装 Wine方法（ubuntu如何安装wine）](https://www.gvkun.com/zb_users/cache/thumbs/4c83df0e2303284d68480d1b1378581d-180-120-1.jpg)
